Plymouth Voyager Specs, Engines & Dimensions (1991–1995)

Plymouth Voyager Engines and Transmissions

Plymouth Voyager engine options include the gasoline 2.5 AT and 3.8 AT with front-wheel drive, plus the gasoline 3.3 AT with all-wheel drive. These automatic versions illustrate the range: larger engines generally feel less strained when carrying passengers and luggage, while all-wheel drive helps you pull away on slippery surfaces.

Minivan — Plymouth Voyager Engines and Transmissions

Minivan Plymouth Voyager Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Gasoline	2972 cm³	144 hp	106 kW	235 N⋅m	Automatic	FWD
3.3 AT	Gasoline	3301 cm³	165 hp	121 kW	263 N⋅m	Automatic	FWD
3.8 AT	Gasoline	3778 cm³	165 hp	121 kW	289 N⋅m	Automatic	FWD
2.5 AT	Gasoline	2501 cm³	98 hp	72 kW	183 N⋅m	Automatic	FWD
3.0 AT	Gasoline	2972 cm³	144 hp	106 kW	235 N⋅m	Automatic	FWD
3.3 AT	Gasoline	3301 cm³	152 hp	112 kW	251 N⋅m	Automatic	AWD
3.3 AT	Gasoline	3301 cm³	165 hp	121 kW	263 N⋅m	Automatic	FWD

Plymouth Voyager Dimensions

Minivan — Plymouth Voyager Dimensions

Minivan Plymouth Voyager Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Ground clearance, minimum
3.0 AT	4896 mm	1830 mm	1646 mm	3030 mm	1575 kg	130 mm
3.3 AT	4896 mm	1830 mm	1646 mm	3030 mm	1718 kg	130 mm
3.8 AT	4896 mm	1830 mm	1646 mm	3030 mm	1718 kg	130 mm
2.5 AT	4896 mm	1830 mm	1646 mm	3030 mm	1498 kg	130 mm
3.0 AT	4896 mm	1830 mm	1646 mm	3030 mm	1498 kg	130 mm
3.3 AT	4896 mm	1830 mm	1646 mm	3030 mm	1748 kg	130 mm
3.3 AT	4896 mm	1830 mm	1646 mm	3030 mm	1616 kg	130 mm

Plymouth Voyager Cargo Space

Minivan — Plymouth Voyager Cargo Space

Minivan Plymouth Voyager Cargo Space
Modification	Trunk volume min
3.0 AT	1020 l
3.3 AT	1020 l
3.8 AT	1020 l
2.5 AT	1020 l
3.0 AT	1020 l
3.3 AT	1020 l
3.3 AT	1020 l
