Audi S5 Specs, Engines & Dimensions (2016–2019)

Audi S5 Engines and Transmissions

The Audi S5 engine pairs a 3.0-liter V6 with an eight-speed automatic and quattro all-wheel drive. Buyers could choose gasoline or diesel in the Coupe, while the Liftback offered diesel. Every powertrain aims for brisk acceleration and smooth cruising.

Coupe — Audi S5 Engines and Transmissions

Coupe Audi S5 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Diesel	2967 cm³	347 hp	255 kW	700 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2995 cm³	354 hp	260 kW	500 N⋅m	Automatic	AWD

Liftback — Audi S5 Engines and Transmissions

Liftback Audi S5 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Diesel	2967 cm³	347 hp	255 kW	700 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2995 cm³	354 hp	260 kW	500 N⋅m	Automatic	AWD

Cabrio — Audi S5 Engines and Transmissions

Cabrio Audi S5 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Gasoline	2995 cm³	354 hp	260 kW	500 N⋅m	Automatic	AWD

Audi S5 Dimensions

Coupe — Audi S5 Dimensions

Coupe Audi S5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.0 AT	4692 mm	1846 mm	1368 mm	2765 mm	1760 kg	2270 kg	Not provided
3.0 AT	4692 mm	1846 mm	1368 mm	2765 mm	1615 kg	2115 kg	140 mm

Liftback — Audi S5 Dimensions

Liftback Audi S5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.0 AT	4752 mm	1843 mm	1384 mm	2825 mm	1795 kg	2380 kg	Not provided
3.0 AT	4752 mm	1843 mm	1384 mm	2825 mm	1660 kg	2230 kg	140 mm

Cabrio — Audi S5 Dimensions

Cabrio Audi S5 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.0 AT	4692 mm	1846 mm	1382 mm	2765 mm	1840 kg	2340 kg	140 mm

Audi S5 Cargo Space

Coupe — Audi S5 Cargo Space

Coupe Audi S5 Cargo Space
Modification	Trunk volume min
3.0 AT	465 l
3.0 AT	465 l

Liftback — Audi S5 Cargo Space

Liftback Audi S5 Cargo Space
Modification	Trunk volume min	Trunk volume max
3.0 AT	480 l	1300 l
3.0 AT	480 l	1300 l

Cabrio — Audi S5 Cargo Space

Cabrio Audi S5 Cargo Space
Modification	Trunk volume min
3.0 AT	380 l

Audi S5 Trims and Equipment

Audi S5 trim levels add comfort and technology on top of the performance base. For example, the gasoline Coupe came in TFSI quattro tiptronic and Basis configurations. Even the entry trim includes premium materials, while higher grades bring enhanced features.

Audi S5 Trims and Equipment
Modification	Body	Equipment
3.0 AT	Coupe	TFSI quattro tiptronic
3.0 AT	Coupe	Basis
3.0 AT	Coupe	Luxury
3.0 AT	Liftback	TFSI quattro tiptronic
3.0 AT	Liftback	Basis
3.0 AT	Liftback	Luxury
