Volkswagen Phaeton Specs, Engines & Dimensions (2010–2016)

Volkswagen Phaeton Engines and Transmissions

Each Volkswagen Phaeton engine here pairs an automatic transmission with all-wheel drive. The 3.6 AT and 4.2 AT gasoline Sedan examples cover daily cruising or extra reserve, while the 3.0 AT diesel favors long highway runs. These powertrains show typical drivetrain pairings, not every version.

Sedan — Volkswagen Phaeton Engines and Transmissions

Sedan Volkswagen Phaeton Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.6 AT	Gasoline	3567 cm³	280 hp	205 kW	360 N⋅m	Automatic	AWD
4.2 AT	Gasoline	4172 cm³	335 hp	246 kW	430 N⋅m	Automatic	AWD
6.0 AT	Gasoline	5998 cm³	450 hp	330 kW	550 N⋅m	Automatic	AWD
3.0 AT	Diesel	2967 cm³	240 hp	176 kW	499 N⋅m	Automatic	AWD

Sedan Long — Volkswagen Phaeton Engines and Transmissions

Sedan Long Volkswagen Phaeton Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.6 AT	Gasoline	3567 cm³	280 hp	205 kW	360 N⋅m	Automatic	AWD
4.2 AT	Gasoline	4172 cm³	335 hp	246 kW	430 N⋅m	Automatic	AWD
6.0 AT	Gasoline	5998 cm³	450 hp	330 kW	550 N⋅m	Automatic	AWD
3.0 AT	Diesel	2967 cm³	240 hp	176 kW	499 N⋅m	Automatic	AWD

Volkswagen Phaeton Dimensions

Sedan — Volkswagen Phaeton Dimensions

Sedan Volkswagen Phaeton Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.6 AT	5059 mm	1903 mm	1450 mm	2881 mm	2154 kg	2680 kg	120 mm
4.2 AT	5059 mm	1903 mm	1450 mm	2881 mm	2182 kg	2700 kg	120 mm
6.0 AT	5059 mm	1903 mm	1450 mm	2881 mm	2300 kg	2850 kg	120 mm
3.0 AT	5059 mm	1903 mm	1450 mm	2881 mm	2252 kg	2780 kg	120 mm

Sedan Long — Volkswagen Phaeton Dimensions

Sedan Long Volkswagen Phaeton Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
3.6 AT	5179 mm	1903 mm	1450 mm	3001 mm	2173 kg	2710 kg	120 mm
4.2 AT	5179 mm	1903 mm	1450 mm	3001 mm	2201 kg	2730 kg	120 mm
6.0 AT	5179 mm	1903 mm	1450 mm	3001 mm	2433 kg	2910 kg	120 mm
3.0 AT	5179 mm	1903 mm	1450 mm	3001 mm	2313 kg	2860 kg	120 mm

Volkswagen Phaeton Cargo Space

Sedan — Volkswagen Phaeton Cargo Space

Sedan Volkswagen Phaeton Cargo Space
Modification	Trunk volume min
3.6 AT	500 l
4.2 AT	500 l
6.0 AT	500 l
3.0 AT	500 l

Sedan Long — Volkswagen Phaeton Cargo Space

Sedan Long Volkswagen Phaeton Cargo Space
Modification	Trunk volume min
3.6 AT	500 l
4.2 AT	500 l
6.0 AT	500 l
3.0 AT	500 l
