BMW Z4 Engines and Transmissions
BMW Z4 engine choices focus on smooth, naturally aspirated gasoline units. The 3.0-liter inline-six powers coupe versions with either an engaging 3.0 MT manual or a convenient automatic, delivering characterful performance and flexible everyday response.
Coupe — BMW Z4 Engines and Transmissions
Coupe BMW Z4 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 3.0 MT Gasoline 2996 cm³ 265 hp 195 kW 315 N⋅m Manual RWD 3.0 AT Gasoline 2996 cm³ 265 hp 195 kW 315 N⋅m Automatic RWD
Roadster — BMW Z4 Engines and Transmissions
Roadster BMW Z4 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1995 cm³ 150 hp 110 kW 200 N⋅m Manual RWD 2.5 MT Gasoline 2497 cm³ 177 hp 130 kW 230 N⋅m Manual RWD 2.2 AT Gasoline 2171 cm³ 170 hp 125 kW 210 N⋅m Automatic RWD 2.2 MT Gasoline 2171 cm³ 170 hp 125 kW 210 N⋅m Manual RWD 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 245 N⋅m Automatic RWD 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 245 N⋅m Manual RWD 2.5 MT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Manual RWD 3.0 MT Gasoline 2979 cm³ 231 hp 170 kW 300 N⋅m Manual RWD 3.0 MT Gasoline 2996 cm³ 265 hp 195 kW 315 N⋅m Manual RWD 2.5 AT Gasoline 2497 cm³ 218 hp 160 kW 250 N⋅m Automatic RWD 3.0 AT Gasoline 2979 cm³ 231 hp 170 kW 300 N⋅m Automatic RWD 3.0 AT Gasoline 2996 cm³ 265 hp 195 kW 315 N⋅m Automatic RWD 2.5 AT Gasoline 2497 cm³ 177 hp 130 kW 230 N⋅m Automatic RWD 3.0 AT Gasoline 2996 cm³ 215 hp 158 kW Not provided Automatic RWD 3.2 MT Gasoline 3246 cm³ 215 hp 158 kW 365 N⋅m Manual RWD
BMW Z4 Dimensions
Coupe — BMW Z4 Dimensions
Coupe BMW Z4 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 3.0 MT 4091 mm 1781 mm 1268 mm 2497 mm 1325 kg 1650 kg 123 mm 3.0 AT 4091 mm 1781 mm 1268 mm 2497 mm 1325 kg 1650 kg 110 mm
Roadster — BMW Z4 Dimensions
Roadster BMW Z4 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4091 mm 1781 mm 1299 mm 2495 mm 1225 kg 1520 kg 123 mm 2.5 MT 4091 mm 1781 mm 1299 mm 2495 mm 1275 kg 1570 kg 123 mm 2.2 AT 4091 mm 1781 mm 1299 mm 2495 mm Not provided 1550 kg 110 mm 2.2 MT 4091 mm 1781 mm 1299 mm 2495 mm 1325 kg 1550 kg 110 mm 2.5 AT 4091 mm 1781 mm 1299 mm 2495 mm Not provided 1560 kg 110 mm 2.5 MT 4091 mm 1781 mm 1299 mm 2495 mm 1335 kg 1560 kg 110 mm 2.5 MT 4091 mm 1781 mm 1299 mm 2495 mm 1290 kg 1585 kg 108 mm 3.0 MT 4091 mm 1781 mm 1299 mm 2495 mm 1365 kg 1590 kg 110 mm 3.0 MT 4091 mm 1781 mm 1299 mm 2495 mm 1315 kg 1610 kg 123 mm 2.5 AT 4091 mm 1781 mm 1299 mm 2495 mm 1325 kg 1620 kg 108 mm 3.0 AT 4091 mm 1781 mm 1299 mm 2495 mm Not provided 1590 kg 110 mm 3.0 AT 4091 mm 1781 mm 1299 mm 2495 mm 1345 kg 1640 kg 108 mm 2.5 AT 4091 mm 1781 mm 1299 mm 2495 mm 1275 kg 1570 kg 123 mm 3.0 AT 4091 mm 1781 mm 1299 mm 2495 mm Not provided Not provided 110 mm 3.2 MT 4091 mm 1781 mm 1299 mm 2495 mm 1485 kg 1705 kg 110 mm
BMW Z4 Cargo Space
Coupe — BMW Z4 Cargo Space
Coupe BMW Z4 Cargo Space Modification Trunk volume min 3.0 MT 340 l 3.0 AT 340 l
Roadster — BMW Z4 Cargo Space
BMW Z4 Trims and Equipment
BMW Z4 trim levels keep equipment straightforward. The 3.0 coupe, for example, offers a focused set of features aimed at driving enjoyment rather than overwhelming luxury, ensuring the roadster or coupe remains accessible and practical for real-world use.
BMW Z4 Trims and Equipment Modification Body Equipment 3.0 MT Coupe 3.0 2.0 MT Roadster 2.0 2.5 MT Roadster 02.may 3.0 MT Roadster 3.0
