Suzuki Jimny Specs, Engines & Dimensions (1970–1981)

Suzuki Jimny Engines and Transmissions

The Suzuki Jimny engine in this generation is a small gasoline unit with a simple powertrain. One example is the 0.8 MT three-door, pairing a manual transmission with all-wheel drive so you can pick gears on steep or loose ground. That drivetrain suits slow, controlled off-road work.

SUV 3-doors — Suzuki Jimny Engines and Transmissions

SUV 3-doors Suzuki Jimny Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
0.4 MT	Gasoline	359 cm³	25 hp	18 kW	Not provided	Manual	AWD
0.4 MT	Gasoline	359 cm³	28 hp	21 kW	36 N⋅m	Manual	AWD
0.5 MT	Gasoline	539 cm³	26 hp	19 kW	56 N⋅m	Manual	AWD
0.5 MT	Gasoline	539 cm³	33 hp	24 kW	56 N⋅m	Manual	AWD
0.8 MT	Gasoline	797 cm³	41 hp	30 kW	60 N⋅m	Manual	AWD

Suzuki Jimny Dimensions

SUV 3-doors — Suzuki Jimny Dimensions

SUV 3-doors Suzuki Jimny Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
0.4 MT	3170 mm	1395 mm	1685 mm	1930 mm	590 kg	Not provided	240 mm
0.4 MT	3170 mm	1395 mm	1685 mm	1930 mm	600 kg	Not provided	240 mm
0.5 MT	3170 mm	1395 mm	1685 mm	1930 mm	700 kg	Not provided	240 mm
0.5 MT	3170 mm	1395 mm	1685 mm	1930 mm	700 kg	Not provided	240 mm
0.8 MT	3170 mm	1395 mm	1685 mm	1930 mm	790 kg	1140 kg	240 mm
