Peugeot 307 Specs, Engines & Dimensions (2001–2006) — First Generation

The first-generation Peugeot 307 offers several ways to fit your routine, from three- and five-door hatchbacks to an estate and Cabrio. Body style, engine and equipment each play a part in choosing a suitable version.

← All Peugeot models

Peugeot 307 Engines and Transmissions

Peugeot 307 engine options include the gasoline-powered Cabrio 2.0 AT with an automatic transmission, plus diesel Estate 5-door examples named 1.4 MT and 1.6 MT with manuals. These selected versions all use front-wheel drive. An automatic saves you repeated gear changes in traffic, while a manual gives you direct control over gear selection.

Cabrio — Peugeot 307 Engines and Transmissions

Cabrio Peugeot 307 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Manual	FWD
2.0 AT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1997 cm³	177 hp	130 kW	202 N⋅m	Manual	FWD

Estate 5-door — Peugeot 307 Engines and Transmissions

Estate 5-door Peugeot 307 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Diesel	1997 cm³	107 hp	79 kW	250 N⋅m	Manual	FWD
1.4 MT	Diesel	1398 cm³	68 hp	50 kW	160 N⋅m	Manual	FWD
1.6 MT	Diesel	1560 cm³	109 hp	80 kW	260 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Manual	FWD
2.0 MT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Automatic	FWD

Hatchback 3-door — Peugeot 307 Engines and Transmissions

Hatchback 3-door Peugeot 307 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1360 cm³	75 hp	55 kW	120 N⋅m	Manual	FWD
1.4 MT	Gasoline	1360 cm³	88 hp	65 kW	133 N⋅m	Manual	FWD
1.4 MT	Diesel	1398 cm³	68 hp	50 kW	150 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	107 hp	79 kW	250 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Manual	FWD
2.0 AT	Gasoline	1997 cm³	137 hp	100 kW	190 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1997 cm³	137 hp	100 kW	190 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Automatic	FWD

Hatchback 5-door — Peugeot 307 Engines and Transmissions

Hatchback 5-door Peugeot 307 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1360 cm³	75 hp	55 kW	120 N⋅m	Manual	FWD
1.4 MT	Gasoline	1360 cm³	88 hp	65 kW	133 N⋅m	Manual	FWD
1.4 MT	Diesel	1398 cm³	68 hp	50 kW	150 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	107 hp	79 kW	250 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1997 cm³	137 hp	100 kW	190 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1997 cm³	137 hp	100 kW	190 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD

Peugeot 307 Dimensions

Cabrio — Peugeot 307 Dimensions

Cabrio Peugeot 307 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4347 mm	1759 mm	1424 mm	2605 mm	1455 kg	1830 kg	120 mm
2.0 AT	4347 mm	1759 mm	1424 mm	2605 mm	1463 kg	1960 kg	110 mm
2.0 MT	4347 mm	1759 mm	1424 mm	2605 mm	1490 kg	1830 kg	120 mm

Estate 5-door — Peugeot 307 Dimensions

Estate 5-door Peugeot 307 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4420 mm	1755 mm	1570 mm	2708 mm	1280 kg	1780 kg	120 mm
1.4 MT	4420 mm	1755 mm	1570 mm	2708 mm	1154 kg	1679 kg	120 mm
1.6 MT	4420 mm	1755 mm	1570 mm	2708 mm	1393 kg	1900 kg	120 mm
1.6 MT	4420 mm	1755 mm	1570 mm	2708 mm	1360 kg	1960 kg	120 mm
2.0 MT	4420 mm	1755 mm	1570 mm	2708 mm	1355 kg	1940 kg	120 mm
2.0 MT	4420 mm	1755 mm	1570 mm	2708 mm	1320 kg	1760 kg	120 mm
1.6 AT	4420 mm	1755 mm	1570 mm	2708 mm	1360 kg	1960 kg	120 mm
2.0 AT	4420 mm	1755 mm	1570 mm	2708 mm	1355 kg	1940 kg	120 mm

Hatchback 3-door — Peugeot 307 Dimensions

Hatchback 3-door Peugeot 307 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4202 mm	1730 mm	1510 mm	2608 mm	1140 kg	1640 kg	120 mm
1.4 MT	4202 mm	1730 mm	1510 mm	2608 mm	1150 kg	1640 kg	120 mm
1.4 MT	4202 mm	1730 mm	1510 mm	2608 mm	1180 kg	1680 kg	120 mm
2.0 MT	4202 mm	1730 mm	1510 mm	2608 mm	1280 kg	1780 kg	120 mm
1.6 MT	4202 mm	1730 mm	1510 mm	2608 mm	1193 kg	1693 kg	120 mm
2.0 AT	4202 mm	1730 mm	1510 mm	2608 mm	1270 kg	1700 kg	120 mm
2.0 MT	4202 mm	1730 mm	1510 mm	2608 mm	1270 kg	1700 kg	120 mm
2.0 MT	4202 mm	1730 mm	1510 mm	2608 mm	1320 kg	1760 kg	120 mm
1.6 AT	4202 mm	1730 mm	1510 mm	2608 mm	1205 kg	1705 kg	120 mm

Hatchback 5-door — Peugeot 307 Dimensions

Hatchback 5-door Peugeot 307 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4202 mm	1730 mm	1510 mm	2608 mm	1140 kg	1640 kg	120 mm
1.4 MT	4202 mm	1730 mm	1510 mm	2608 mm	1150 kg	1640 kg	120 mm
1.4 MT	4202 mm	1730 mm	1510 mm	2608 mm	1180 kg	1680 kg	120 mm
2.0 MT	4202 mm	1730 mm	1510 mm	2608 mm	1280 kg	1780 kg	120 mm
1.6 MT	4202 mm	1730 mm	1510 mm	2608 mm	1193 kg	1693 kg	120 mm
1.6 AT	4202 mm	1730 mm	1510 mm	2608 mm	1204 kg	1676 kg	120 mm
2.0 AT	4202 mm	1730 mm	1510 mm	2608 mm	1270 kg	1700 kg	120 mm
2.0 MT	4202 mm	1730 mm	1510 mm	2608 mm	1270 kg	1700 kg	120 mm
2.0 MT	4202 mm	1730 mm	1510 mm	2608 mm	1320 kg	1760 kg	120 mm

Peugeot 307 Cargo Space

Cabrio — Peugeot 307 Cargo Space

Cabrio Peugeot 307 Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	204 l	305 l
2.0 AT	204 l	305 l
2.0 MT	204 l	305 l

Estate 5-door — Peugeot 307 Cargo Space

Estate 5-door Peugeot 307 Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	340 l	1540 l
1.4 MT	340 l	1540 l
1.6 MT	340 l	1540 l
1.6 MT	340 l	1540 l
2.0 MT	340 l	1540 l
2.0 MT	340 l	1540 l
1.6 AT	340 l	1540 l
2.0 AT	340 l	1540 l

Hatchback 3-door — Peugeot 307 Cargo Space

Hatchback 3-door Peugeot 307 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	341 l	1328 l
1.4 MT	341 l	1328 l
1.4 MT	341 l	1328 l
2.0 MT	341 l	1328 l
1.6 MT	341 l	1328 l
2.0 AT	341 l	1328 l
2.0 MT	341 l	1328 l
2.0 MT	341 l	1328 l
1.6 AT	341 l	1328 l

Hatchback 5-door — Peugeot 307 Cargo Space

Hatchback 5-door Peugeot 307 Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	341 l	1328 l
1.4 MT	341 l	1328 l
1.4 MT	341 l	1328 l
2.0 MT	341 l	1328 l
1.6 MT	341 l	1328 l
1.6 AT	341 l	1328 l
2.0 AT	341 l	1328 l
2.0 MT	341 l	1328 l
2.0 MT	341 l	1328 l

Peugeot 307 Trims and Equipment

Peugeot 307 trim levels distinguish equipment choices within a technical version: the gasoline, automatic 1.6 AT Hatchback 5-door has configurations named XT and XR. When comparing cars, check the actual comfort and convenience features fitted to each. The engine and transmission designation alone does not tell you which equipment you will get.

Peugeot 307 Trims and Equipment
Modification	Body	Equipment
2.0 AT	Cabrio	Base
1.6 AT	Estate 5-door	XR
1.6 AT	Hatchback 5-door	XT
1.6 AT	Hatchback 5-door	XR
