Volkswagen Tiguan Specs, Engines & Dimensions

Volkswagen Tiguan Engines and Transmissions

Every Volkswagen Tiguan engine in this generation is turbocharged and paired with a DSG robotic dual-clutch gearbox, which shifts by itself but responds more directly than a traditional torque-converter automatic. The 2.0 DSG gasoline versions are offered with front-wheel drive or all-wheel drive, the latter useful on wet roads and light gravel. The 1.5 DSG plug-in hybrid drives the front wheels and adds electric assistance for quiet town running.

SUV 5-doors — Volkswagen Tiguan Engines and Transmissions

SUV 5-doors Volkswagen Tiguan Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 DSG	Gasoline	Not provided	265 hp	194 kW	Not provided	Robotic	FWD
1.5 DSG	Plug-in	Not provided	204 hp	150 kW	Not provided	Robotic	FWD
1.5 DSG	Gasoline	1498 cm³	150 hp	110 kW	250 N⋅m	Robotic	FWD
2.0 DSG	Gasoline	1984 cm³	204 hp	150 kW	320 N⋅m	Robotic	AWD

Volkswagen Tiguan Dimensions

SUV 5-doors — Volkswagen Tiguan Dimensions

SUV 5-doors Volkswagen Tiguan Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 DSG	4539 mm	1842 mm	1639 mm	2680 mm	Not provided	Not provided	Not provided
1.5 DSG	4539 mm	1842 mm	1639 mm	2680 mm	Not provided	Not provided	Not provided
1.5 DSG	4539 mm	1842 mm	1639 mm	2680 mm	1616 kg	2180 kg	190 mm
2.0 DSG	4539 mm	1842 mm	1639 mm	2680 mm	1644 kg	2220 kg	Not provided

Volkswagen Tiguan Cargo Space

SUV 5-doors — Volkswagen Tiguan Cargo Space

SUV 5-doors Volkswagen Tiguan Cargo Space
Modification	Trunk volume min	Trunk volume max
2.0 DSG	652 l	1652 l
1.5 DSG	652 l	1652 l
1.5 DSG	652 l	1652 l
2.0 DSG	652 l	1652 l

Volkswagen Tiguan Trims and Equipment

Volkswagen Tiguan trim levels mainly change the cabin, styling and convenience content rather than the mechanical package underneath. On the 1.5 DSG gasoline front-wheel-drive version you can choose between Life and R-Line: Life covers the comfort-focused everyday specification, while R-Line leans toward sportier exterior and interior detailing. Always read the equipment list of the individual car, because content varies by market and production year.

Volkswagen Tiguan Trims and Equipment
Modification	Body	Equipment
1.5 DSG	SUV 5-doors	Life
1.5 DSG	SUV 5-doors	R-Line
1.5 DSG	SUV 5-doors	R-Line Plus
1.5 DSG	SUV 5-doors	Elegance
2.0 DSG	SUV 5-doors	Elegance

Volkswagen Tiguan Battery

Only the hybrid carries a traction battery. Volkswagen Tiguan battery capacity on the 1.5 DSG plug-in hybrid front-wheel-drive version comes from a lithium-ion pack, which stores energy from a wall socket and from braking, then lets the SUV cover shorter trips on electricity alone. The gasoline versions have no such pack, so their running costs depend entirely on the combustion engine and how you drive.

SUV 5-doors — Volkswagen Tiguan Battery

SUV 5-doors Volkswagen Tiguan Battery
Modification	Battery power	Battery type
1.5 DSG	19.7 kWh	Lithium-ion batterie

Volkswagen Tiguan Specs, Engines & Dimensions — Third Generation
