Mitsubishi ASX Specs, Engines & Dimensions (2012–2016)

Mitsubishi ASX Engines and Transmissions

The Mitsubishi ASX engine range covers everyday commuting and light off-road use. A 1.8-litre petrol with a CVT drives the front wheels for smooth urban travel. For diesel fans, a 1.6 manual pairs with all-wheel drive, while a 2.0 petrol CVT also offers all-wheel drive for extra traction.

SUV 5-doors — Mitsubishi ASX Engines and Transmissions

SUV 5-doors Mitsubishi ASX Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.8 CVT	Gasoline	1798 cm³	140 hp	103 kW	177 N⋅m	Variable	FWD
2.0 CVT	Gasoline	1998 cm³	150 hp	110 kW	197 N⋅m	Variable	AWD
1.6 MT	Gasoline	1590 cm³	117 hp	86 kW	154 N⋅m	Manual	FWD
2.0 MT	Gasoline	1998 cm³	150 hp	110 kW	197 N⋅m	Manual	AWD
2.0 MT	Gasoline	1998 cm³	150 hp	110 kW	197 N⋅m	Manual	FWD
1.6 MT	Diesel	1560 cm³	114 hp	84 kW	270 N⋅m	Manual	FWD
1.6 MT	Diesel	1560 cm³	114 hp	84 kW	270 N⋅m	Manual	AWD
1.8 MT	Diesel	1798 cm³	116 hp	85 kW	270 N⋅m	Manual	FWD
1.8 MT	Diesel	1798 cm³	150 hp	110 kW	300 N⋅m	Manual	FWD
1.8 MT	Diesel	1798 cm³	150 hp	110 kW	300 N⋅m	Manual	AWD
2.3 AT	Diesel	2268 cm³	150 hp	110 kW	360 N⋅m	Automatic	AWD
2.3 AT	Diesel	2268 cm³	147 hp	108 kW	360 N⋅m	Automatic	AWD
2.0 CVT	Gasoline	1998 cm³	150 hp	110 kW	197 N⋅m	Variable	FWD

Mitsubishi ASX Dimensions

SUV 5-doors — Mitsubishi ASX Dimensions

SUV 5-doors Mitsubishi ASX Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.8 CVT	4295 mm	1770 mm	1625 mm	2670 mm	1390 kg	1970 kg	195 mm
2.0 CVT	4295 mm	1770 mm	1625 mm	2670 mm	1455 kg	1970 kg	195 mm
1.6 MT	4295 mm	1770 mm	1625 mm	2670 mm	1300 kg	1870 kg	195 mm
2.0 MT	4295 mm	1770 mm	1625 mm	2670 mm	1410 kg	1970 kg	195 mm
2.0 MT	4295 mm	1770 mm	1625 mm	2670 mm	1345 kg	1970 kg	195 mm
1.6 MT	4295 mm	1770 mm	1625 mm	2670 mm	1395 kg	1980 kg	180 mm
1.6 MT	4295 mm	1770 mm	1625 mm	2670 mm	1495 kg	1980 kg	180 mm
1.8 MT	4295 mm	1770 mm	1625 mm	2670 mm	1535 kg	2060 kg	195 mm
1.8 MT	4295 mm	1770 mm	1625 mm	2670 mm	1495 kg	2060 kg	195 mm
1.8 MT	4295 mm	1770 mm	1625 mm	2670 mm	1570 kg	2060 kg	195 mm
2.3 AT	4295 mm	1770 mm	1625 mm	2670 mm	1645 kg	2060 kg	195 mm
2.3 AT	4295 mm	1770 mm	1625 mm	2670 mm	1645 kg	2060 kg	195 mm
2.0 CVT	4295 mm	1770 mm	1625 mm	2670 mm	1395 kg	1970 kg	195 mm

Mitsubishi ASX Cargo Space

SUV 5-doors — Mitsubishi ASX Cargo Space

SUV 5-doors Mitsubishi ASX Cargo Space
Modification	Trunk volume min	Trunk volume max
1.8 CVT	384 l	1219 l
2.0 CVT	384 l	1219 l
1.6 MT	384 l	1219 l
2.0 MT	384 l	1219 l
2.0 MT	384 l	1219 l
1.6 MT	384 l	1219 l
1.6 MT	384 l	1219 l
1.8 MT	384 l	1219 l
1.8 MT	384 l	1219 l
1.8 MT	384 l	1219 l
2.3 AT	384 l	1219 l
2.3 AT	384 l	1219 l
2.0 CVT	384 l	1219 l

Mitsubishi ASX Trims and Equipment

Mitsubishi ASX trim levels like Intense and Instyle build on the 2.0-litre all-wheel-drive version. They add comfort and convenience features, allowing buyers to choose between a more essential setup and a more comprehensively equipped cabin without changing the core mechanical package.

Mitsubishi ASX Trims and Equipment
Modification	Body	Equipment
1.8 CVT	SUV 5-doors	Instyle
1.8 CVT	SUV 5-doors	Intense
1.8 CVT	SUV 5-doors	Invite
1.8 CVT	SUV 5-doors	Suriken
2.0 CVT	SUV 5-doors	Instyle
2.0 CVT	SUV 5-doors	Intense
2.0 CVT	SUV 5-doors	Suriken
2.0 CVT	SUV 5-doors	Exclusive
2.0 CVT	SUV 5-doors	Ultimate
