Audi TT Specs, Engines & Dimensions (from 2018) — Third Generation Restyling

The restyled third-generation Audi TT keeps its compact sports-car character in Coupe and Roadster form, pairing turbocharged four-cylinder power with a tightly packaged cabin and the low, wide stance the nameplate has carried since the beginning.

← All Audi models

9 modificationsAll supplied years

Audi TT Engines and Transmissions

Every Audi TT engine here is a turbocharged 2.0-litre petrol four, differing in tune and drivetrain. The 2.0 MT gives front-wheel drive with a manual gearbox, the 2.0 S-tronic swaps in a dual-clutch automatic, and the 45 TFSI quattro S-tronic adds all-wheel-drive traction for quicker, surer starts.

Coupe — Audi TT Engines and Transmissions

Coupe Audi TT Engines and Transmissions
ModificationEngine typeEngine capacityMaximum powerMaximum power, kwMaximum torque N⋅mTransmissionType of drive
2.0 MTGasoline1984 cm³245 hp180 kW370 N⋅mManualFWD
2.0 S-tronicGasoline1984 cm³245 hp180 kW370 N⋅mRoboticFWD
40 TFSI S-tronicGasoline1984 cm³197 hp145 kW326 N⋅mRoboticFWD
45 TFSI quattro S-tronicGasoline1984 cm³245 hp180 kW377 N⋅mRoboticAWD
40 TFSI S-tronicGasoline1984 cm³197 hp145 kW326 N⋅mRoboticFWD

Roadster — Audi TT Engines and Transmissions

Roadster Audi TT Engines and Transmissions
ModificationEngine typeEngine capacityMaximum powerMaximum power, kwMaximum torque N⋅mTransmissionType of drive
2.0 MTGasoline1984 cm³245 hp180 kW370 N⋅mManualFWD
2.0 S-tronicGasoline1984 cm³245 hp180 kW370 N⋅mRoboticFWD
40 TFSI S-tronicGasoline1984 cm³197 hp145 kW326 N⋅mRoboticFWD
2.0 S-tronicGasoline1984 cm³245 hp180 kW370 N⋅mRoboticAWD

Audi TT Dimensions

Coupe — Audi TT Dimensions

Coupe Audi TT Dimensions
ModificationLengthWidthHeightWheelbaseCurb weightMax weightGround clearance, minimum
2.0 MT4177 mm1832 mm1330 mm2501 mm1250 kg1685 kgNot provided
2.0 S-tronic4177 mm1832 mm1330 mm2501 mm1285 kg1720 kgNot provided
40 TFSI S-tronic4177 mm1832 mm1330 mm2501 mm1345 kg1705 kg120 mm
45 TFSI quattro S-tronic4177 mm1832 mm1330 mm2501 mm1440 kg1800 kg120 mm
40 TFSI S-tronic4177 mm1832 mm1330 mm2501 mm1435 kg1715 kg120 mm

Roadster — Audi TT Dimensions

Roadster Audi TT Dimensions
ModificationLengthWidthHeightWheelbaseCurb weightMax weightGround clearance, minimum
2.0 MT4191 mm1832 mm1355 mm2505 mm1340 kg1695 kgNot provided
2.0 S-tronic4191 mm1832 mm1355 mm2505 mm1375 kg1730 kgNot provided
40 TFSI S-tronic4191 mm1832 mm1355 mm2505 mm1435 kg1715 kg120 mm
2.0 S-tronic4191 mm1832 mm1355 mm2505 mm1455 kg1810 kgNot provided

Audi TT Cargo Space

Coupe — Audi TT Cargo Space

Coupe Audi TT Cargo Space
ModificationTrunk volume minTrunk volume max
2.0 MT305 l712 l
2.0 S-tronic305 l712 l
40 TFSI S-tronic305 l712 l
45 TFSI quattro S-tronic305 l712 l
40 TFSI S-tronic305 l712 l

Roadster — Audi TT Cargo Space

Roadster Audi TT Cargo Space
ModificationTrunk volume min
2.0 MT280 l
2.0 S-tronic280 l
40 TFSI S-tronic280 l
2.0 S-tronic280 l

Audi TT Trims and Equipment

Audi TT trim levels sit on top of the mechanical version rather than changing it. The 45 TFSI quattro S-tronic, for instance, appears as TT Coupe 45 TFSI and as Design, so the same powertrain can arrive with different wheels, cabin materials and comfort or assistance equipment.

Audi TT Trims and Equipment
ModificationBodyEquipment
40 TFSI S-tronicCoupeTT Coupe 40 TFSI
40 TFSI S-tronicCoupeDesign
45 TFSI quattro S-tronicCoupeTT Coupe 45 TFSI
45 TFSI quattro S-tronicCoupeDesign
2.0 S-tronicRoadsterDesign Roadster
