Volvo V90 Specs, Engines & Dimensions (from 2020)

Volvo V90 Engines and Transmissions

Volvo V90 engine choices include the 2.0 D3 MT, a front-wheel-drive diesel manual suited to regular long journeys. The front-wheel-drive petrol 2.0 T5 MHEV Automatic provides mild-hybrid assistance without plugging in, while the 2.0 T5 Plug-in Hybrid AWD AT combines an automatic transmission and all-wheel drive with electric driving capability that rewards regular charging. These are selected examples of the range.

Estate 5-door — Volvo V90 Engines and Transmissions

Estate 5-door Volvo V90 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 D3 MT	Diesel	1969 cm³	150 hp	110 kW	320 N⋅m	Manual	FWD
2.0 D3 AT	Diesel	1969 cm³	150 hp	110 kW	320 N⋅m	Automatic	FWD
2.0 D3 AT AWD	Diesel	1969 cm³	150 hp	110 kW	320 N⋅m	Automatic	AWD
2.0 D4 MT	Diesel	1969 cm³	190 hp	139 kW	400 N⋅m	Manual	FWD
2.0 D4 AT	Diesel	1969 cm³	190 hp	139 kW	400 N⋅m	Automatic	FWD
2.0 T5 MHEV Automatic	Gasoline	1969 cm³	250 hp	183 kW	350 N⋅m	Automatic	FWD
2.0 D5 AT AWD	Diesel	1969 cm³	235 hp	172 kW	480 N⋅m	Automatic	AWD
2.0 T5 Plug-in Hybrid AWD AT	Plug-in	1969 cm³	253 hp	186 kW	350 N⋅m	Automatic	AWD

Volvo V90 Dimensions

Estate 5-door — Volvo V90 Dimensions

Estate 5-door Volvo V90 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 D3 MT	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 D3 AT	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 D3 AT AWD	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 D4 MT	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 D4 AT	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 T5 MHEV Automatic	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 D5 AT AWD	4945 mm	1879 mm	1478 mm	2941 mm	Not provided	Not provided	156 mm
2.0 T5 Plug-in Hybrid AWD AT	4945 mm	1879 mm	1478 mm	2941 mm	2000 kg	2590 kg	156 mm

Volvo V90 Cargo Space

Estate 5-door — Volvo V90 Cargo Space

Estate 5-door Volvo V90 Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 D3 MT	560 l	1526 l
2.0 D3 AT	560 l	1526 l
2.0 D3 AT AWD	560 l	1526 l
2.0 D4 MT	560 l	1526 l
2.0 D4 AT	560 l	1526 l
2.0 T5 MHEV Automatic	560 l	1526 l
2.0 D5 AT AWD	560 l	1526 l
2.0 T5 Plug-in Hybrid AWD AT	560 l	1526 l
