Catalog / Volvo / 240 Series / 1 generation
Volvo 240 Series Engines and Transmissions
A Volvo 240 Series engine is gasoline-powered with rear-wheel drive. Examples include the 2.3 MT Sedan 2-doors and 2.7 MT Sedan with a manual gearbox, plus the 2.1 AT Sedan if you want an automatic transmission in the same drivetrain layout.
Sedan 2-doors — Volvo 240 Series Engines and Transmissions
Sedan 2-doors Volvo 240 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.3 MT Gasoline 2315 cm³ 140 hp 103 kW 191 N⋅m Manual RWD
Sedan — Volvo 240 Series Engines and Transmissions
Sedan Volvo 240 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.3 MT Gasoline 2300 cm³ 136 hp 100 kW Not provided Manual RWD 2.0 MT Gasoline 1986 cm³ 101 hp 74 kW 160 N⋅m Manual RWD 2.0 MT Gasoline 2000 cm³ 95 hp 70 kW Not provided Manual RWD 2.1 MT Gasoline 2080 cm³ 100 hp 73 kW Not provided Manual RWD 2.1 MT Gasoline 2080 cm³ 107 hp 79 kW Not provided Manual RWD 2.1 AT Gasoline 2100 cm³ 122 hp 90 kW Not provided Automatic RWD 2.1 MT Gasoline 2100 cm³ 122 hp 90 kW Not provided Manual RWD 2.1 MT Gasoline 2127 cm³ 155 hp 114 kW 240 N⋅m Manual RWD 2.3 MT Gasoline 2300 cm³ 113 hp 83 kW Not provided Manual RWD 2.3 AT Gasoline 2300 cm³ 113 hp 83 kW Not provided Automatic RWD 2.3 MT Gasoline 2300 cm³ 115 hp 85 kW 192 N⋅m Manual RWD 2.3 AT Gasoline 2300 cm³ 136 hp 100 kW Not provided Automatic RWD 2.3 AT Gasoline 2300 cm³ 140 hp 103 kW Not provided Automatic RWD 2.3 MT Gasoline 2300 cm³ 140 hp 103 kW Not provided Manual RWD 2.3 MT Gasoline 2316 cm³ 113 hp 83 kW 183 N⋅m Manual RWD 2.3 MT Gasoline 2316 cm³ 115 hp 85 kW 192 N⋅m Manual RWD 2.3 AT Gasoline 2316 cm³ 115 hp 85 kW 192 N⋅m Automatic RWD 2.3 AT Gasoline 2316 cm³ 131 hp 96 kW 185 N⋅m Automatic RWD 2.3 MT Gasoline 2316 cm³ 131 hp 96 kW 185 N⋅m Manual RWD 2.7 MT Gasoline 2700 cm³ 140 hp 103 kW Not provided Manual RWD 2.4 MT Diesel 2383 cm³ 82 hp 60 kW 140 N⋅m Manual RWD 2.4 MT Diesel 2383 cm³ 82 hp 60 kW 145 N⋅m Manual RWD 2.0 MT Gasoline 1998 cm³ 90 hp 66 kW Not provided Manual RWD 2.0 MT Gasoline 2000 cm³ 82 hp 60 kW Not provided Manual RWD 1.8 MT Gasoline 1788 cm³ 76 hp 55 kW Not provided Manual RWD
Estate 5-door — Volvo 240 Series Engines and Transmissions
Estate 5-door Volvo 240 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1986 cm³ 101 hp 74 kW 160 N⋅m Manual RWD 2.0 MT Gasoline 1986 cm³ 112 hp 82 kW 158 N⋅m Manual RWD 2.0 MT Gasoline 1998 cm³ 90 hp 66 kW Not provided Manual RWD 2.0 MT Gasoline 1998 cm³ 97 hp 71 kW Not provided Manual RWD 2.0 AT Gasoline 1998 cm³ 97 hp 71 kW Not provided Automatic RWD 2.1 MT Gasoline 2080 cm³ 100 hp 74 kW Not provided Manual RWD 2.1 MT Gasoline 2080 cm³ 107 hp 79 kW Not provided Manual RWD 2.1 AT Gasoline 2080 cm³ 107 hp 79 kW Not provided Automatic RWD 2.1 AT Gasoline 2080 cm³ 155 hp 114 kW Not provided Automatic RWD 2.1 MT Gasoline 2100 cm³ 97 hp 71 kW Not provided Manual RWD 2.1 MT Gasoline 2127 cm³ 122 hp 90 kW 162 N⋅m Manual RWD 2.1 MT Gasoline 2127 cm³ 155 hp 114 kW 240 N⋅m Manual RWD 2.3 AT Gasoline 2300 cm³ 131 hp 96 kW Not provided Automatic RWD 2.3 AT Gasoline 2300 cm³ 133 hp 98 kW Not provided Automatic RWD 2.3 MT Gasoline 2300 cm³ 136 hp 100 kW Not provided Manual RWD 2.3 AT Gasoline 2300 cm³ 136 hp 100 kW Not provided Automatic RWD 2.3 AT Gasoline 2316 cm³ 113 hp 83 kW 183 N⋅m Automatic RWD 2.3 MT Gasoline 2316 cm³ 113 hp 83 kW 183 N⋅m Manual RWD 2.3 AT Gasoline 2316 cm³ 115 hp 85 kW 192 N⋅m Automatic RWD 2.3 MT Gasoline 2316 cm³ 115 hp 85 kW 192 N⋅m Manual RWD 2.3 MT Gasoline 2316 cm³ 133 hp 98 kW Not provided Manual RWD 2.7 AT Gasoline 2700 cm³ 140 hp 103 kW Not provided Automatic RWD 2.4 MT Diesel 2383 cm³ 82 hp 60 kW 140 N⋅m Manual RWD 2.4 MT Diesel 2400 cm³ 79 hp 58 kW Not provided Manual RWD 2.1 AT Gasoline 2100 cm³ 122 hp 90 kW Not provided Automatic RWD 2.7 MT Gasoline 2700 cm³ 140 hp 103 kW Not provided Manual RWD 2.0 MT Gasoline 2000 cm³ 82 hp 60 kW Not provided Manual RWD
Volvo 240 Series Dimensions
Sedan 2-doors — Volvo 240 Series Dimensions
Sedan 2-doors Volvo 240 Series Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm 110 mm
Sedan — Volvo 240 Series Dimensions
Sedan Volvo 240 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.0 MT 4790 mm 1707 mm 1435 mm 2640 mm 1222 kg 1780 kg 110 mm 2.0 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.1 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.1 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.1 AT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.1 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.1 MT 4790 mm 1707 mm 1435 mm 2640 mm 1289 kg 1789 kg 110 mm 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided 1780 kg 110 mm 2.3 AT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.3 AT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.3 AT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm 1264 kg 1780 kg 110 mm 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm 1243 kg 1780 kg 110 mm 2.3 AT 4790 mm 1707 mm 1435 mm 2640 mm 1243 kg 1780 kg 110 mm 2.3 AT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.3 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.7 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.4 MT 4790 mm 1707 mm 1435 mm 2640 mm 1335 kg 1850 kg 110 mm 2.4 MT 4790 mm 1707 mm 1435 mm 2640 mm 1335 kg 1850 kg 110 mm 2.0 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 2.0 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm 1.8 MT 4790 mm 1707 mm 1435 mm 2640 mm Not provided Not provided 110 mm
Estate 5-door — Volvo 240 Series Dimensions
Estate 5-door Volvo 240 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4840 mm 1710 mm 1460 mm 2650 mm 1278 kg 1830 kg 110 mm 2.0 MT 4840 mm 1710 mm 1460 mm 2650 mm 1324 kg 1930 kg 110 mm 2.0 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.0 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.0 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 MT 4840 mm 1710 mm 1460 mm 2650 mm 1311 kg 1900 kg 110 mm 2.1 MT 4840 mm 1710 mm 1460 mm 2650 mm 1343 kg 1900 kg 110 mm 2.3 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.3 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.3 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.3 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.3 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.3 MT 4840 mm 1710 mm 1460 mm 2650 mm 1305 kg 1930 kg 110 mm 2.3 AT 4840 mm 1710 mm 1460 mm 2650 mm 1297 kg 1930 kg 110 mm 2.3 MT 4840 mm 1710 mm 1460 mm 2650 mm 1297 kg 1930 kg 110 mm 2.3 MT 4840 mm 1710 mm 1460 mm 2650 mm 1311 kg 1900 kg 110 mm 2.7 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.4 MT 4840 mm 1710 mm 1460 mm 2650 mm 1385 kg 2000 kg 110 mm 2.4 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.1 AT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.7 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm 2.0 MT 4840 mm 1710 mm 1460 mm 2650 mm Not provided Not provided 110 mm
