Catalog / Renault / 5 / 1 generation
Renault 5 Engines and Transmissions
The Renault 5 engine range focuses on everyday usability. A small gasoline unit with a manual gearbox delivers light, economical performance for city trips. For longer runs or heavier use, a diesel with manual transmission offers stronger low-speed pull and better fuel economy. An automatic option paired with a gasoline engine adds relaxed stop-and-go convenience, while all versions send power to the front wheels.
Mini 5-doors — Renault 5 Engines and Transmissions
Mini 5-doors Renault 5 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
0.8 MT Gasoline 800 cm³ 34 hp 25 kW Not provided Manual FWD 1.0 MT Gasoline 956 cm³ 41 hp 30 kW Not provided Manual FWD 1.1 MT Gasoline 1100 cm³ 45 hp 33 kW Not provided Manual FWD 1.3 MT4 Gasoline 1280 cm³ 42 hp 31 kW Not provided Manual FWD 1.3 MT3 Gasoline 1280 cm³ 42 hp 31 kW Not provided Manual FWD 1.3 MT Gasoline 1280 cm³ 64 hp 47 kW Not provided Manual FWD 1.3 AT Gasoline 1337 cm³ 54 hp 40 kW Not provided Automatic FWD 1.4 MT Gasoline 1390 cm³ 60 hp 44 kW 102 N⋅m Manual FWD 1.4 AT Gasoline 1397 cm³ 58 hp 43 kW 102 N⋅m Automatic FWD 1.6 MT Diesel 1595 cm³ 55 hp 40 kW 102 N⋅m Manual FWD 1.3 MT Gasoline 1280 cm³ 42 hp 31 kW Not provided Manual FWD
Mini 3-doors — Renault 5 Engines and Transmissions
Mini 3-doors Renault 5 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
0.8 MT Gasoline 800 cm³ 34 hp 25 kW Not provided Manual FWD 1.0 MT Gasoline 956 cm³ 41 hp 30 kW Not provided Manual FWD 1.1 MT Gasoline 1100 cm³ 45 hp 33 kW Not provided Manual FWD 1.3 MT Gasoline 1280 cm³ 42 hp 31 kW Not provided Manual FWD 1.3 MT Gasoline 1280 cm³ 64 hp 47 kW Not provided Manual FWD 1.3 AT Gasoline 1337 cm³ 54 hp 40 kW Not provided Automatic FWD 1.4 MT Gasoline 1380 cm³ 108 hp 79 kW Not provided Manual FWD 1.4 MT Gasoline 1390 cm³ 60 hp 44 kW 102 N⋅m Manual FWD 1.4 AT Gasoline 1397 cm³ 58 hp 43 kW 102 N⋅m Automatic FWD 1.4 MT Gasoline 1397 cm³ 93 hp 68 kW Not provided Manual FWD 1.4 MT Gasoline 1397 cm³ 160 hp 118 kW 221 N⋅m Manual FWD 1.6 MT Diesel 1595 cm³ 55 hp 40 kW 102 N⋅m Manual FWD
Renault 5 Dimensions
Mini 5-doors — Renault 5 Dimensions
Mini 5-doors Renault 5 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
0.8 MT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.0 MT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.1 MT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 MT4 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 MT3 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 MT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 AT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.4 MT 3590 mm 1565 mm 1385 mm 2415 mm 760 kg 1195 kg 120 mm 1.4 AT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.6 MT 3590 mm 1565 mm 1385 mm 2415 mm 795 kg 1215 kg 120 mm 1.3 MT 3590 mm 1565 mm 1385 mm 2415 mm Not provided Not provided 120 mm
Mini 3-doors — Renault 5 Dimensions
Mini 3-doors Renault 5 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
0.8 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.0 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.1 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.3 AT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.4 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.4 MT 3590 mm 1556 mm 1385 mm 2415 mm 760 kg 1195 kg 120 mm 1.4 AT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.4 MT 3590 mm 1556 mm 1385 mm 2415 mm Not provided Not provided 120 mm 1.4 MT 3590 mm 1556 mm 1385 mm 2415 mm 980 kg 1260 kg 120 mm 1.6 MT 3590 mm 1556 mm 1385 mm 2415 mm 795 kg 1215 kg 120 mm
Renault 5 Cargo Space
Mini 5-doors — Renault 5 Cargo Space
Mini 3-doors — Renault 5 Cargo Space
