Toyota Auris Engines and Transmissions
Toyota Auris engine choices cover small petrol units, economical diesels and a petrol-electric hybrid. Selected examples include the 1.4 MT with a manual gearbox in the three-door, the 1.4 TFT diesel with a robotic transmission, and the 1.8 CVT hybrid with a variable transmission. Each sends power to the front wheels, the usual drivetrain layout in this class.
Hatchback 3-door — Toyota Auris Engines and Transmissions
Hatchback 3-door Toyota Auris Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.4 MT Diesel 1364 cm³ 90 hp 66 kW 205 N⋅m Manual FWD 1.4 MT Diesel 1364 cm³ 90 hp 66 kW 205 N⋅m Manual FWD 1.4 MT Gasoline 1398 cm³ 97 hp 71 kW 130 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 124 hp 91 kW 157 N⋅m Manual FWD 1.6 TFT Gasoline 1598 cm³ 124 hp 91 kW 157 N⋅m Robotic FWD 1.6 MT Gasoline 1598 cm³ 132 hp 97 kW 160 N⋅m Manual FWD 1.6 TFT Gasoline 1598 cm³ 132 hp 97 kW 160 N⋅m Robotic FWD
Hatchback 5-door — Toyota Auris Engines and Transmissions
Hatchback 5-door Toyota Auris Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.3 MT Gasoline 1329 cm³ 101 hp 74 kW 132 N⋅m Manual FWD 1.4 MT Gasoline 1398 cm³ 97 hp 71 kW 130 N⋅m Manual FWD 1.5 CVT Gasoline 1496 cm³ 105 hp 77 kW 138 N⋅m Variable AWD 1.5 CVT Gasoline 1496 cm³ 110 hp 81 kW 138 N⋅m Variable FWD 1.6 MT Gasoline 1598 cm³ 124 hp 91 kW 157 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 132 hp 97 kW 160 N⋅m Manual FWD 1.6 TFT Gasoline 1598 cm³ 132 hp 97 kW 160 N⋅m Robotic FWD 1.8 CVT Gasoline 1794 cm³ 128 hp 94 kW 166 N⋅m Variable AWD 1.8 MT Gasoline 1794 cm³ 136 hp 100 kW 175 N⋅m Manual FWD 1.8 CVT Gasoline 1797 cm³ 136 hp 100 kW 175 N⋅m Variable FWD 1.8 MT Gasoline 1798 cm³ 147 hp 108 kW 180 N⋅m Manual FWD 1.4 MT Diesel 1364 cm³ 90 hp 66 kW 190 N⋅m Manual FWD 1.4 TFT Diesel 1364 cm³ 90 hp 66 kW 190 N⋅m Robotic FWD 2.0 MT Diesel 1998 cm³ 126 hp 93 kW 300 N⋅m Manual FWD 2.2 MT Diesel 2231 cm³ 177 hp 130 kW 400 N⋅m Manual FWD 1.8 CVT Hybrid 1798 cm³ 98 hp 72 kW 142 N⋅m Variable FWD 1.6 TFT Gasoline 1598 cm³ 124 hp 91 kW 157 N⋅m Robotic FWD 1.6 AT Gasoline 1598 cm³ 124 hp 91 kW 157 N⋅m Automatic FWD
Toyota Auris Dimensions
Hatchback 3-door — Toyota Auris Dimensions
Hatchback 3-door Toyota Auris Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.4 MT 4220 mm 1760 mm 1515 mm 2600 mm 1220 kg 1720 kg 150 mm 1.4 MT 4220 mm 1760 mm 1515 mm 2600 mm 1220 kg 1720 kg 150 mm 1.4 MT 4220 mm 1760 mm 1515 mm 2600 mm 1220 kg 1720 kg 150 mm 1.6 MT 4220 mm 1760 mm 1515 mm 2600 mm 1230 kg 1750 kg 150 mm 1.6 TFT 4220 mm 1760 mm 1515 mm 2600 mm 1230 kg 1750 kg 150 mm 1.6 MT 4220 mm 1760 mm 1515 mm 2600 mm 1275 kg 1750 kg 140 mm 1.6 TFT 4220 mm 1760 mm 1515 mm 2600 mm 1320 kg 1750 kg 140 mm
Hatchback 5-door — Toyota Auris Dimensions
Hatchback 5-door Toyota Auris Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.3 MT 4220 mm 1760 mm 1515 mm 2600 mm 1220 kg 1720 kg 140 mm 1.4 MT 4220 mm 1760 mm 1515 mm 2600 mm 1220 kg 1720 kg 150 mm 1.5 CVT 4220 mm 1760 mm 1515 mm 2600 mm 1330 kg 1920 kg 150 mm 1.5 CVT 4220 mm 1760 mm 1515 mm 2600 mm 1330 kg 1920 kg 150 mm 1.6 MT 4220 mm 1760 mm 1515 mm 2600 mm 1230 kg 1750 kg 150 mm 1.6 MT 4220 mm 1760 mm 1515 mm 2600 mm 1275 kg 1750 kg 140 mm 1.6 TFT 4220 mm 1760 mm 1515 mm 2600 mm 1320 kg 1750 kg 140 mm 1.8 CVT 4220 mm 1760 mm 1515 mm 2600 mm 1370 kg 1920 kg 150 mm 1.8 MT 4220 mm 1760 mm 1515 mm 2600 mm 1260 kg 1535 kg 140 mm 1.8 CVT 4220 mm 1760 mm 1515 mm 2600 mm 1260 kg 1535 kg 140 mm 1.8 MT 4220 mm 1760 mm 1515 mm 2600 mm 1260 kg Not provided 140 mm 1.4 MT 4220 mm 1760 mm 1515 mm 2600 mm 1285 kg 1760 kg 150 mm 1.4 TFT 4220 mm 1760 mm 1515 mm 2600 mm 1285 kg 1760 kg 150 mm 2.0 MT 4220 mm 1760 mm 1515 mm 2600 mm 1400 kg 1890 kg 150 mm 2.2 MT 4220 mm 1760 mm 1515 mm 2600 mm 1435 kg 1920 kg 150 mm 1.8 CVT 4220 mm 1760 mm 1515 mm 2600 mm 1455 kg 1805 kg 114 mm 1.6 TFT 4220 mm 1760 mm 1515 mm 2600 mm 1230 kg 1750 kg 150 mm 1.6 AT 4220 mm 1760 mm 1515 mm 2600 mm 1230 kg 1750 kg 150 mm
Toyota Auris Cargo Space
Hatchback 3-door — Toyota Auris Cargo Space
Hatchback 5-door — Toyota Auris Cargo Space
Toyota Auris Trims and Equipment
Toyota Auris trim levels sit above the technical version, so one engine and gearbox pairing can appear with several equipment packages. The 1.8 CVT hybrid, for example, is listed with HSD equipment. Because features such as climate control, wheels and driver assistance vary, check the exact car rather than assuming trims match across versions.
Toyota Auris Trims and Equipment Modification Body Equipment 1.8 CVT Hatchback 5-door HSD 1.6 TFT Hatchback 5-door GLI 1.6 TFT Hatchback 5-door Luxury 1.6 TFT Hatchback 5-door Platinum Terra 1.6 TFT Hatchback 5-door SR 1.6 TFT Hatchback 5-door Terra Plus 1.6 AT Hatchback 5-door Terra
