Citroen Xsara Specs, Engines & Dimensions (1997–2006) — First Generation

The first-generation Citroen Xsara offers three-door and five-door hatchbacks alongside a five-door estate. Your choice depends on how often you carry passengers or bulky luggage, as well as the driving experience you prefer.

← All Citroen models

Citroen Xsara Engines and Transmissions

Choosing a Citroen Xsara engine also means considering the transmission. Estate examples include the gasoline 1.4 MT manual and 1.8 AT automatic, plus the diesel 2.0 AT automatic. A manual gives you direct control over gear selection, while an automatic reduces the effort of driving in stop-start traffic.

Estate 5-door — Citroen Xsara Engines and Transmissions

Estate 5-door Citroen Xsara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1361 cm³	75 hp	55 kW	120 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	88 hp	65 kW	135 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	88 hp	65 kW	135 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Manual	FWD
1.8 MT	Gasoline	1762 cm³	90 hp	66 kW	147 N⋅m	Manual	FWD
1.8 AT	Gasoline	1762 cm³	101 hp	74 kW	153 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1762 cm³	110 hp	81 kW	155 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	132 hp	97 kW	180 N⋅m	Manual	FWD
1.4 MT	Diesel	1399 cm³	68 hp	50 kW	150 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Automatic	FWD
1.9 MT	Diesel	1868 cm³	71 hp	52 kW	125 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Manual	FWD
2.0 AT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Automatic	FWD

Hatchback 3-door — Citroen Xsara Engines and Transmissions

Hatchback 3-door Citroen Xsara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 AT	Gasoline	1587 cm³	88 hp	65 kW	135 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1587 cm³	88 hp	65 kW	135 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Automatic	FWD
1.8 MT	Gasoline	1762 cm³	90 hp	66 kW	147 N⋅m	Manual	FWD
1.8 MT	Gasoline	1762 cm³	110 hp	81 kW	155 N⋅m	Manual	FWD
2.0 MT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Manual	FWD
2.0 AT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Automatic	FWD
2.0 MT	Gasoline	1998 cm³	163 hp	120 kW	193 N⋅m	Manual	FWD
1.4 MT	Diesel	1399 cm³	68 hp	50 kW	150 N⋅m	Manual	FWD
1.9 MT	Diesel	1868 cm³	71 hp	52 kW	125 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Manual	FWD
2.0 AT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Automatic	FWD
1.4 MT	Gasoline	1361 cm³	75 hp	55 kW	120 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD

Hatchback 5-door — Citroen Xsara Engines and Transmissions

Hatchback 5-door Citroen Xsara Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Manual	FWD
1.4 MT	Diesel	1399 cm³	68 hp	50 kW	150 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Manual	FWD
1.8 MT	Gasoline	1762 cm³	90 hp	66 kW	147 N⋅m	Manual	FWD
1.8 MT	Gasoline	1762 cm³	110 hp	81 kW	155 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	132 hp	97 kW	180 N⋅m	Manual	FWD
1.4 MT	Gasoline	1361 cm³	75 hp	55 kW	120 N⋅m	Manual	FWD
1.6 MT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Manual	FWD
2.0 MT	Diesel	1997 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	88 hp	65 kW	135 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1587 cm³	88 hp	65 kW	135 N⋅m	Manual	FWD
1.6 AT	Gasoline	1587 cm³	109 hp	80 kW	147 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1998 cm³	132 hp	97 kW	180 N⋅m	Automatic	FWD
1.9 MT	Diesel	1868 cm³	70 hp	51 kW	125 N⋅m	Manual	FWD
2.0 AT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Automatic	FWD
2.0 AT	Diesel	1997 cm³	109 hp	80 kW	250 N⋅m	Automatic	FWD
2.0 AT	Gasoline	1997 cm³	136 hp	100 kW	190 N⋅m	Automatic	FWD
1.9 MT	Diesel	1905 cm³	90 hp	66 kW	196 N⋅m	Manual	FWD
1.8 AT	Gasoline	1762 cm³	110 hp	81 kW	155 N⋅m	Automatic	FWD

Citroen Xsara Dimensions

Estate 5-door — Citroen Xsara Dimensions

Estate 5-door Citroen Xsara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4369 mm	1705 mm	1420 mm	2540 mm	1162 kg	1682 kg	Not provided
1.6 MT	4369 mm	1705 mm	1420 mm	2540 mm	1050 kg	1650 kg	150 mm
1.6 AT	4369 mm	1705 mm	1420 mm	2540 mm	Not provided	1650 kg	150 mm
1.6 MT	4369 mm	1705 mm	1420 mm	2540 mm	1166 kg	1694 kg	Not provided
1.8 MT	4369 mm	1705 mm	1420 mm	2540 mm	1055 kg	1650 kg	150 mm
1.8 AT	4369 mm	1705 mm	1420 mm	2540 mm	1070 kg	1670 kg	150 mm
1.8 MT	4369 mm	1705 mm	1420 mm	2540 mm	1075 kg	1670 kg	150 mm
2.0 MT	4369 mm	1705 mm	1420 mm	2540 mm	1115 kg	1710 kg	150 mm
1.4 MT	4369 mm	1705 mm	1420 mm	2540 mm	1165 kg	1670 kg	Not provided
1.6 AT	4369 mm	1705 mm	1420 mm	2540 mm	1197 kg	1728 kg	Not provided
1.9 MT	4369 mm	1705 mm	1420 mm	2540 mm	1075 kg	1690 kg	150 mm
2.0 MT	4369 mm	1705 mm	1420 mm	2540 mm	1220 kg	1740 kg	Not provided
2.0 MT	4369 mm	1705 mm	1420 mm	2540 mm	1265 kg	1770 kg	Not provided
2.0 AT	4369 mm	1705 mm	1420 mm	2540 mm	1296 kg	1784 kg	150 mm

Hatchback 3-door — Citroen Xsara Dimensions

Hatchback 3-door Citroen Xsara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1600 kg	150 mm
1.6 MT	4188 mm	1705 mm	1405 mm	2540 mm	1005 kg	1600 kg	150 mm
1.6 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1656 kg	150 mm
1.8 MT	4188 mm	1705 mm	1405 mm	2540 mm	1070 kg	1620 kg	150 mm
1.8 MT	4188 mm	1705 mm	1405 mm	2540 mm	1100 kg	1620 kg	150 mm
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1105 kg	1690 kg	Not provided
2.0 AT	4188 mm	1705 mm	1405 mm	2540 mm	1135 kg	1715 kg	Not provided
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1150 kg	1700 kg	Not provided
1.4 MT	4188 mm	1705 mm	1405 mm	2540 mm	1050 kg	1675 kg	Not provided
1.9 MT	4188 mm	1705 mm	1405 mm	2540 mm	1015 kg	1630 kg	150 mm
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1145 kg	1735 kg	Not provided
2.0 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1725 kg	150 mm
1.4 MT	4188 mm	1705 mm	1405 mm	2540 mm	1045 kg	1665 kg	Not provided
1.6 MT	4188 mm	1705 mm	1405 mm	2540 mm	1070 kg	1665 kg	Not provided
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1135 kg	1725 kg	Not provided

Hatchback 5-door — Citroen Xsara Dimensions

Hatchback 5-door Citroen Xsara Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1105 kg	1690 kg	Not provided
1.4 MT	4188 mm	1705 mm	1405 mm	2540 mm	1050 kg	1675 kg	Not provided
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1145 kg	1735 kg	Not provided
1.8 MT	4188 mm	1705 mm	1405 mm	2540 mm	1020 kg	1600 kg	150 mm
1.8 MT	4188 mm	1705 mm	1405 mm	2540 mm	1115 kg	1630 kg	150 mm
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1180 kg	1690 kg	150 mm
1.4 MT	4188 mm	1705 mm	1405 mm	2540 mm	1045 kg	1665 kg	Not provided
1.6 MT	4188 mm	1705 mm	1405 mm	2540 mm	1070 kg	1665 kg	Not provided
2.0 MT	4188 mm	1705 mm	1405 mm	2540 mm	1135 kg	1725 kg	Not provided
1.6 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1590 kg	150 mm
1.6 MT	4188 mm	1705 mm	1405 mm	2540 mm	1080 kg	1590 kg	150 mm
1.6 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1663 kg	150 mm
2.0 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1690 kg	150 mm
1.9 MT	4188 mm	1705 mm	1405 mm	2540 mm	1090 kg	1697 kg	Not provided
2.0 AT	4188 mm	1705 mm	1405 mm	2540 mm	Not provided	1725 kg	150 mm
2.0 AT	4188 mm	1705 mm	1405 mm	2540 mm	1247 kg	1810 kg	Not provided
2.0 AT	4188 mm	1705 mm	1405 mm	2540 mm	1135 kg	1715 kg	Not provided
1.9 MT	4188 mm	1705 mm	1405 mm	2540 mm	1127 kg	1690 kg	Not provided
1.8 AT	4188 mm	1705 mm	1405 mm	2540 mm	1110 kg	1630 kg	150 mm

Citroen Xsara Cargo Space

Estate 5-door — Citroen Xsara Cargo Space

Estate 5-door Citroen Xsara Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	517 l	1512 l
1.6 MT	517 l	1512 l
1.6 AT	517 l	1512 l
1.6 MT	517 l	1512 l
1.8 MT	517 l	1512 l
1.8 AT	517 l	1512 l
1.8 MT	517 l	1512 l
2.0 MT	517 l	1512 l
1.4 MT	517 l	1512 l
1.6 AT	517 l	1512 l
1.9 MT	517 l	1512 l
2.0 MT	517 l	1512 l
2.0 MT	517 l	1512 l
2.0 AT	517 l	1512 l

Hatchback 3-door — Citroen Xsara Cargo Space

Hatchback 3-door Citroen Xsara Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 AT	408 l	1190 l
1.6 MT	408 l	1190 l
1.6 AT	408 l	1190 l
1.8 MT	408 l	1190 l
1.8 MT	408 l	1190 l
2.0 MT	408 l	1190 l
2.0 AT	408 l	1190 l
2.0 MT	408 l	1190 l
1.4 MT	408 l	1190 l
1.9 MT	408 l	1190 l
2.0 MT	408 l	1190 l
2.0 AT	408 l	1190 l
1.4 MT	408 l	1190 l
1.6 MT	408 l	1190 l
2.0 MT	408 l	1190 l

Hatchback 5-door — Citroen Xsara Cargo Space

Hatchback 5-door Citroen Xsara Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 MT	408 l	1190 l
1.4 MT	408 l	1190 l
2.0 MT	408 l	1190 l
1.8 MT	408 l	1190 l
1.8 MT	408 l	1190 l
2.0 MT	408 l	1190 l
1.4 MT	408 l	1190 l
1.6 MT	408 l	1190 l
2.0 MT	408 l	1190 l
1.6 AT	408 l	1190 l
1.6 MT	408 l	1190 l
1.6 AT	408 l	1190 l
2.0 AT	408 l	1190 l
1.9 MT	408 l	1190 l
2.0 AT	408 l	1190 l
2.0 AT	408 l	1190 l
2.0 AT	408 l	1190 l
1.9 MT	408 l	1190 l
1.8 AT	408 l	1190 l
