Catalog / Vauxhall / Insignia / 2 generation
Vauxhall Insignia Engines and Transmissions
Vauxhall Insignia engine choices include the 1.5 AT petrol liftback, pairing an automatic transmission with front-wheel drive for easy progress in traffic. Selected all-wheel-drive alternatives include the 2.0 MT diesel estate with a manual gearbox and the 2.0 AT petrol liftback with an automatic. All-wheel drive can help you pull away on slippery surfaces, although grip still depends on your tyres and the conditions.
Liftback — Vauxhall Insignia Engines and Transmissions
Liftback Vauxhall Insignia Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Gasoline 1490 cm³ 140 hp 103 kW 250 N⋅m Manual FWD 1.5 AT Gasoline 1490 cm³ 165 hp 121 kW 250 N⋅m Automatic FWD 1.5 MT Gasoline 1490 cm³ 165 hp 122 kW 250 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 260 hp 191 kW 400 N⋅m Automatic AWD 1.6 MT Diesel 1598 cm³ 110 hp 81 kW 300 N⋅m Manual FWD 1.6 AT Diesel 1598 cm³ 136 hp 100 kW 320 N⋅m Automatic FWD 1.6 MT Diesel 1598 cm³ 136 hp 100 kW 320 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Manual FWD 2.0 AT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Automatic FWD 2.0 AT Diesel 1956 cm³ 210 hp 154 kW 480 N⋅m Automatic AWD
Estate 5-door — Vauxhall Insignia Engines and Transmissions
Estate 5-door Vauxhall Insignia Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Gasoline 1490 cm³ 140 hp 103 kW 250 N⋅m Manual FWD 1.5 MT Gasoline 1490 cm³ 165 hp 122 kW 250 N⋅m Manual FWD 1.5 AT Gasoline 1490 cm³ 165 hp 122 kW 250 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 260 hp 191 kW 400 N⋅m Automatic AWD 2.0 AT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Automatic FWD 2.0 MT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Manual FWD 2.0 MT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Manual AWD 2.0 AT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Automatic FWD 2.0 MT Diesel 1956 cm³ 170 hp 125 kW 400 N⋅m Manual FWD
Vauxhall Insignia Dimensions
Liftback — Vauxhall Insignia Dimensions
Liftback Vauxhall Insignia Dimensions Modification Length Width Height Wheelbase Curb weight 1.5 MT 4897 mm 1863 mm 1455 mm 2829 mm Not provided 1.5 AT 4897 mm 1863 mm 1455 mm 2829 mm Not provided 1.5 MT 4897 mm 1863 mm 1455 mm 2829 mm Not provided 2.0 AT 4897 mm 1863 mm 1455 mm 2829 mm 1649 kg 1.6 MT 4897 mm 1863 mm 1455 mm 2829 mm 1503 kg 1.6 AT 4897 mm 1863 mm 1455 mm 2829 mm 1522 kg 1.6 MT 4897 mm 1863 mm 1455 mm 2829 mm 1503 kg 2.0 MT 4897 mm 1863 mm 1455 mm 2829 mm 1582 kg 2.0 AT 4897 mm 1863 mm 1455 mm 2829 mm Not provided 2.0 AT 4897 mm 1863 mm 1455 mm 2829 mm Not provided
Estate 5-door — Vauxhall Insignia Dimensions
Estate 5-door Vauxhall Insignia Dimensions Modification Length Width Height Wheelbase Curb weight 1.5 MT 4986 mm 1863 mm 1514 mm 2829 mm 1487 kg 1.5 MT 4986 mm 1863 mm 1514 mm 2829 mm 1487 kg 1.5 AT 4986 mm 1863 mm 1514 mm 2829 mm Not provided 2.0 AT 4986 mm 1863 mm 1514 mm 2829 mm Not provided 2.0 AT 4986 mm 1863 mm 1514 mm 2829 mm Not provided 2.0 MT 4986 mm 1863 mm 1514 mm 2829 mm 1633 kg 2.0 MT 4986 mm 1863 mm 1514 mm 2829 mm Not provided 2.0 AT 4986 mm 1863 mm 1514 mm 2829 mm Not provided 2.0 MT 4986 mm 1863 mm 1514 mm 2829 mm Not provided
Vauxhall Insignia Cargo Space
Liftback — Vauxhall Insignia Cargo Space
Estate 5-door — Vauxhall Insignia Cargo Space
