Subaru R2 Specs, Engines & Dimensions (2003–2010)

Subaru R2 Engines and Transmissions

Every Subaru R2 engine in this generation is gasoline-fuelled and small in displacement, tuned for low running costs rather than outright speed. Some versions add forced induction for stronger mid-range pull, while automatic transmissions keep city driving relaxed and drivetrain choices suit both urban commutes and poorer surfaces.

Mini 5-doors — Subaru R2 Engines and Transmissions

Mini 5-doors Subaru R2 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
0.7 CVT	Gasoline	658 cm³	46 hp	34 kW	58 N⋅m	Variable	AWD
0.7 MT	Gasoline	658 cm³	46 hp	34 kW	58 N⋅m	Manual	FWD
0.7 CVT	Gasoline	658 cm³	46 hp	34 kW	58 N⋅m	Variable	FWD
0.7 MT	Gasoline	658 cm³	46 hp	34 kW	58 N⋅m	Manual	AWD
0.7 CVT	Gasoline	658 cm³	54 hp	40 kW	63 N⋅m	Variable	FWD
0.7 CVT	Gasoline	658 cm³	54 hp	40 kW	63 N⋅m	Variable	AWD
0.7 MT	Gasoline	658 cm³	54 hp	40 kW	63 N⋅m	Manual	FWD
0.7 MT	Gasoline	658 cm³	54 hp	40 kW	63 N⋅m	Manual	AWD
0.7 CVT	Gasoline	658 cm³	64 hp	47 kW	103 N⋅m	Variable	AWD
0.7 CVT	Gasoline	658 cm³	64 hp	47 kW	103 N⋅m	Variable	FWD
0.7 MT	Gasoline	658 cm³	64 hp	47 kW	99 N⋅m	Manual	FWD
0.7 MT	Gasoline	658 cm³	64 hp	47 kW	99 N⋅m	Manual	AWD

Subaru R2 Dimensions

Mini 5-doors — Subaru R2 Dimensions

Mini 5-doors Subaru R2 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
0.7 CVT	3395 mm	1475 mm	1520 mm	2360 mm	840 kg	1200 kg	155 mm
0.7 MT	3395 mm	1475 mm	1520 mm	2360 mm	770 kg	Not provided	155 mm
0.7 CVT	3395 mm	1475 mm	1520 mm	2360 mm	800 kg	1200 kg	155 mm
0.7 MT	3395 mm	1475 mm	1520 mm	2360 mm	810 kg	Not provided	155 mm
0.7 CVT	3395 mm	1475 mm	1520 mm	2360 mm	810 kg	1200 kg	155 mm
0.7 CVT	3395 mm	1475 mm	1520 mm	2360 mm	850 kg	1200 kg	155 mm
0.7 MT	3395 mm	1475 mm	1520 mm	2360 mm	780 kg	Not provided	155 mm
0.7 MT	3395 mm	1475 mm	1520 mm	2360 mm	820 kg	Not provided	155 mm
0.7 CVT	3395 mm	1475 mm	1520 mm	2360 mm	870 kg	1200 kg	160 mm
0.7 CVT	3395 mm	1475 mm	1520 mm	2360 mm	830 kg	1200 kg	160 mm
0.7 MT	3395 mm	1475 mm	1520 mm	2360 mm	770 kg	Not provided	155 mm
0.7 MT	3395 mm	1475 mm	1520 mm	2360 mm	770 kg	Not provided	155 mm

Subaru R2 Cargo Space

Mini 5-doors — Subaru R2 Cargo Space

Mini 5-doors Subaru R2 Cargo Space
Modification	Trunk volume min
0.7 CVT	120 l
0.7 MT	120 l
0.7 CVT	120 l
0.7 MT	120 l
0.7 CVT	120 l
0.7 CVT	120 l
0.7 MT	120 l
0.7 MT	120 l
0.7 CVT	120 l
0.7 CVT	120 l
0.7 MT	120 l
0.7 MT	120 l
