Mitsubishi Lancer Specs, Engines & Dimensions (2016–2017)

Mitsubishi Lancer Engines and Transmissions

The Mitsubishi Lancer engine lineup focuses on smooth, efficient gasoline options paired with either a manual or continuously variable transmission. For example, the 1.6 MT hatchback pairs a manual gearbox with front-wheel drive, ideal for straightforward, economical commuting. Meanwhile, the 2.4 CVT sedan uses all-wheel drive for extra traction in varied conditions, and the 1.8 CVT hatchback offers a balance of ease and efficiency.

Hatchback 5-door — Mitsubishi Lancer Engines and Transmissions

Hatchback 5-door Mitsubishi Lancer Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 MT	Gasoline	1590 cm³	117 hp	86 kW	154 N⋅m	Manual	FWD
1.8 CVT	Gasoline	1798 cm³	140 hp	103 kW	176 N⋅m	Variable	FWD

Sedan — Mitsubishi Lancer Engines and Transmissions

Sedan Mitsubishi Lancer Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
2.0 MT	Gasoline	1998 cm³	148 hp	109 kW	197 N⋅m	Manual	FWD
2.0 CVT	Gasoline	1998 cm³	148 hp	109 kW	197 N⋅m	Variable	FWD
2.4 MT	Gasoline	2360 cm³	168 hp	124 kW	226 N⋅m	Manual	FWD
2.4 CVT	Gasoline	2360 cm³	168 hp	124 kW	226 N⋅m	Variable	FWD
2.4 CVT	Gasoline	2360 cm³	168 hp	124 kW	226 N⋅m	Variable	AWD

Mitsubishi Lancer Dimensions

Hatchback 5-door — Mitsubishi Lancer Dimensions

Hatchback 5-door Mitsubishi Lancer Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 MT	4640 mm	1760 mm	1505 mm	2635 mm	1375 kg	1800 kg	140 mm
1.8 CVT	4640 mm	1760 mm	1505 mm	2635 mm	1450 kg	1900 kg	140 mm

Sedan — Mitsubishi Lancer Dimensions

Sedan Mitsubishi Lancer Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
2.0 MT	4625 mm	1763 mm	1481 mm	2634 mm	1310 kg	1800 kg	140 mm
2.0 CVT	4625 mm	1763 mm	1481 mm	2634 mm	1340 kg	1800 kg	140 mm
2.4 MT	4625 mm	1763 mm	1481 mm	2634 mm	1350 kg	1850 kg	147 mm
2.4 CVT	4625 mm	1763 mm	1481 mm	2634 mm	1380 kg	1850 kg	147 mm
2.4 CVT	4625 mm	1763 mm	1481 mm	2634 mm	1425 kg	1900 kg	140 mm

Mitsubishi Lancer Cargo Space

Hatchback 5-door — Mitsubishi Lancer Cargo Space

Hatchback 5-door Mitsubishi Lancer Cargo Space
Modification	Trunk volume min	Trunk volume max
1.6 MT	344 l	1349 l
1.8 CVT	344 l	1349 l

Sedan — Mitsubishi Lancer Cargo Space

Sedan Mitsubishi Lancer Cargo Space
Modification	Trunk volume min
2.0 MT	348 l
2.0 CVT	348 l
2.4 MT	348 l
2.4 CVT	348 l
2.4 CVT	348 l

Mitsubishi Lancer Trims and Equipment

Mitsubishi Lancer trim levels add convenience and style on top of the mechanical choices. For instance, the 1.8 CVT hatchback is available in a Sport equipment configuration, which typically includes sportier exterior accents and upgraded interior touches. Other editions may focus on comfort or value, allowing buyers to match the car to their priorities without changing the core driving character.

Mitsubishi Lancer Trims and Equipment
Modification	Body	Equipment
1.8 CVT	Hatchback 5-door	Sport

Mitsubishi Lancer Specs, Engines & Dimensions (2016–2017) — Tenth Generation Restyling 2
