BMW 5 Series Engines and Transmissions
BMW 5 Series engine choices include diesel, gasoline and plug-in hybrid powertrains. Examples include the rear-wheel-drive 520d with a manual gearbox, the all-wheel-drive 530i with an automatic, and the rear-wheel-drive 530e plug-in hybrid. These configurations offer different balances of long-distance touring, traction and electric driving for shorter trips.
Estate 5-door — BMW 5 Series Engines and Transmissions
Estate 5-door BMW 5 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 520d 2.0 MT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Manual RWD 520d 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic RWD 520d 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic AWD 525d 2.0 AT Diesel 1995 cm³ 231 hp 170 kW 500 N⋅m Automatic RWD 530d 3.0 AT Diesel 2993 cm³ 265 hp 195 kW 620 N⋅m Automatic RWD 530d 3.0 AT Diesel 2993 cm³ 265 hp 195 kW 620 N⋅m Automatic AWD 540d 3.0 AT Diesel 2993 cm³ 320 hp 235 kW 680 N⋅m Automatic AWD M550d 3.0 AT Diesel 2993 cm³ 400 hp 294 kW 760 N⋅m Automatic AWD 520i 2.0 AT Gasoline 1998 cm³ 184 hp 135 kW 290 N⋅m Automatic RWD 530i 2.0 AT Gasoline 1998 cm³ 252 hp 185 kW 350 N⋅m Automatic RWD 530i 2.0 AT Gasoline 1998 cm³ 252 hp 185 kW 350 N⋅m Automatic AWD 540i 3.0 AT Gasoline 2998 cm³ 340 hp 250 kW 450 N⋅m Automatic AWD
Sedan — BMW 5 Series Engines and Transmissions
Sedan BMW 5 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 530i 2.0 AT Gasoline 1998 cm³ 249 hp 183 kW 350 N⋅m Automatic AWD 530i 2.0 AT Gasoline 1998 cm³ 252 hp 185 kW 350 N⋅m Automatic AWD 520d 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic AWD 530d 3.0 AT Diesel 2993 cm³ 249 hp 183 kW 620 N⋅m Automatic AWD M550d 3.0 AT Diesel 2993 cm³ 400 hp 294 kW 760 N⋅m Automatic AWD 520d 2.0 MT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Manual RWD 525d 2.0 AT Diesel 1995 cm³ 231 hp 170 kW 500 N⋅m Automatic RWD 530d 3.0 AT Diesel 2993 cm³ 265 hp 195 kW 620 N⋅m Automatic RWD 530d 3.0 AT Diesel 2993 cm³ 265 hp 195 kW 620 N⋅m Automatic AWD 540d 3.0 AT Diesel 2993 cm³ 320 hp 235 kW 680 N⋅m Automatic AWD 520i 2.0 AT Gasoline 1998 cm³ 184 hp 135 kW 290 N⋅m Automatic RWD 540i 3.0 AT Gasoline 2998 cm³ 340 hp 250 kW 450 N⋅m Automatic AWD M550i 4.4 AT Gasoline 4395 cm³ 462 hp 340 kW 650 N⋅m Automatic AWD 530i 2.0 AT Gasoline 1998 cm³ 249 hp 183 kW 350 N⋅m Automatic RWD 530i 2.0 AT Gasoline 1998 cm³ 252 hp 185 kW 350 N⋅m Automatic RWD 540i 3.0 AT Gasoline 2998 cm³ 340 hp 250 kW 450 N⋅m Automatic RWD 520d 2.0 AT Diesel 1995 cm³ 190 hp 140 kW 400 N⋅m Automatic RWD 530e 2.0 AT Plug-in 1998 cm³ 292 hp 136 kW 428 N⋅m Automatic RWD 530e 2.0 AT iPerformance Plug-in 1998 cm³ 252 hp 185 kW 420 N⋅m Automatic RWD 530e 2.0 AT xDrive iPerformance Plug-in 1998 cm³ 252 hp 185 kW 420 N⋅m Automatic AWD
BMW 5 Series Dimensions
Estate 5-door — BMW 5 Series Dimensions
Estate 5-door BMW 5 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 520d 2.0 MT 4943 mm 1868 mm 1498 mm 2975 mm 1655 kg 2380 kg 140 mm 520d 2.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1660 kg 2390 kg 140 mm 520d 2.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1750 kg 2480 kg 140 mm 525d 2.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1690 kg 2425 kg 140 mm 530d 3.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1640 kg 2345 kg 140 mm 530d 3.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1800 kg 2530 kg 140 mm 540d 3.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1845 kg 2565 kg 140 mm M550d 3.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1955 kg 2620 kg 130 mm 520i 2.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1635 kg 2350 kg 140 mm 530i 2.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1640 kg 2360 kg 140 mm 530i 2.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1700 kg 2440 kg 140 mm 540i 3.0 AT 4943 mm 1868 mm 1498 mm 2975 mm 1765 kg 2495 kg 140 mm
Sedan — BMW 5 Series Dimensions
Sedan BMW 5 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 530i 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1595 kg 2270 kg 139 mm 530i 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1595 kg 2270 kg 139 mm 520d 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1620 kg 2325 kg 139 mm 530d 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1695 kg 2385 kg 139 mm M550d 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1920 kg 2470 kg 139 mm 520d 2.0 MT 4936 mm 1868 mm 1483 mm 2975 mm 1540 kg 2230 kg 144 mm 525d 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1610 kg 2295 kg 144 mm 530d 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1640 kg 2345 kg 144 mm 530d 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1695 kg 2385 kg 139 mm 540d 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1750 kg 2440 kg 139 mm 520i 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1530 kg 2200 kg 144 mm 540i 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1660 kg 2340 kg 139 mm M550i 4.4 AT 4936 mm 1868 mm 1483 mm 2975 mm 1810 kg 2460 kg 131 mm 530i 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1540 kg 2200 kg 144 mm 530i 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1540 kg 2200 kg 144 mm 540i 3.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1595 kg 2270 kg 144 mm 520d 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1560 kg 2245 kg 144 mm 530e 2.0 AT 4936 mm 1868 mm 1483 mm 2975 mm 1845 kg 2420 kg 150 mm 530e 2.0 AT iPerformance 4936 mm 1868 mm 1483 mm 2975 mm 1770 kg 2420 kg 150 mm 530e 2.0 AT xDrive iPerformance 4936 mm 1868 mm 1483 mm 2975 mm 1860 kg 2500 kg 150 mm
BMW 5 Series Cargo Space
Estate 5-door — BMW 5 Series Cargo Space
Sedan — BMW 5 Series Cargo Space
BMW 5 Series Trims and Equipment
The 530e iPerformance is available with Business and M-Sport equipment packages. Business focuses on comfort and convenience features suited for professional use, while M-Sport adds sportier styling and suspension tuning for a more dynamic driving experience. These trim levels allow you to tailor the vehicle to your preferences, enhancing comfort, convenience, or athletic character.
BMW 5 Series Battery, Range and Charging
The 530e uses a lithium-ion battery to power its electric motor, enabling electric-only driving for short distances and improving overall fuel efficiency. Charging can be done at home or public stations, and the battery recharges during driving through regenerative braking. This setup offers practical electric range for daily commutes while retaining the flexibility of a gasoline engine for longer trips.
Sedan — BMW 5 Series Battery, Range and Charging
Sedan BMW 5 Series Battery, Range and Charging Modification Battery power Battery type Driving range, maximum Full charge home Full public charging time 530e 2.0 AT Not provided Lithium-ion batterie 56 km 360 min 216 min 530e 2.0 AT iPerformance 9.2 kWh Lithium-ion batterie 56 km 360 min 216 min 530e 2.0 AT xDrive iPerformance 9.2 kWh Lithium-ion batterie 56 km 360 min 216 min
