Mitsubishi Diamante Specs, Engines & Dimensions (1995–2005)

Mitsubishi Diamante Engines and Transmissions

You will find the Mitsubishi Diamante engine paired with an automatic and front-wheel drive in the examples here. A 3.0 AT Estate 5-door suits relaxed family hauling, while a 3.5 AT Sedan shows how a larger gasoline mill keeps the same transmission and drivetrain character.

Estate 5-door — Mitsubishi Diamante Engines and Transmissions

Estate 5-door Mitsubishi Diamante Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Gasoline	2972 cm³	200 hp	147 kW	275 N⋅m	Automatic	FWD

Sedan — Mitsubishi Diamante Engines and Transmissions

Sedan Mitsubishi Diamante Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.5 AT	Gasoline	2497 cm³	175 hp	129 kW	225 N⋅m	Automatic	FWD
2.5 AT	Gasoline	2497 cm³	175 hp	129 kW	225 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2497 cm³	200 hp	147 kW	240 N⋅m	Automatic	FWD
2.5 AT	Gasoline	2497 cm³	200 hp	147 kW	240 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2498 cm³	170 hp	125 kW	225 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	230 hp	169 kW	286 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	230 hp	169 kW	286 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2972 cm³	240 hp	177 kW	304 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2972 cm³	240 hp	177 kW	304 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	270 hp	199 kW	301 N⋅m	Automatic	FWD
3.5 AT	Gasoline	3497 cm³	208 hp	153 kW	300 N⋅m	Automatic	FWD

Mitsubishi Diamante Dimensions

Estate 5-door — Mitsubishi Diamante Dimensions

Estate 5-door Mitsubishi Diamante Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
3.0 AT	4810 mm	1785 mm	1500 mm	2720 mm	1600 kg	165 mm

Sedan — Mitsubishi Diamante Dimensions

Sedan Mitsubishi Diamante Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.5 AT	4785 mm	1785 mm	1435 mm	2720 mm	1440 kg	Not provided	165 mm
2.5 AT	4785 mm	1785 mm	1435 mm	2720 mm	1530 kg	Not provided	165 mm
2.5 AT	4785 mm	1785 mm	1435 mm	2720 mm	1480 kg	Not provided	165 mm
2.5 AT	4785 mm	1785 mm	1435 mm	2720 mm	1570 kg	Not provided	165 mm
2.5 AT	4785 mm	1785 mm	1435 mm	2720 mm	1500 kg	Not provided	155 mm
3.0 AT	4785 mm	1785 mm	1435 mm	2720 mm	1510 kg	Not provided	165 mm
3.0 AT	4785 mm	1785 mm	1435 mm	2720 mm	1620 kg	Not provided	165 mm
3.0 AT	4785 mm	1785 mm	1435 mm	2720 mm	1610 kg	Not provided	155 mm
3.0 AT	4785 mm	1785 mm	1435 mm	2720 mm	1510 kg	Not provided	155 mm
3.0 AT	4785 mm	1785 mm	1435 mm	2720 mm	1510 kg	Not provided	155 mm
3.5 AT	4785 mm	1785 mm	1435 mm	2720 mm	1550 kg	2000 kg	155 mm
