Toyota Corolla Specs, Engines & Dimensions (2012–2016)

Toyota Corolla Engines and Transmissions

Selected Toyota Corolla engine options include the gasoline 1.3 CVT and hybrid 1.5 CVT estates, plus the diesel 1.4 MT sedan, all with front-wheel drive. The CVT versions spare you manual gear changes, while the diesel pairs its engine with a manual transmission. In general, hybrid powertrains can make particularly good use of stop-start urban driving.

Estate 5-door — Toyota Corolla Engines and Transmissions

Estate 5-door Toyota Corolla Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 CVT	Gasoline	1329 cm³	95 hp	60 kW	121 N⋅m	Variable	FWD
1.5 CVT	Gasoline	1496 cm³	103 hp	76 kW	132 N⋅m	Variable	AWD
1.5 MT	Gasoline	1496 cm³	109 hp	80 kW	138 N⋅m	Manual	FWD
1.5 CVT	Gasoline	1496 cm³	109 hp	80 kW	136 N⋅m	Variable	FWD
1.8 CVT	Gasoline	1797 cm³	140 hp	103 kW	172 N⋅m	Variable	FWD
1.5 CVT	Hybrid	1496 cm³	74 hp	54 kW	111 N⋅m	Variable	FWD

Sedan — Toyota Corolla Engines and Transmissions

Sedan Toyota Corolla Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.3 MT	Gasoline	1329 cm³	99 hp	73 kW	128 N⋅m	Manual	FWD
1.6 CVT	Gasoline	1598 cm³	122 hp	90 kW	157 N⋅m	Variable	FWD
1.6 MT	Gasoline	1598 cm³	122 hp	90 kW	157 N⋅m	Manual	FWD
1.8 CVT	Gasoline	1798 cm³	140 hp	103 kW	173 N⋅m	Variable	FWD
1.4 MT	Diesel	1364 cm³	90 hp	66 kW	205 N⋅m	Manual	FWD
1.3 CVT	Gasoline	1329 cm³	95 hp	60 kW	121 N⋅m	Variable	FWD
1.5 CVT	Gasoline	1496 cm³	103 hp	76 kW	132 N⋅m	Variable	AWD
1.5 MT	Gasoline	1496 cm³	109 hp	80 kW	138 N⋅m	Manual	FWD
1.5 CVT	Gasoline	1496 cm³	109 hp	80 kW	136 N⋅m	Variable	FWD
1.5 CVT	Hybrid	1496 cm³	74 hp	54 kW	111 N⋅m	Variable	FWD
1.6 MT	Gasoline	1598 cm³	132 hp	97 kW	160 N⋅m	Manual	FWD
1.6 CVT	Gasoline	1598 cm³	132 hp	97 kW	160 N⋅m	Variable	FWD

Toyota Corolla Dimensions

Estate 5-door — Toyota Corolla Dimensions

Estate 5-door Toyota Corolla Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.3 CVT	4360 mm	1695 mm	1460 mm	2600 mm	1050 kg	1325 kg	150 mm
1.5 CVT	4360 mm	1695 mm	1460 mm	2600 mm	1180 kg	1455 kg	150 mm
1.5 MT	4360 mm	1695 mm	1460 mm	2600 mm	1070 kg	1345 kg	150 mm
1.5 CVT	4360 mm	1695 mm	1460 mm	2600 mm	1180 kg	1455 kg	150 mm
1.8 CVT	4360 mm	1695 mm	1460 mm	2600 mm	1160 kg	Not provided	150 mm
1.5 CVT	4360 mm	1695 mm	1460 mm	2600 mm	1140 kg	1415 kg	150 mm

Sedan — Toyota Corolla Dimensions

Sedan Toyota Corolla Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.3 MT	4620 mm	1775 mm	1465 mm	2700 mm	1225 kg	1735 kg	150 mm
1.6 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1260 kg	1760 kg	150 mm
1.6 MT	4620 mm	1775 mm	1465 mm	2700 mm	1260 kg	1760 kg	150 mm
1.8 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1275 kg	1785 kg	150 mm
1.4 MT	4620 mm	1775 mm	1465 mm	2700 mm	1270 kg	1780 kg	150 mm
1.3 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1050 kg	1325 kg	150 mm
1.5 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1180 kg	1455 kg	150 mm
1.5 MT	4620 mm	1775 mm	1465 mm	2700 mm	1070 kg	1345 kg	150 mm
1.5 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1180 kg	1455 kg	150 mm
1.5 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1140 kg	1415 kg	150 mm
1.6 MT	4620 mm	1775 mm	1465 mm	2700 mm	1270 kg	1770 kg	150 mm
1.6 CVT	4620 mm	1775 mm	1465 mm	2700 mm	1280 kg	1770 kg	150 mm

Toyota Corolla Cargo Space

Sedan — Toyota Corolla Cargo Space

Sedan Toyota Corolla Cargo Space
Modification	Trunk volume min
1.3 MT	452 l
1.6 CVT	452 l
1.6 MT	452 l
1.8 CVT	452 l
1.4 MT	452 l
1.3 CVT	452 l
1.5 CVT	452 l
1.5 MT	452 l
1.5 CVT	452 l
1.5 CVT	452 l
1.6 MT	452 l
1.6 CVT	452 l

Toyota Corolla Trims and Equipment

Toyota Corolla trim levels describe equipment choices alongside the mechanical specification. The gasoline, front-wheel-drive 1.3 MT sedan has a configuration named Base. When choosing a car, check its actual comfort, convenience and safety equipment: the engine and transmission designation alone does not tell you which features are fitted.

Toyota Corolla Trims and Equipment
Modification	Body	Equipment
1.3 MT	Sedan	Base
1.6 CVT	Sedan	Classic
1.6 CVT	Sedan	Prestige
1.6 CVT	Sedan	Style
1.6 CVT	Sedan	Style Plus
1.6 MT	Sedan	Classic
1.6 MT	Sedan	GLI
1.6 CVT	Sedan	Sun
1.6 CVT	Sedan	GLI
