Rolls-Royce Phantom Specs, Engines & Dimensions (2012–2016)

Rolls-Royce Phantom Engines and Transmissions

The Rolls-Royce Phantom engine in these examples is a 6.8-litre gasoline V12 paired with an automatic transmission and rear-wheel drive, as seen in the 6.8 AT Coupe, Sedan and Sedan Long. Such a powertrain prioritises quiet, low-effort acceleration over revs, with the drivetrain masking gearchanges almost entirely.

Coupe — Rolls-Royce Phantom Engines and Transmissions

Coupe Rolls-Royce Phantom Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
6.8 AT	Gasoline	6749 cm³	460 hp	338 kW	720 N⋅m	Automatic	RWD

Sedan — Rolls-Royce Phantom Engines and Transmissions

Sedan Rolls-Royce Phantom Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
6.8 AT	Gasoline	6749 cm³	460 hp	338 kW	720 N⋅m	Automatic	RWD

Sedan Long — Rolls-Royce Phantom Engines and Transmissions

Sedan Long Rolls-Royce Phantom Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
6.8 AT	Gasoline	6749 cm³	460 hp	338 kW	720 N⋅m	Automatic	RWD

Cabrio — Rolls-Royce Phantom Engines and Transmissions

Cabrio Rolls-Royce Phantom Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
6.8 AT	Gasoline	6749 cm³	460 hp	338 kW	720 N⋅m	Automatic	RWD

Rolls-Royce Phantom Dimensions

Coupe — Rolls-Royce Phantom Dimensions

Coupe Rolls-Royce Phantom Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
6.8 AT	5612 mm	1987 mm	1598 mm	3320 mm	2580 kg	3050 kg	140 mm

Sedan — Rolls-Royce Phantom Dimensions

Sedan Rolls-Royce Phantom Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
6.8 AT	5842 mm	1990 mm	1638 mm	3570 mm	2560 kg	3110 kg	140 mm

Sedan Long — Rolls-Royce Phantom Dimensions

Sedan Long Rolls-Royce Phantom Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
6.8 AT	6092 mm	1990 mm	1640 mm	3820 mm	2670 kg	3170 kg	140 mm

Cabrio — Rolls-Royce Phantom Dimensions

Cabrio Rolls-Royce Phantom Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
6.8 AT	5612 mm	1987 mm	1566 mm	3320 mm	2630 kg	3050 kg	140 mm

Rolls-Royce Phantom Cargo Space

Coupe — Rolls-Royce Phantom Cargo Space

Coupe Rolls-Royce Phantom Cargo Space
Modification	Trunk volume min
6.8 AT	395 l

Sedan — Rolls-Royce Phantom Cargo Space

Sedan Rolls-Royce Phantom Cargo Space
Modification	Trunk volume min
6.8 AT	460 l

Sedan Long — Rolls-Royce Phantom Cargo Space

Sedan Long Rolls-Royce Phantom Cargo Space
Modification	Trunk volume min
6.8 AT	460 l

Cabrio — Rolls-Royce Phantom Cargo Space

Cabrio Rolls-Royce Phantom Cargo Space
Modification	Trunk volume min
6.8 AT	315 l

Rolls-Royce Phantom Trims and Equipment

Rolls-Royce Phantom trim levels sit above the technical version rather than beside it: the 6.8 AT Coupe, for instance, is listed with a Standart equipment configuration. In practice much of the specification came from individual commissioning, so two cars sharing one trim label can differ considerably in materials and fitted options.

Rolls-Royce Phantom Trims and Equipment
Modification	Body	Equipment
6.8 AT	Coupe	Standart
6.8 AT	Sedan	Standart
6.8 AT	Sedan Long	Standart
6.8 AT	Cabrio	Standart
