Pontiac Wave Specs, Engines & Dimensions (2006–2009)

Pontiac Wave Engines and Transmissions

The Pontiac Wave engine focuses on dependable, everyday performance. A 1.6-liter gasoline unit pairs with either a manual or automatic transmission, sending power to the front wheels. This setup keeps the Wave simple to drive in traffic while remaining easy on fuel during commutes.

Sedan — Pontiac Wave Engines and Transmissions

Sedan Pontiac Wave Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 AT	Gasoline	1598 cm³	106 hp	78 kW	148 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1598 cm³	106 hp	78 kW	148 N⋅m	Manual	FWD

Mini 5-doors — Pontiac Wave Engines and Transmissions

Mini 5-doors Pontiac Wave Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 AT	Gasoline	1598 cm³	106 hp	78 kW	148 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1598 cm³	106 hp	78 kW	148 N⋅m	Manual	FWD

Pontiac Wave Dimensions

Sedan — Pontiac Wave Dimensions

Sedan Pontiac Wave Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 AT	4310 mm	1710 mm	1505 mm	2480 mm	1148 kg	1535 kg	160 mm
1.6 MT	4310 mm	1710 mm	1505 mm	2480 mm	1048 kg	1535 kg	160 mm

Mini 5-doors — Pontiac Wave Dimensions

Mini 5-doors Pontiac Wave Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 AT	3880 mm	1670 mm	1495 mm	2480 mm	1148 kg	1535 kg	160 mm
1.6 MT	3880 mm	1670 mm	1495 mm	2480 mm	1048 kg	1535 kg	160 mm

Pontiac Wave Cargo Space

Sedan — Pontiac Wave Cargo Space

Sedan Pontiac Wave Cargo Space
Modification	Trunk volume min
1.6 AT	350 l
1.6 MT	350 l

Mini 5-doors — Pontiac Wave Cargo Space

Mini 5-doors Pontiac Wave Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 AT	200 l	1190 l
1.6 MT	200 l	1190 l
