Catalog / Ford / Mustang / 6 generation
Ford Mustang Engines and Transmissions
Every Ford Mustang engine here is gasoline and sends power to the rear wheels. The 3.7 arrives as 3.7 AT with an automatic, easier in traffic, or 3.7 MT with a manual; the 5.2 MT pairs a high-revving V8 with a manual gearbox for committed drivers.
Coupe — Ford Mustang Engines and Transmissions
Coupe Ford Mustang Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.3 MT Gasoline 2300 cm³ 317 hp 233 kW 432 N⋅m Manual RWD 2.3 AT Gasoline 2300 cm³ 317 hp 233 kW 432 N⋅m Automatic RWD 5.0 MT Gasoline 4951 cm³ 421 hp 310 kW 530 N⋅m Manual RWD 2.3 AT Gasoline 2264 cm³ 309 hp 227 kW 407 N⋅m Automatic RWD 2.3 MT Gasoline 2264 cm³ 309 hp 227 kW 407 N⋅m Manual RWD 3.7 AT Gasoline 3720 cm³ 305 hp 224 kW 366 N⋅m Automatic RWD 3.7 MT Gasoline 3720 cm³ 305 hp 224 kW 366 N⋅m Manual RWD 5.0 AT Gasoline 4951 cm³ 421 hp 310 kW 530 N⋅m Automatic RWD 5.0 MT Gasoline 4951 cm³ 426 hp 313 kW 529 N⋅m Manual RWD 5.0 AT Gasoline 4951 cm³ 426 hp 313 kW 529 N⋅m Automatic RWD 5.2 MT Gasoline 5163 cm³ 526 hp 387 kW 583 N⋅m Manual RWD 5.0 AT Gasoline 4951 cm³ 406 hp 298 kW 529 N⋅m Automatic RWD
Cabrio — Ford Mustang Engines and Transmissions
Cabrio Ford Mustang Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.3 MT Gasoline 2264 cm³ 309 hp 227 kW 407 N⋅m Manual RWD 2.3 MT Gasoline 2300 cm³ 317 hp 233 kW 432 N⋅m Manual RWD 3.7 MT Gasoline 3720 cm³ 305 hp 224 kW 366 N⋅m Manual RWD 5.0 MT Gasoline 4951 cm³ 421 hp 310 kW 530 N⋅m Manual RWD 5.0 AT Gasoline 4951 cm³ 426 hp 313 kW 529 N⋅m Automatic RWD 2.3 AT Gasoline 2264 cm³ 309 hp 227 kW 407 N⋅m Automatic RWD 2.3 AT Gasoline 2300 cm³ 317 hp 233 kW 432 N⋅m Automatic RWD 3.7 AT Gasoline 3720 cm³ 305 hp 224 kW 366 N⋅m Automatic RWD 5.0 AT Gasoline 4951 cm³ 421 hp 310 kW 530 N⋅m Automatic RWD 5.0 MT Gasoline 4951 cm³ 426 hp 313 kW 529 N⋅m Manual RWD
Ford Mustang Dimensions
Coupe — Ford Mustang Dimensions
Coupe Ford Mustang Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.3 MT 4784 mm 1916 mm 1381 mm 2720 mm 1620 kg Not provided 130 mm 2.3 AT 4784 mm 1916 mm 1381 mm 2720 mm 1617 kg Not provided 130 mm 5.0 MT 4784 mm 1916 mm 1381 mm 2720 mm 1651 kg Not provided 130 mm 2.3 AT 4784 mm 1916 mm 1381 mm 2720 mm Not provided Not provided 130 mm 2.3 MT 4784 mm 1916 mm 1381 mm 2720 mm Not provided Not provided 130 mm 3.7 AT 4784 mm 1916 mm 1381 mm 2720 mm 1601 kg 2077 kg 130 mm 3.7 MT 4784 mm 1916 mm 1381 mm 2720 mm 1599 kg Not provided 130 mm 5.0 AT 4784 mm 1916 mm 1381 mm 2720 mm 1659 kg Not provided 130 mm 5.0 MT 4784 mm 1916 mm 1381 mm 2720 mm 1530 kg Not provided 130 mm 5.0 AT 4784 mm 1916 mm 1381 mm 2720 mm 1530 kg Not provided 130 mm 5.2 MT 4784 mm 1916 mm 1381 mm 2720 mm 1707 kg Not provided 130 mm 5.0 AT 4784 mm 1916 mm 1381 mm 2720 mm 1530 kg Not provided 130 mm
Cabrio — Ford Mustang Dimensions
Cabrio Ford Mustang Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.3 MT 4784 mm 1916 mm 1394 mm 2720 mm 1675 kg 130 mm 2.3 MT 4784 mm 1916 mm 1394 mm 2720 mm 1620 kg 130 mm 3.7 MT 4784 mm 1916 mm 1394 mm 2720 mm 1620 kg 130 mm 5.0 MT 4784 mm 1916 mm 1394 mm 2720 mm 1651 kg 130 mm 5.0 AT 4784 mm 1916 mm 1394 mm 2720 mm 1770 kg 130 mm 2.3 AT 4784 mm 1916 mm 1394 mm 2720 mm 1680 kg 130 mm 2.3 AT 4784 mm 1916 mm 1394 mm 2720 mm 1617 kg 130 mm 3.7 AT 4784 mm 1916 mm 1394 mm 2720 mm 1625 kg 130 mm 5.0 AT 4784 mm 1916 mm 1394 mm 2720 mm 1659 kg 130 mm 5.0 MT 4784 mm 1916 mm 1394 mm 2720 mm 1765 kg 130 mm
Ford Mustang Cargo Space
Coupe — Ford Mustang Cargo Space
Cabrio — Ford Mustang Cargo Space
Ford Mustang Trims and Equipment
Ford Mustang trim levels sit on top of a technical version rather than changing it: the 3.7 AT is offered as Base or Premium Coupe. Both share the same powertrain, while the Premium generally concentrates on cabin comfort, trim materials and infotainment equipment. Options often vary between individual cars.
Ford Mustang Trims and Equipment Modification Body Equipment 3.7 AT Coupe Base 3.7 AT Coupe Premium Coupe 3.7 MT Coupe Base 5.0 AT Coupe Premium Coupe 3.7 AT Cabrio Premium
