Subaru Forester Specs, Engines & Dimensions (2012–2016)

Subaru Forester Engines and Transmissions

A Subaru Forester engine here can be diesel or gasoline, both as 2.0 MT examples with a manual transmission and all-wheel drive. You pick diesel for longer trips, or gasoline for simpler daily driving. These powertrains illustrate the generation, not every drivetrain on the five-door SUV.

SUV 5-doors — Subaru Forester Engines and Transmissions

SUV 5-doors Subaru Forester Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.5 CVT	Gasoline	2498 cm³	171 hp	126 kW	235 N⋅m	Variable	AWD
2.0 CVT	Gasoline	1998 cm³	280 hp	206 kW	350 N⋅m	Variable	AWD
2.5 CVT	Gasoline	2498 cm³	175 hp	129 kW	235 N⋅m	Variable	AWD
2.0 MT	Diesel	1998 cm³	147 hp	108 kW	350 N⋅m	Manual	AWD
2.0 CVT	Gasoline	1995 cm³	150 hp	110 kW	198 N⋅m	Variable	AWD
2.0 MT	Gasoline	1995 cm³	150 hp	110 kW	198 N⋅m	Manual	AWD
2.0 CVT	Gasoline	1998 cm³	241 hp	177 kW	350 N⋅m	Variable	AWD

Subaru Forester Dimensions

SUV 5-doors — Subaru Forester Dimensions

SUV 5-doors Subaru Forester Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.5 CVT	4595 mm	1795 mm	1735 mm	2640 mm	1513 kg	1850 kg	220 mm
2.0 CVT	4595 mm	1795 mm	1735 mm	2640 mm	1590 kg	Not provided	220 mm
2.5 CVT	4595 mm	1795 mm	1735 mm	2640 mm	1513 kg	Not provided	220 mm
2.0 MT	4595 mm	1795 mm	1735 mm	2640 mm	1469 kg	Not provided	220 mm
2.0 CVT	4595 mm	1795 mm	1735 mm	2640 mm	1499 kg	1850 kg	220 mm
2.0 MT	4595 mm	1795 mm	1735 mm	2640 mm	1469 kg	1850 kg	220 mm
2.0 CVT	4595 mm	1795 mm	1735 mm	2640 mm	1613 kg	1850 kg	220 mm

Subaru Forester Cargo Space

SUV 5-doors — Subaru Forester Cargo Space

SUV 5-doors Subaru Forester Cargo Space
Modification	Trunk volume min	Trunk volume max
2.5 CVT	488 l	1577 l
2.0 CVT	488 l	1577 l
2.5 CVT	488 l	1577 l
2.0 MT	488 l	1577 l
2.0 CVT	488 l	1577 l
2.0 MT	488 l	1577 l
2.0 CVT	488 l	1577 l

Subaru Forester Trims and Equipment

Subaru Forester trim levels sit on top of a technical version such as the gasoline 2.0 MT. On that five-door SUV, one equipment configuration is named X. You use X for cabin fittings and convenience features, not to change the engine, manual gearbox, or all-wheel drive.

Subaru Forester Trims and Equipment
Modification	Body	Equipment
2.5 CVT	SUV 5-doors	CB
2.5 CVT	SUV 5-doors	CS
2.5 CVT	SUV 5-doors	KR
2.0 CVT	SUV 5-doors	1A
2.0 CVT	SUV 5-doors	BM
2.0 CVT	SUV 5-doors	GJ
2.0 CVT	SUV 5-doors	KJ
2.0 CVT	SUV 5-doors	NM
2.0 CVT	SUV 5-doors	VF
2.0 CVT	SUV 5-doors	X
2.0 CVT	SUV 5-doors	XS
2.0 CVT	SUV 5-doors	Z
2.0 MT	SUV 5-doors	X
2.0 CVT	SUV 5-doors	GR
2.0 CVT	SUV 5-doors	NS
2.0 CVT	SUV 5-doors	XT
