Mitsubishi Diamante Specs, Engines & Dimensions (1990–1997)

Mitsubishi Diamante Engines and Transmissions

A Mitsubishi Diamante engine here is gasoline, and the powertrain you choose shapes everyday driving. The 2.0 MT Sedan uses a manual and front-wheel drive for a more direct feel. Automatics such as the 2.5 AT Sedan and 3.0 AT Estate 5-door ease commuting, with all-wheel drive on the 2.5 AT for extra traction.

Estate 5-door — Mitsubishi Diamante Engines and Transmissions

Estate 5-door Mitsubishi Diamante Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Gasoline	2972 cm³	165 hp	121 kW	251 N⋅m	Automatic	FWD

Sedan — Mitsubishi Diamante Engines and Transmissions

Sedan Mitsubishi Diamante Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1998 cm³	125 hp	92 kW	172 N⋅m	Manual	FWD
2.0 AT	Gasoline	1998 cm³	125 hp	92 kW	172 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	145 hp	107 kW	182 N⋅m	Automatic	FWD
2.5 AT	Gasoline	2497 cm³	175 hp	129 kW	222 N⋅m	Automatic	AWD
2.5 AT	Gasoline	2497 cm³	175 hp	129 kW	222 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	165 hp	121 kW	251 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	210 hp	154 kW	270 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2972 cm³	210 hp	154 kW	270 N⋅m	Automatic	FWD

Mitsubishi Diamante Dimensions

Estate 5-door — Mitsubishi Diamante Dimensions

Estate 5-door Mitsubishi Diamante Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
3.0 AT	4785 mm	1780 mm	1515 mm	2720 mm	1590 kg	170 mm

Sedan — Mitsubishi Diamante Dimensions

Sedan Mitsubishi Diamante Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
2.0 MT	4785 mm	1780 mm	1410 mm	2720 mm	1360 kg	165 mm
2.0 AT	4785 mm	1780 mm	1410 mm	2720 mm	1400 kg	165 mm
2.0 AT	4785 mm	1780 mm	1410 mm	2720 mm	1400 kg	165 mm
2.5 AT	4785 mm	1780 mm	1410 mm	2720 mm	1660 kg	165 mm
2.5 AT	4785 mm	1780 mm	1410 mm	2720 mm	1660 kg	165 mm
3.0 AT	4785 mm	1780 mm	1410 mm	2720 mm	1590 kg	170 mm
3.0 AT	4785 mm	1780 mm	1410 mm	2720 mm	1680 kg	165 mm
3.0 AT	4785 mm	1780 mm	1410 mm	2720 mm	1580 kg	165 mm

Mitsubishi Diamante Cargo Space

Estate 5-door — Mitsubishi Diamante Cargo Space

Estate 5-door Mitsubishi Diamante Cargo Space
Modification	Trunk volume min	Trunk volume max
3.0 AT	428 l	1460 l
