Toyota Land Cruiser Prado Specs, Engines & Dimensions (1996–1999) — Second Generation

The second-generation Toyota Land Cruiser Prado blends rugged all-wheel-drive capability with everyday comfort. Available in three- and five-door SUV bodies, it offers practical gasoline engines paired with manual or automatic transmissions to suit varied driving needs.

← All Toyota models

Toyota Land Cruiser Prado Engines and Transmissions

Depending on the configuration, the Prado’s gasoline engines range from a 2.7-liter four-cylinder to a stronger 3.4-liter V6. Both are built for durability and smooth low-speed response, making them well suited to off-road trails and loaded highway trips alike. You can choose between a manual transmission for direct control and an automatic for relaxed daily driving.

SUV 3-doors — Toyota Land Cruiser Prado Engines and Transmissions

SUV 3-doors Toyota Land Cruiser Prado Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.7 MT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Manual	AWD
2.7 AT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Automatic	AWD
3.4 MT	Gasoline	3378 cm³	178 hp	131 kW	303 N⋅m	Manual	AWD
3.4 AT	Gasoline	3378 cm³	178 hp	131 kW	303 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	125 hp	92 kW	295 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	130 hp	95 kW	295 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	130 hp	95 kW	295 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	125 hp	92 kW	295 N⋅m	Automatic	AWD

SUV 5-doors — Toyota Land Cruiser Prado Engines and Transmissions

SUV 5-doors Toyota Land Cruiser Prado Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.7 AT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Automatic	AWD
2.7 MT	Gasoline	2694 cm³	150 hp	110 kW	240 N⋅m	Manual	AWD
3.4 MT	Gasoline	3378 cm³	178 hp	131 kW	303 N⋅m	Manual	AWD
3.4 AT	Gasoline	3378 cm³	178 hp	131 kW	303 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	125 hp	92 kW	295 N⋅m	Manual	AWD
3.0 MT	Diesel	2982 cm³	130 hp	95 kW	295 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	130 hp	95 kW	295 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	140 hp	103 kW	333 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	140 hp	103 kW	333 N⋅m	Automatic	AWD
3.0 MT	Diesel	2982 cm³	145 hp	107 kW	343 N⋅m	Manual	AWD
3.0 AT	Diesel	2982 cm³	145 hp	107 kW	343 N⋅m	Automatic	AWD
3.0 AT	Diesel	2982 cm³	125 hp	92 kW	295 N⋅m	Automatic	AWD

Toyota Land Cruiser Prado Dimensions

SUV 3-doors — Toyota Land Cruiser Prado Dimensions

SUV 3-doors Toyota Land Cruiser Prado Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.7 MT	4330 mm	1820 mm	1870 mm	2365 mm	1710 kg	2510 kg	230 mm
2.7 AT	4330 mm	1820 mm	1870 mm	2365 mm	1710 kg	2510 kg	230 mm
3.4 MT	4330 mm	1820 mm	1870 mm	2365 mm	1755 kg	2510 kg	230 mm
3.4 AT	4330 mm	1820 mm	1870 mm	2365 mm	1755 kg	2510 kg	230 mm
3.0 MT	4330 mm	1820 mm	1870 mm	2365 mm	1730 kg	2550 kg	230 mm
3.0 AT	4330 mm	1820 mm	1870 mm	2365 mm	1775 kg	2510 kg	230 mm
3.0 MT	4330 mm	1820 mm	1870 mm	2365 mm	1775 kg	2510 kg	230 mm
3.0 AT	4330 mm	1820 mm	1870 mm	2365 mm	1730 kg	2550 kg	230 mm

SUV 5-doors — Toyota Land Cruiser Prado Dimensions

SUV 5-doors Toyota Land Cruiser Prado Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.7 AT	4675 mm	1820 mm	1880 mm	2675 mm	1790 kg	2720 kg	230 mm
2.7 MT	4675 mm	1820 mm	1880 mm	2675 mm	1750 kg	2680 kg	230 mm
3.4 MT	4675 mm	1820 mm	1880 mm	2675 mm	1835 kg	2710 kg	230 mm
3.4 AT	4675 mm	1820 mm	1880 mm	2675 mm	1835 kg	2710 kg	230 mm
3.0 MT	4675 mm	1820 mm	1880 mm	2675 mm	1810 kg	2680 kg	230 mm
3.0 MT	4675 mm	1820 mm	1880 mm	2675 mm	1855 kg	2730 kg	230 mm
3.0 AT	4675 mm	1820 mm	1880 mm	2675 mm	1855 kg	2730 kg	230 mm
3.0 MT	4675 mm	1820 mm	1880 mm	2675 mm	1800 kg	Not provided	230 mm
3.0 AT	4675 mm	1820 mm	1880 mm	2675 mm	1970 kg	Not provided	230 mm
3.0 MT	4675 mm	1820 mm	1880 mm	2675 mm	1840 kg	Not provided	230 mm
3.0 AT	4675 mm	1820 mm	1880 mm	2675 mm	1980 kg	Not provided	230 mm
3.0 AT	4675 mm	1820 mm	1880 mm	2675 mm	1810 kg	2680 kg	230 mm

Toyota Land Cruiser Prado Cargo Space

SUV 3-doors — Toyota Land Cruiser Prado Cargo Space

SUV 3-doors Toyota Land Cruiser Prado Cargo Space
Modification	Trunk volume min	Trunk volume max
2.7 MT	450 l	840 l
2.7 AT	450 l	840 l
3.4 MT	450 l	840 l
3.4 AT	450 l	840 l
3.0 MT	450 l	840 l
3.0 AT	450 l	840 l
3.0 MT	450 l	840 l
3.0 AT	450 l	840 l

SUV 5-doors — Toyota Land Cruiser Prado Cargo Space

SUV 5-doors Toyota Land Cruiser Prado Cargo Space
Modification	Trunk volume min	Trunk volume max
2.7 AT	740 l	1150 l
2.7 MT	740 l	1150 l
3.4 MT	740 l	1150 l
3.4 AT	740 l	1150 l
3.0 MT	740 l	1150 l
3.0 MT	740 l	1150 l
3.0 AT	740 l	1150 l
3.0 MT	740 l	1150 l
3.0 AT	740 l	1150 l
3.0 MT	740 l	1150 l
3.0 AT	740 l	1150 l
3.0 AT	740 l	1150 l

Toyota Land Cruiser Prado Trims and Equipment

Toyota Land Cruiser Prado Trims and Equipment
Modification	Body	Equipment
3.0 AT	SUV 3-doors	STD
3.0 AT	SUV 3-doors	Luxury
3.0 AT	SUV 5-doors	STD
