Catalog / Mazda / Xedos 9 / 1 generation
Mazda Xedos 9 Engines and Transmissions
Mazda Xedos 9 engine choices include gasoline examples such as the 2.0 MT, 2.0 AT and 2.3 AT, all with front-wheel drive. The manual transmission in the 2.0 MT lets you choose when to shift, while the automatic versions reduce the effort of driving in stop-start traffic.
Sedan — Mazda Xedos 9 Engines and Transmissions
Sedan Mazda Xedos 9 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 MT Gasoline 1995 cm³ 143 hp 105 kW 176 N⋅m Manual FWD 2.0 AT Gasoline 1995 cm³ 143 hp 105 kW 176 N⋅m Automatic FWD 2.3 AT Gasoline 2255 cm³ 211 hp 155 kW 290 N⋅m Automatic FWD 2.3 MT Gasoline 2255 cm³ 211 hp 155 kW 290 N⋅m Manual FWD 2.5 MT Gasoline 2497 cm³ 167 hp 123 kW 212 N⋅m Manual FWD 2.5 AT Gasoline 2497 cm³ 167 hp 123 kW 212 N⋅m Automatic FWD
Mazda Xedos 9 Dimensions
Sedan — Mazda Xedos 9 Dimensions
Sedan Mazda Xedos 9 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 MT 4825 mm 1770 mm 1390 mm 2750 mm 1415 kg 1940 kg 140 mm 2.0 AT 4825 mm 1770 mm 1390 mm 2750 mm Not provided Not provided 120 mm 2.3 AT 4825 mm 1770 mm 1390 mm 2750 mm 1500 kg 1985 kg 140 mm 2.3 MT 4825 mm 1770 mm 1390 mm 2750 mm Not provided 1985 kg 120 mm 2.5 MT 4825 mm 1770 mm 1390 mm 2750 mm 1415 kg 1940 kg 140 mm 2.5 AT 4825 mm 1770 mm 1390 mm 2750 mm 1415 kg 1940 kg 140 mm
Mazda Xedos 9 Cargo Space
Sedan — Mazda Xedos 9 Cargo Space
