Toyota Sprinter Specs, Engines & Dimensions (1991–2002) — Seventh Generation

The seventh-generation Toyota Sprinter offers practical bodies and dependable drivetrains. This overview covers the Estate 5-door and Sedan, with examples of available engines and transmissions.

← All Toyota models

Toyota Sprinter Engines and Transmissions

The Toyota Sprinter engine range balances economy and versatility. A 2.0 diesel pairs with a manual or automatic transmission in front-wheel-drive Estate models, while a 1.6 gasoline with automatic and all-wheel drive appears in the Sedan. These are selected examples, not an exhaustive list.

Estate 5-door — Toyota Sprinter Engines and Transmissions

Estate 5-door Toyota Sprinter Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.5 MT	Gasoline	1456 cm³	79 hp	58 kW	118 N⋅m	Manual	FWD
1.5 AT	Gasoline	1456 cm³	79 hp	58 kW	118 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1496 cm³	89 hp	65 kW	128 N⋅m	Manual	FWD
1.5 AT	Gasoline	1496 cm³	89 hp	65 kW	128 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1496 cm³	91 hp	67 kW	129 N⋅m	Manual	FWD
1.5 AT	Gasoline	1496 cm³	91 hp	67 kW	129 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1496 cm³	97 hp	71 kW	124 N⋅m	Manual	FWD
1.5 AT	Gasoline	1496 cm³	97 hp	71 kW	124 N⋅m	Automatic	FWD
2.0 MT	Diesel	1974 cm³	73 hp	54 kW	129 N⋅m	Manual	FWD
2.0 AT	Diesel	1974 cm³	73 hp	54 kW	129 N⋅m	Automatic	FWD
2.2 MT	Diesel	2184 cm³	79 hp	58 kW	147 N⋅m	Manual	FWD
2.2 AT	Diesel	2184 cm³	79 hp	58 kW	147 N⋅m	Automatic	FWD

Sedan — Toyota Sprinter Engines and Transmissions

Sedan Toyota Sprinter Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 MT	Gasoline	1331 cm³	97 hp	71 kW	113 N⋅m	Manual	FWD
1.3 AT	Gasoline	1331 cm³	97 hp	71 kW	113 N⋅m	Automatic	FWD
1.3 AT	Gasoline	1331 cm³	100 hp	74 kW	115 N⋅m	Automatic	FWD
1.3 MT	Gasoline	1331 cm³	100 hp	74 kW	115 N⋅m	Manual	FWD
1.5 AT	Gasoline	1498 cm³	105 hp	77 kW	135 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1498 cm³	105 hp	77 kW	135 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	115 hp	85 kW	147 N⋅m	Manual	AWD
1.6 AT	Gasoline	1587 cm³	115 hp	85 kW	147 N⋅m	Automatic	FWD
1.6 AT	Gasoline	1587 cm³	115 hp	85 kW	147 N⋅m	Automatic	AWD
1.6 MT	Gasoline	1587 cm³	115 hp	85 kW	147 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	160 hp	118 kW	161 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1587 cm³	160 hp	118 kW	161 N⋅m	Manual	FWD
2.0 AT	Diesel	1974 cm³	73 hp	54 kW	132 N⋅m	Automatic	FWD
2.0 MT	Diesel	1974 cm³	73 hp	54 kW	132 N⋅m	Manual	FWD
2.0 MT	Diesel	1974 cm³	73 hp	54 kW	132 N⋅m	Manual	AWD

Toyota Sprinter Dimensions

Estate 5-door — Toyota Sprinter Dimensions

Estate 5-door Toyota Sprinter Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.5 MT	4265 mm	1685 mm	1435 mm	2465 mm	960 kg	150 mm
1.5 AT	4265 mm	1685 mm	1435 mm	2465 mm	980 kg	150 mm
1.5 MT	4265 mm	1685 mm	1435 mm	2465 mm	990 kg	150 mm
1.5 AT	4265 mm	1685 mm	1435 mm	2465 mm	1010 kg	150 mm
1.5 MT	4265 mm	1685 mm	1435 mm	2465 mm	970 kg	150 mm
1.5 AT	4265 mm	1685 mm	1435 mm	2465 mm	990 kg	150 mm
1.5 MT	4265 mm	1685 mm	1435 mm	2465 mm	960 kg	150 mm
1.5 AT	4265 mm	1685 mm	1435 mm	2465 mm	980 kg	150 mm
2.0 MT	4265 mm	1685 mm	1435 mm	2465 mm	1040 kg	150 mm
2.0 AT	4265 mm	1685 mm	1435 mm	2465 mm	1070 kg	150 mm
2.2 MT	4265 mm	1685 mm	1435 mm	2465 mm	1090 kg	150 mm
2.2 AT	4265 mm	1685 mm	1435 mm	2465 mm	1120 kg	150 mm

Sedan — Toyota Sprinter Dimensions

Sedan Toyota Sprinter Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.3 MT	4290 mm	1685 mm	1375 mm	2465 mm	Not provided	150 mm
1.3 AT	4290 mm	1685 mm	1375 mm	2465 mm	Not provided	150 mm
1.3 AT	4290 mm	1685 mm	1375 mm	2465 mm	980 kg	150 mm
1.3 MT	4290 mm	1685 mm	1375 mm	2465 mm	960 kg	150 mm
1.5 AT	4290 mm	1685 mm	1375 mm	2465 mm	1000 kg	150 mm
1.5 MT	4290 mm	1685 mm	1375 mm	2465 mm	1020 kg	150 mm
1.6 MT	4290 mm	1685 mm	1375 mm	2465 mm	1140 kg	160 mm
1.6 AT	4290 mm	1685 mm	1375 mm	2465 mm	1080 kg	150 mm
1.6 AT	4290 mm	1685 mm	1375 mm	2465 mm	1180 kg	160 mm
1.6 MT	4290 mm	1685 mm	1375 mm	2465 mm	1050 kg	150 mm
1.6 AT	4290 mm	1685 mm	1375 mm	2465 mm	1110 kg	145 mm
1.6 MT	4290 mm	1685 mm	1375 mm	2465 mm	1080 kg	145 mm
2.0 AT	4290 mm	1685 mm	1375 mm	2465 mm	1080 kg	155 mm
2.0 MT	4290 mm	1685 mm	1375 mm	2465 mm	1050 kg	155 mm
2.0 MT	4290 mm	1685 mm	1375 mm	2465 mm	1210 kg	160 mm
