Catalog / Cadillac / ATS / 1 generation, restyling
Cadillac ATS Engines and Transmissions
Among Cadillac ATS engine and transmission choices, Coupe examples include gasoline 2.0 AT versions with rear-wheel or all-wheel drive, plus a rear-wheel-drive 2.0 MT. The automatic eases stop-start driving, while the manual gives you control over gear changes. All-wheel drive can improve traction under power on slippery roads.
Coupe — Cadillac ATS Engines and Transmissions
Coupe Cadillac ATS Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 AT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Automatic RWD 2.0 MT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Manual RWD 2.0 AT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Automatic AWD 3.6 AT Gasoline 3564 cm³ 325 hp 239 kW 371 N⋅m Automatic RWD 3.6 AT Gasoline 3564 cm³ 325 hp 239 kW 371 N⋅m Automatic AWD
Sedan — Cadillac ATS Engines and Transmissions
Sedan Cadillac ATS Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 AT Gasoline 1998 cm³ 226 hp 166 kW 350 N⋅m Automatic RWD 2.0 AT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Automatic AWD 2.0 AT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Automatic RWD 2.0 MT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Manual RWD 2.5 AT Gasoline 2499 cm³ 202 hp 149 kW 258 N⋅m Automatic RWD 3.6 AT Gasoline 3564 cm³ 325 hp 239 kW 371 N⋅m Automatic AWD 3.6 AT Gasoline 3564 cm³ 325 hp 239 kW 371 N⋅m Automatic RWD 3.6 AT Gasoline 3564 cm³ 340 hp 250 kW 386 N⋅m Automatic RWD 3.6 AT Gasoline 3564 cm³ 340 hp 250 kW 386 N⋅m Automatic AWD 2.0 AT Gasoline 1998 cm³ 276 hp 203 kW 353 N⋅m Automatic RWD
Cadillac ATS Dimensions
Coupe — Cadillac ATS Dimensions
Coupe Cadillac ATS Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 AT 4663 mm 1841 mm 1392 mm 2775 mm 1550 kg 2050 kg 145 mm 2.0 MT 4663 mm 1841 mm 1392 mm 2775 mm 1550 kg 2050 kg 145 mm 2.0 AT 4663 mm 1841 mm 1392 mm 2775 mm Not provided 2050 kg 145 mm 3.6 AT 4663 mm 1841 mm 1392 mm 2775 mm 1550 kg 2050 kg 145 mm 3.6 AT 4663 mm 1841 mm 1392 mm 2775 mm Not provided 2050 kg 145 mm
Sedan — Cadillac ATS Dimensions
Sedan Cadillac ATS Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 AT 4643 mm 1806 mm 1421 mm 2775 mm 1530 kg 2050 kg 145 mm 2.0 AT 4643 mm 1806 mm 1421 mm 2775 mm 1607 kg 2110 kg 145 mm 2.0 AT 4643 mm 1806 mm 1421 mm 2775 mm 1530 kg 2050 kg 145 mm 2.0 MT 4643 mm 1806 mm 1421 mm 2775 mm 1543 kg 2050 kg 145 mm 2.5 AT 4643 mm 1806 mm 1421 mm 2775 mm 1543 kg 2050 kg 145 mm 3.6 AT 4643 mm 1806 mm 1421 mm 2775 mm 1543 kg 2050 kg 145 mm 3.6 AT 4643 mm 1806 mm 1421 mm 2775 mm 1543 kg 2050 kg 145 mm 3.6 AT 4643 mm 1806 mm 1421 mm 2775 mm Not provided Not provided 145 mm 3.6 AT 4643 mm 1806 mm 1421 mm 2775 mm Not provided Not provided 145 mm 2.0 AT 4643 mm 1806 mm 1421 mm 2775 mm 1550 kg 2050 kg 145 mm
Cadillac ATS Cargo Space
Coupe — Cadillac ATS Cargo Space
Sedan — Cadillac ATS Cargo Space
Cadillac ATS Trims and Equipment
Cadillac ATS Trims and Equipment Modification Body Equipment 2.0 AT Sedan Luxury 2.0 AT Sedan Performance 2.0 AT Sedan Standard 2.0 AT Sedan Luxury 2.0 AT Sedan Premium
