Geo Spectrum Specs, Engines & Dimensions (1990–1993)

Geo Spectrum Engines and Transmissions

A typical Geo Spectrum engine is a small four-cylinder sized for economy rather than speed. Examples include a 1.6 MT gasoline version with a manual gearbox, a 1.6 AT with an automatic, and a 1.7 AT diesel. Every powertrain here sends drive to the front wheels.

Sedan — Geo Spectrum Engines and Transmissions

Sedan Geo Spectrum Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.5 MT	Gasoline	1471 cm³	100 hp	74 kW	130 N⋅m	Manual	FWD
1.5 AT	Gasoline	1471 cm³	100 hp	74 kW	130 N⋅m	Automatic	FWD
1.5 MT	Gasoline	1471 cm³	120 hp	88 kW	Not provided	Manual	FWD
1.5 AT	Gasoline	1471 cm³	120 hp	88 kW	Not provided	Automatic	FWD
1.6 MT	Gasoline	1588 cm³	95 hp	70 kW	131 N⋅m	Manual	FWD
1.6 AT	Gasoline	1588 cm³	95 hp	70 kW	131 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1809 cm³	140 hp	103 kW	162 N⋅m	Manual	FWD
1.8 AT	Gasoline	1809 cm³	140 hp	103 kW	162 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1809 cm³	142 hp	104 kW	162 N⋅m	Manual	FWD
1.8 AT	Gasoline	1809 cm³	142 hp	104 kW	162 N⋅m	Automatic	FWD
1.7 MT	Diesel	1686 cm³	88 hp	65 kW	167 N⋅m	Manual	FWD
1.7 AT	Diesel	1686 cm³	88 hp	65 kW	167 N⋅m	Automatic	FWD

Geo Spectrum Dimensions

Sedan — Geo Spectrum Dimensions

Sedan Geo Spectrum Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
1.5 MT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.5 AT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.5 MT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.5 AT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.6 MT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.6 AT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.8 MT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.8 AT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.8 MT	4195 mm	1680 mm	1370 mm	2450 mm	1000 kg	145 mm
1.8 AT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.7 MT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm
1.7 AT	4195 mm	1680 mm	1370 mm	2450 mm	Not provided	145 mm

Geo Spectrum Cargo Space

Sedan — Geo Spectrum Cargo Space

Sedan Geo Spectrum Cargo Space
Modification	Trunk volume min
1.5 MT	325 l
1.5 AT	325 l
1.5 MT	325 l
1.5 AT	325 l
1.6 MT	325 l
1.6 AT	325 l
1.8 MT	325 l
1.8 AT	325 l
1.8 MT	325 l
1.8 AT	325 l
1.7 MT	325 l
1.7 AT	325 l
