Catalog / Suzuki / Jimny / 3 generation, restyling 1
Suzuki Jimny Engines and Transmissions
Suzuki Jimny engine and powertrain choices stay compact. A 0.7 MT gasoline SUV 3-doors pairs a manual gearbox with all-wheel drive for trails, while a 1.5 MT diesel manual all-wheel-drive example adds pulling power. The 1.3 AT gasoline automatic with rear-wheel drive is a simpler on-road drivetrain.
SUV 3-doors — Suzuki Jimny Engines and Transmissions
SUV 3-doors Suzuki Jimny Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 0.7 MT Gasoline 658 cm³ 64 hp 47 kW 103 N⋅m Manual AWD 0.7 AT Gasoline 658 cm³ 64 hp 47 kW 103 N⋅m Automatic AWD 1.3 MT Gasoline 1328 cm³ 85 hp 63 kW 110 N⋅m Manual RWD 1.3 AT Gasoline 1328 cm³ 85 hp 63 kW 110 N⋅m Automatic RWD 1.3 MT Gasoline 1328 cm³ 88 hp 63 kW 118 N⋅m Manual AWD 1.3 AT Gasoline 1328 cm³ 88 hp 63 kW 118 N⋅m Automatic AWD 1.5 MT Diesel 1461 cm³ 86 hp 63 kW 160 N⋅m Manual AWD 1.3 MT Gasoline 1328 cm³ 85 hp 63 kW 110 N⋅m Manual AWD 1.3 AT Gasoline 1328 cm³ 85 hp 63 kW 110 N⋅m Automatic AWD
SUV cabriolet — Suzuki Jimny Engines and Transmissions
SUV cabriolet Suzuki Jimny Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1298 cm³ 80 hp 59 kW 104 N⋅m Manual RWD 1.3 MT Gasoline 1298 cm³ 80 hp 59 kW 104 N⋅m Manual AWD 1.3 AT Gasoline 1298 cm³ 80 hp 59 kW 104 N⋅m Automatic AWD 1.5 MT Diesel 1461 cm³ 86 hp 63 kW 160 N⋅m Manual AWD
Suzuki Jimny Dimensions
SUV 3-doors — Suzuki Jimny Dimensions
SUV 3-doors Suzuki Jimny Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 0.7 MT 3645 mm 1600 mm 1705 mm 2250 mm 930 kg Not provided 190 mm 0.7 AT 3645 mm 1600 mm 1705 mm 2250 mm Not provided Not provided 190 mm 1.3 MT 3645 mm 1600 mm 1705 mm 2250 mm 1005 kg 1365 kg 190 mm 1.3 AT 3645 mm 1600 mm 1705 mm 2250 mm 1005 kg 1365 kg 190 mm 1.3 MT 3645 mm 1600 mm 1705 mm 2250 mm 1060 kg 1420 kg 190 mm 1.3 AT 3645 mm 1600 mm 1705 mm 2250 mm 1060 kg 1420 kg 190 mm 1.5 MT 3645 mm 1600 mm 1705 mm 2250 mm 1050 kg 1420 kg 190 mm 1.3 MT 3645 mm 1600 mm 1705 mm 2250 mm 1060 kg 1420 kg 190 mm 1.3 AT 3645 mm 1600 mm 1705 mm 2250 mm 1075 kg 1420 kg 190 mm
SUV cabriolet — Suzuki Jimny Dimensions
SUV cabriolet Suzuki Jimny Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 3665 mm 1600 mm 1655 mm 2250 mm 995 kg 1365 kg 185 mm 1.3 MT 3665 mm 1600 mm 1655 mm 2250 mm 1010 kg 1420 kg 190 mm 1.3 AT 3665 mm 1600 mm 1655 mm 2250 mm Not provided 1420 kg 190 mm 1.5 MT 3665 mm 1600 mm 1655 mm 2250 mm 1100 kg 1420 kg 190 mm
Suzuki Jimny Cargo Space
SUV 3-doors — Suzuki Jimny Cargo Space
SUV cabriolet — Suzuki Jimny Cargo Space
SUV cabriolet Suzuki Jimny Cargo Space Modification Trunk volume min Trunk volume max 1.3 MT 85 l 620 l 1.3 MT 85 l 620 l 1.3 AT 85 l 620 l 1.5 MT 85 l 620 l
Suzuki Jimny Trims and Equipment
