Catalog / Lotus / Evora / 1 generation
Lotus Evora Engines and Transmissions
The examples shown share a 3.5-litre petrol V6 sitting behind the cabin and driving the rear wheels. That Lotus Evora engine works with either a manual gearbox, as in the 3.5 MT 410, or the automatic 3.5 AT 410, while the GT designation marks a further-honed variant of the same layout.
Coupe — Lotus Evora Engines and Transmissions
Coupe Lotus Evora Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
3.5 MT Gasoline 3456 cm³ 280 hp 206 kW 346 N⋅m Manual RWD 3.5 AT Gasoline 3456 cm³ 280 hp 206 kW 346 N⋅m Automatic RWD 3.5 MT Gasoline 3456 cm³ 350 hp 257 kW 400 N⋅m Manual RWD 3.5 AT Gasoline 3456 cm³ 350 hp 257 kW 400 N⋅m Automatic RWD 3.5 MT Gasoline 3456 cm³ 350 hp 258 kW 400 N⋅m Manual RWD 3.5 AT Gasoline 3456 cm³ 350 hp 258 kW 400 N⋅m Automatic RWD 3.5 MT Gasoline 3456 cm³ 406 hp 298 kW 410 N⋅m Manual RWD 3.5 AT Gasoline 3456 cm³ 406 hp 298 kW 410 N⋅m Automatic RWD 3.5 MT 410 Gasoline 3456 cm³ 416 hp 306 kW 410 N⋅m Manual RWD 3.5 AT 410 Gasoline 3456 cm³ 416 hp 306 kW 410 N⋅m Automatic RWD 3.5 MT Gasoline 3456 cm³ 436 hp 321 kW 440 N⋅m Manual RWD 3.5 MT GT 410 Gasoline 3456 cm³ 416 hp 306 kW 410 N⋅m Manual RWD 3.5 MT GT 410 Sport Gasoline 3456 cm³ 416 hp 306 kW 410 N⋅m Manual RWD 3.5 AT GT 410 Gasoline 3456 cm³ 416 hp 306 kW 410 N⋅m Automatic RWD 3.5 AT GT 410 Sport Gasoline 3456 cm³ 416 hp 306 kW 410 N⋅m Automatic RWD
Lotus Evora Dimensions
Coupe — Lotus Evora Dimensions
Coupe Lotus Evora Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
3.5 MT 4361 mm 1972 mm 1229 mm 2575 mm 1382 kg 1782 kg 119 mm 3.5 AT 4361 mm 1972 mm 1229 mm 2575 mm 1436 kg 1782 kg 119 mm 3.5 MT 4361 mm 1972 mm 1229 mm 2575 mm 1382 kg 1782 kg 119 mm 3.5 AT 4361 mm 1972 mm 1229 mm 2575 mm 1442 kg 1782 kg 119 mm 3.5 MT 4361 mm 1972 mm 1229 mm 2575 mm 1436 kg Not provided 119 mm 3.5 AT 4361 mm 1972 mm 1229 mm 2575 mm 1442 kg Not provided 119 mm 3.5 MT 4361 mm 1972 mm 1229 mm 2575 mm 1415 kg Not provided 119 mm 3.5 AT 4361 mm 1972 mm 1229 mm 2575 mm 1422 kg Not provided 119 mm 3.5 MT 410 4361 mm 1972 mm 1229 mm 2575 mm 1325 kg Not provided 119 mm 3.5 AT 410 4361 mm 1972 mm 1229 mm 2575 mm 1337 kg Not provided 119 mm 3.5 MT 4361 mm 1972 mm 1229 mm 2575 mm 1299 kg Not provided 119 mm 3.5 MT GT 410 4361 mm 1972 mm 1229 mm 2575 mm 1394 kg Not provided 119 mm 3.5 MT GT 410 Sport 4361 mm 1972 mm 1229 mm 2575 mm 1360 kg Not provided 119 mm 3.5 AT GT 410 4361 mm 1972 mm 1229 mm 2575 mm 1400 kg Not provided 119 mm 3.5 AT GT 410 Sport 4361 mm 1972 mm 1229 mm 2575 mm 1333 kg Not provided 119 mm
Lotus Evora Cargo Space
Coupe — Lotus Evora Cargo Space
Lotus Evora Trims and Equipment
A technical version describes the powertrain; an equipment configuration describes what is actually fitted inside. The 3.5 MT GT 410 appears with an Individual configuration, which reflects the brand's bespoke approach: buyers specify seats, materials and finishes themselves rather than picking from fixed Lotus Evora trim levels.
