Catalog / BMW / 5 series / 3 generation
BMW 5 Series Engines and Transmissions
BMW 5 Series engine options cover both gasoline and diesel, matched with manual or automatic transmissions. For example, the 518i 1.8 AT uses a gasoline powertrain with an automatic gearbox and rear-wheel drive, while the 524td 2.4 MT pairs a diesel engine with a manual and rear-wheel drive. The 525ix 2.5 MT brings all-wheel drive to the Estate body for added traction.
Estate 5-door — BMW 5 Series Engines and Transmissions
Estate 5-door BMW 5 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 518i 1.8 MT Gasoline 1796 cm³ 113 hp 85 kW 162 N⋅m Manual RWD 518i 1.8 MT Gasoline 1796 cm³ 115 hp 85 kW 168 N⋅m Manual RWD 518i 1.8 AT Gasoline 1796 cm³ 115 hp 85 kW 168 N⋅m Automatic RWD 520i 2.0 MT Gasoline 1991 cm³ 150 hp 110 kW 190 N⋅m Manual RWD 525i 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Manual RWD 525ix 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Manual AWD 525i 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Automatic RWD 525ix 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Automatic AWD 530i 3.0 AT Gasoline 2997 cm³ 218 hp 160 kW 290 N⋅m Automatic RWD 530i 3.0 MT Gasoline 2997 cm³ 218 hp 160 kW 290 N⋅m Manual RWD 540i 4.0 MT Gasoline 3982 cm³ 286 hp 210 kW 400 N⋅m Manual RWD 540i 4.0 AT Gasoline 3982 cm³ 286 hp 210 kW 400 N⋅m Automatic RWD 525td 2.5 MT Diesel 2498 cm³ 115 hp 85 kW 222 N⋅m Manual RWD 525td 2.5 AT Diesel 2498 cm³ 115 hp 85 kW 222 N⋅m Automatic RWD 525td 2.5 AT Diesel 2498 cm³ 143 hp 105 kW 260 N⋅m Automatic RWD 525td 2.5 MT Diesel 2498 cm³ 143 hp 105 kW 260 N⋅m Manual RWD 520i 2.0 AT Gasoline 1991 cm³ 150 hp 110 kW 190 N⋅m Automatic RWD
Sedan — BMW 5 Series Engines and Transmissions
Sedan BMW 5 Series Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 518i 1.8 MT Gasoline 1796 cm³ 113 hp 85 kW 161 N⋅m Manual RWD 518i 1.8 AT Gasoline 1796 cm³ 115 hp 85 kW 168 N⋅m Automatic RWD 518i 1.8 MT Gasoline 1796 cm³ 115 hp 85 kW 168 N⋅m Manual RWD 520i 2.0 AT Gasoline 1991 cm³ 129 hp 95 kW 162 N⋅m Automatic RWD 520i 2.0 MT Gasoline 1991 cm³ 129 hp 95 kW 162 N⋅m Manual RWD 520i 2.0 AT Gasoline 1991 cm³ 150 hp 110 kW 190 N⋅m Automatic RWD 520i 2.0 MT Gasoline 1991 cm³ 150 hp 110 kW 190 N⋅m Manual RWD 525i 2.5 AT Gasoline 2494 cm³ 170 hp 125 kW 222 N⋅m Automatic RWD 525i 2.5 MT Gasoline 2494 cm³ 170 hp 125 kW 222 N⋅m Manual RWD 525ix 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Manual AWD 525ix 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Automatic AWD 530i 3.0 AT Gasoline 2986 cm³ 188 hp 138 kW 260 N⋅m Automatic RWD 530i 3.0 MT Gasoline 2986 cm³ 188 hp 138 kW 260 N⋅m Manual RWD 530i 3.0 MT Gasoline 2997 cm³ 218 hp 160 kW 290 N⋅m Manual RWD 535i 3.4 AT Gasoline 3430 cm³ 211 hp 155 kW 305 N⋅m Automatic RWD 540i 4.0 AT Gasoline 3982 cm³ 286 hp 210 kW 400 N⋅m Automatic RWD 540i 4.0 MT Gasoline 3982 cm³ 286 hp 210 kW 400 N⋅m Manual RWD 524td 2.4 MT Diesel 2443 cm³ 115 hp 85 kW 220 N⋅m Manual RWD 524td 2.4 AT Diesel 2443 cm³ 115 hp 85 kW 220 N⋅m Automatic RWD 525td 2.5 MT Diesel 2498 cm³ 115 hp 85 kW 222 N⋅m Manual RWD 525td 2.5 AT Diesel 2498 cm³ 115 hp 85 kW 222 N⋅m Automatic RWD 525td 2.5 AT Diesel 2498 cm³ 143 hp 105 kW 260 N⋅m Automatic RWD 525td 2.5 MT Diesel 2498 cm³ 143 hp 105 kW 260 N⋅m Manual RWD 525i 2.5 AT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Automatic RWD 525i 2.5 MT Gasoline 2494 cm³ 192 hp 141 kW 250 N⋅m Manual RWD 530i 3.0 AT Gasoline 2997 cm³ 218 hp 160 kW 290 N⋅m Automatic RWD 535i 3.4 MT Gasoline 3430 cm³ 211 hp 155 kW 305 N⋅m Manual RWD
BMW 5 Series Dimensions
Estate 5-door — BMW 5 Series Dimensions
Estate 5-door BMW 5 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 518i 1.8 MT 4719 mm 1750 mm 1417 mm 2761 mm 1445 kg 2015 kg 120 mm 518i 1.8 MT 4719 mm 1750 mm 1417 mm 2761 mm 1420 kg 2015 kg 120 mm 518i 1.8 AT 4719 mm 1750 mm 1417 mm 2761 mm 1445 kg 2015 kg 120 mm 520i 2.0 MT 4719 mm 1750 mm 1417 mm 2761 mm 1530 kg 2100 kg 120 mm 525i 2.5 MT 4719 mm 1750 mm 1417 mm 2761 mm 1575 kg 2125 kg 120 mm 525ix 2.5 MT 4719 mm 1750 mm 1417 mm 2761 mm 1650 kg 2200 kg 120 mm 525i 2.5 AT 4719 mm 1750 mm 1417 mm 2761 mm 1575 kg 2125 kg 120 mm 525ix 2.5 AT 4719 mm 1750 mm 1417 mm 2761 mm 1685 kg 2235 kg 120 mm 530i 3.0 AT 4719 mm 1750 mm 1417 mm 2761 mm 1630 kg 2180 kg 120 mm 530i 3.0 MT 4719 mm 1750 mm 1417 mm 2761 mm 1630 kg 2180 kg 120 mm 540i 4.0 MT 4719 mm 1750 mm 1417 mm 2761 mm 1650 kg 2230 kg 120 mm 540i 4.0 AT 4719 mm 1750 mm 1417 mm 2761 mm 1680 kg 2230 kg 120 mm 525td 2.5 MT 4719 mm 1750 mm 1417 mm 2761 mm 1575 kg 2095 kg 120 mm 525td 2.5 AT 4719 mm 1750 mm 1417 mm 2761 mm 1575 kg 2095 kg 120 mm 525td 2.5 AT 4719 mm 1750 mm 1417 mm 2761 mm 1590 kg 2110 kg 120 mm 525td 2.5 MT 4719 mm 1750 mm 1417 mm 2761 mm 1590 kg 2110 kg 120 mm 520i 2.0 AT 4719 mm 1750 mm 1417 mm 2761 mm 1530 kg 2100 kg 120 mm
Sedan — BMW 5 Series Dimensions
Sedan BMW 5 Series Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 518i 1.8 MT 4720 mm 1751 mm 1412 mm 2761 mm 1360 kg 1870 kg 120 mm 518i 1.8 AT 4720 mm 1751 mm 1412 mm 2761 mm 1390 kg 1870 kg 120 mm 518i 1.8 MT 4720 mm 1751 mm 1412 mm 2761 mm 1360 kg 1870 kg 120 mm 520i 2.0 AT 4720 mm 1751 mm 1412 mm 2761 mm 1400 kg 1910 kg 120 mm 520i 2.0 MT 4720 mm 1751 mm 1412 mm 2761 mm 1400 kg 1910 kg 120 mm 520i 2.0 AT 4720 mm 1751 mm 1412 mm 2761 mm 1445 kg 1955 kg 120 mm 520i 2.0 MT 4720 mm 1751 mm 1412 mm 2761 mm 1445 kg 1955 kg 120 mm 525i 2.5 AT 4720 mm 1751 mm 1412 mm 2761 mm 1450 kg 1960 kg 120 mm 525i 2.5 MT 4720 mm 1751 mm 1412 mm 2761 mm 1450 kg 1960 kg 120 mm 525ix 2.5 MT 4720 mm 1751 mm 1412 mm 2761 mm 1570 kg 2080 kg 120 mm 525ix 2.5 AT 4720 mm 1751 mm 1412 mm 2761 mm 1605 kg 2115 kg 120 mm 530i 3.0 AT 4720 mm 1751 mm 1412 mm 2761 mm 1530 kg 2040 kg 120 mm 530i 3.0 MT 4720 mm 1751 mm 1412 mm 2761 mm 1510 kg 2020 kg 120 mm 530i 3.0 MT 4720 mm 1751 mm 1412 mm 2761 mm 1565 kg 2075 kg 120 mm 535i 3.4 AT 4720 mm 1751 mm 1412 mm 2761 mm 1545 kg 2055 kg 120 mm 540i 4.0 AT 4720 mm 1751 mm 1412 mm 2761 mm 1605 kg 2115 kg 120 mm 540i 4.0 MT 4720 mm 1751 mm 1412 mm 2761 mm 1605 kg 2115 kg 120 mm 524td 2.4 MT 4720 mm 1751 mm 1412 mm 2761 mm 1480 kg 1990 kg 120 mm 524td 2.4 AT 4720 mm 1751 mm 1412 mm 2761 mm 1480 kg 1990 kg 120 mm 525td 2.5 MT 4720 mm 1751 mm 1412 mm 2761 mm 1498 kg 1975 kg 120 mm 525td 2.5 AT 4720 mm 1751 mm 1412 mm 2761 mm 1498 kg 1975 kg 120 mm 525td 2.5 AT 4720 mm 1751 mm 1412 mm 2761 mm 1513 kg 1990 kg 120 mm 525td 2.5 MT 4720 mm 1751 mm 1412 mm 2761 mm 1513 kg 1990 kg 120 mm 525i 2.5 AT 4720 mm 1751 mm 1412 mm 2761 mm 1500 kg 2025 kg 120 mm 525i 2.5 MT 4720 mm 1751 mm 1412 mm 2761 mm 1475 kg 1985 kg 120 mm 530i 3.0 AT 4720 mm 1751 mm 1412 mm 2761 mm 1565 kg 2075 kg 120 mm 535i 3.4 MT 4720 mm 1751 mm 1412 mm 2761 mm 1600 kg 2035 kg 120 mm
BMW 5 Series Cargo Space
Estate 5-door — BMW 5 Series Cargo Space
Sedan — BMW 5 Series Cargo Space
BMW 5 Series Trims and Equipment
