Catalog / SEAT / Ibiza / 2 generation, restyling
SEAT Ibiza Engines and Transmissions
The SEAT Ibiza engine range focuses on simple, economical petrol units paired with either a manual or automatic transmission. Front-wheel drive keeps the setup straightforward and light. For example, the 1.0 MT in the Mini 5-doors uses a manual gearbox, while the 1.6 AT offers automatic convenience.
Mini 5-doors — SEAT Ibiza Engines and Transmissions
Mini 5-doors SEAT Ibiza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.0 MT Gasoline 999 cm³ 50 hp 37 kW 86 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 75 hp 55 kW 128 N⋅m Manual FWD 1.4 MT Gasoline 1391 cm³ 100 hp 74 kW 128 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 68 hp 50 kW 133 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 90 hp 66 kW 210 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 110 hp 81 kW 235 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 60 hp 44 kW 116 N⋅m Manual FWD 1.6 MT Gasoline 1595 cm³ 101 hp 74 kW 140 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 75 hp 55 kW 135 N⋅m Manual FWD 1.6 AT Gasoline 1595 cm³ 101 hp 74 kW 145 N⋅m Automatic FWD
Mini 3-doors — SEAT Ibiza Engines and Transmissions
Mini 3-doors SEAT Ibiza Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.0 MT Gasoline 999 cm³ 50 hp 37 kW 86 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 75 hp 55 kW 128 N⋅m Manual FWD 1.4 MT Gasoline 1391 cm³ 100 hp 74 kW 128 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 68 hp 50 kW 133 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 90 hp 66 kW 210 N⋅m Manual FWD 1.9 MT Diesel 1896 cm³ 110 hp 81 kW 235 N⋅m Manual FWD 1.4 MT Gasoline 1390 cm³ 60 hp 44 kW 116 N⋅m Manual FWD 1.6 MT Gasoline 1595 cm³ 101 hp 74 kW 140 N⋅m Manual FWD 1.6 AT Gasoline 1595 cm³ 101 hp 74 kW 145 N⋅m Automatic FWD 1.6 MT Gasoline 1598 cm³ 75 hp 55 kW 135 N⋅m Manual FWD 1.8 MT Gasoline 1781 cm³ 156 hp 114 kW 210 N⋅m Manual FWD
SEAT Ibiza Dimensions
Mini 5-doors — SEAT Ibiza Dimensions
Mini 5-doors SEAT Ibiza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.0 MT 3853 mm 1640 mm 1422 mm 2443 mm 910 kg 1370 kg Not provided 1.4 MT 3853 mm 1640 mm 1422 mm 2443 mm 995 kg 1445 kg 150 mm 1.4 MT 3853 mm 1640 mm 1422 mm 2443 mm 985 kg 1440 kg Not provided 1.9 MT 3853 mm 1640 mm 1422 mm 2443 mm 1042 kg 1505 kg 150 mm 1.9 MT 3853 mm 1640 mm 1422 mm 2443 mm 1050 kg 1510 kg Not provided 1.9 MT 3853 mm 1640 mm 1422 mm 2443 mm 1060 kg 1520 kg Not provided 1.4 MT 3853 mm 1640 mm 1422 mm 2443 mm 920 kg 1380 kg Not provided 1.6 MT 3853 mm 1640 mm 1422 mm 2443 mm 1000 kg 1465 kg Not provided 1.6 MT 3853 mm 1640 mm 1422 mm 2443 mm 970 kg 1435 kg Not provided 1.6 AT 3853 mm 1640 mm 1422 mm 2443 mm 1044 kg 1500 kg 150 mm
Mini 3-doors — SEAT Ibiza Dimensions
Mini 3-doors SEAT Ibiza Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.0 MT 3853 mm 1640 mm 1422 mm 2443 mm 910 kg 1370 kg Not provided 1.4 MT 3853 mm 1640 mm 1422 mm 2443 mm 995 kg 1445 kg 150 mm 1.4 MT 3853 mm 1640 mm 1422 mm 2443 mm 985 kg 1440 kg Not provided 1.9 MT 3853 mm 1640 mm 1422 mm 2443 mm 1042 kg 1505 kg 150 mm 1.9 MT 3853 mm 1640 mm 1422 mm 2443 mm 1050 kg 1510 kg Not provided 1.9 MT 3853 mm 1640 mm 1422 mm 2443 mm 1060 kg 1520 kg Not provided 1.4 MT 3853 mm 1640 mm 1422 mm 2443 mm 920 kg 1380 kg Not provided 1.6 MT 3853 mm 1640 mm 1422 mm 2443 mm 1000 kg 1465 kg Not provided 1.6 AT 3853 mm 1640 mm 1422 mm 2443 mm 1044 kg 1500 kg 150 mm 1.6 MT 3853 mm 1640 mm 1422 mm 2443 mm 970 kg 1435 kg Not provided 1.8 MT 3853 mm 1640 mm 1422 mm 2443 mm 1120 kg 1580 kg Not provided
SEAT Ibiza Cargo Space
Mini 5-doors — SEAT Ibiza Cargo Space
Mini 3-doors — SEAT Ibiza Cargo Space
