Volkswagen Sharan Specs, Engines & Dimensions (2015–2022)

Volkswagen Sharan Engines and Transmissions

Volkswagen Sharan engine choices include gasoline and diesel options. The gasoline 1.4 MT and 1.4 DSG examples pair front-wheel drive with manual and automated dual-clutch shifting respectively. The diesel 2.0 DSG example combines automated shifting with all-wheel drive, which can help you pull away on slippery roads.

Minivan — Volkswagen Sharan Engines and Transmissions

Minivan Volkswagen Sharan Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1395 cm³	150 hp	110 kW	250 N⋅m	Manual	FWD
1.4 DSG	Gasoline	1395 cm³	150 hp	110 kW	250 N⋅m	Robotic	FWD
2.0 DSG	Gasoline	1984 cm³	220 hp	162 kW	350 N⋅m	Robotic	FWD
2.0 MT	Diesel	1968 cm³	115 hp	85 kW	280 N⋅m	Manual	FWD
2.0 MT	Diesel	1968 cm³	150 hp	110 kW	340 N⋅m	Manual	FWD
2.0 MT	Diesel	1968 cm³	150 hp	110 kW	340 N⋅m	Manual	AWD
2.0 DSG	Diesel	1968 cm³	150 hp	110 kW	340 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	177 hp	130 kW	380 N⋅m	Robotic	FWD
2.0 DSG	Diesel	1968 cm³	177 hp	130 kW	380 N⋅m	Robotic	AWD
2.0 MT	Diesel	1968 cm³	184 hp	135 kW	380 N⋅m	Manual	FWD
2.0 DSG	Diesel	1968 cm³	184 hp	135 kW	380 N⋅m	Robotic	FWD

Volkswagen Sharan Dimensions

Minivan — Volkswagen Sharan Dimensions

Minivan Volkswagen Sharan Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4854 mm	1904 mm	1720 mm	2920 mm	1703 kg	2300 kg	152 mm
1.4 DSG	4854 mm	1904 mm	1720 mm	2920 mm	1717 kg	2310 kg	152 mm
2.0 DSG	4854 mm	1904 mm	1720 mm	2920 mm	1790 kg	2360 kg	152 mm
2.0 MT	4854 mm	1904 mm	1720 mm	2920 mm	1772 kg	2390 kg	152 mm
2.0 MT	4854 mm	1904 mm	1720 mm	2920 mm	1772 kg	2390 kg	152 mm
2.0 MT	4854 mm	1904 mm	1720 mm	2920 mm	1891 kg	2560 kg	152 mm
2.0 DSG	4854 mm	1904 mm	1720 mm	2920 mm	1793 kg	2410 kg	152 mm
2.0 DSG	4854 mm	1904 mm	1720 mm	2920 mm	1815 kg	2390 kg	152 mm
2.0 DSG	4854 mm	1904 mm	1720 mm	2920 mm	1915 kg	2560 kg	152 mm
2.0 MT	4854 mm	1904 mm	1720 mm	2920 mm	1800 kg	2400 kg	152 mm
2.0 DSG	4854 mm	1904 mm	1720 mm	2920 mm	1804 kg	2400 kg	152 mm

Volkswagen Sharan Cargo Space

Minivan — Volkswagen Sharan Cargo Space

Minivan Volkswagen Sharan Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	300 l	2430 l
1.4 DSG	300 l	2430 l
2.0 DSG	300 l	2430 l
2.0 MT	300 l	2430 l
2.0 MT	300 l	2430 l
2.0 MT	300 l	2430 l
2.0 DSG	300 l	2430 l
2.0 DSG	300 l	2430 l
2.0 DSG	300 l	2430 l
2.0 MT	300 l	2430 l
2.0 DSG	300 l	2430 l
