Renault Grand Scenic Specs, Engines & Dimensions (2006–2009)

Renault Grand Scenic Engines and Transmissions

The Renault Grand Scenic engine lineup balances economy and performance. A 1.6 16V gasoline unit with a manual transmission suits everyday driving, while a 2.0 16V offers more power for loaded trips. For efficiency, a 1.9 dCi diesel pairs with an automatic transmission, easing urban commutes.

Compact Van — Renault Grand Scenic Engines and Transmissions

Compact Van Renault Grand Scenic Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 16V MT	Gasoline	1598 cm³	113 hp	83 kW	191 N⋅m	Manual	FWD
2.0 16V MT	Gasoline	1998 cm³	135 hp	99 kW	191 N⋅m	Manual	FWD
2.0 16V Turbo MT	Gasoline	1998 cm³	163 hp	119 kW	270 N⋅m	Manual	FWD
1.5 dCi MT	Diesel	1461 cm³	106 hp	77 kW	240 N⋅m	Manual	FWD
1.9 dCi MT	Diesel	1870 cm³	130 hp	95 kW	300 N⋅m	Manual	FWD
1.9 dCi AT	Diesel	1870 cm³	130 hp	95 kW	300 N⋅m	Automatic	FWD
2.0 dCi MT	Diesel	1998 cm³	150 hp	110 kW	260 N⋅m	Manual	FWD
2.0 16V AT	Gasoline	1998 cm³	135 hp	99 kW	191 N⋅m	Automatic	FWD

Renault Grand Scenic Dimensions

Compact Van — Renault Grand Scenic Dimensions

Compact Van Renault Grand Scenic Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight
1.6 16V MT	4493 mm	1810 mm	1636 mm	2736 mm	1445 kg	2120 kg
2.0 16V MT	4493 mm	1810 mm	1636 mm	2736 mm	1510 kg	2180 kg
2.0 16V Turbo MT	4493 mm	1810 mm	1636 mm	2736 mm	1610 kg	2205 kg
1.5 dCi MT	4493 mm	1810 mm	1636 mm	2736 mm	1530 kg	2195 kg
1.9 dCi MT	4493 mm	1810 mm	1636 mm	2736 mm	1530 kg	2195 kg
1.9 dCi AT	4493 mm	1810 mm	1636 mm	2736 mm	1540 kg	2205 kg
2.0 dCi MT	4493 mm	1810 mm	1636 mm	2736 mm	1535 kg	2215 kg
2.0 16V AT	4493 mm	1810 mm	1636 mm	2736 mm	1530 kg	2200 kg

Renault Grand Scenic Cargo Space

Compact Van — Renault Grand Scenic Cargo Space

Compact Van Renault Grand Scenic Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 16V MT	200 l	1920 l
2.0 16V MT	200 l	1920 l
2.0 16V Turbo MT	200 l	1920 l
1.5 dCi MT	200 l	1920 l
1.9 dCi MT	200 l	1920 l
1.9 dCi AT	200 l	1920 l
2.0 dCi MT	200 l	1920 l
2.0 16V AT	200 l	1920 l
