Catalog / Mercedes / S-Class / 5 generation
Mercedes S-Class Engines and Transmissions
The Mercedes S-Class engine lineup offers a range of smooth, powerful options. For example, the S600 uses a 6.2-liter gasoline unit paired with an automatic transmission and rear-wheel drive, ideal for effortless cruising. Alternatively, the S320d delivers diesel efficiency with all-wheel-drive traction, while the S350 balances performance and versatility through a 3.5-liter gasoline engine available with either rear- or all-wheel drive.
Limousine — Mercedes S-Class Engines and Transmissions
Limousine Mercedes S-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
S600 6.2 AT Gasoline 6208 cm³ 525 hp 386 kW 630 N⋅m Automatic RWD
Sedan — Mercedes S-Class Engines and Transmissions
Sedan Mercedes S-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
S350 3.5 AT Gasoline 3498 cm³ 272 hp 200 kW 350 N⋅m Automatic AWD S450 4.7 AT Gasoline 4663 cm³ 340 hp 250 kW 460 N⋅m Automatic AWD S450 4.7 AT Gasoline 4663 cm³ 340 hp 250 kW 460 N⋅m Automatic RWD S500 5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic AWD S320d 3.0 AT Diesel 2987 cm³ 235 hp 173 kW 540 N⋅m Automatic AWD S420d 4.0 AT Diesel 3996 cm³ 320 hp 235 kW 730 N⋅m Automatic RWD S350 3.5 AT Gasoline 3498 cm³ 272 hp 200 kW 350 N⋅m Automatic RWD S500 5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic RWD S320d 3.0 AT Diesel 2987 cm³ 235 hp 173 kW 540 N⋅m Automatic RWD
Sedan Long — Mercedes S-Class Engines and Transmissions
Sedan Long Mercedes S-Class Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
S350 3.5 AT Gasoline 3498 cm³ 272 hp 200 kW 350 N⋅m Automatic AWD S450 4.7 AT Gasoline 4663 cm³ 340 hp 250 kW 460 N⋅m Automatic AWD S450 4.7 AT Gasoline 4663 cm³ 340 hp 250 kW 460 N⋅m Automatic RWD S500 5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic AWD S300 3.0 AT Gasoline 2996 cm³ 235 hp 172 kW 300 N⋅m Automatic RWD S320d 3.0 AT Diesel 2987 cm³ 235 hp 173 kW 540 N⋅m Automatic AWD S420d 4.0 AT Diesel 3996 cm³ 320 hp 235 kW 730 N⋅m Automatic RWD S350 3.5 AT Gasoline 3498 cm³ 272 hp 200 kW 350 N⋅m Automatic RWD S500 5.5 AT Gasoline 5461 cm³ 388 hp 285 kW 530 N⋅m Automatic RWD S600 5.5 AT Gasoline 5513 cm³ 517 hp 380 kW 830 N⋅m Automatic RWD S320d 3.0 AT Diesel 2987 cm³ 235 hp 173 kW 540 N⋅m Automatic RWD
Mercedes S-Class Dimensions
Limousine — Mercedes S-Class Dimensions
Limousine Mercedes S-Class Dimensions Modification Length Width Height Wheelbase Ground clearance, minimum
S600 6.2 AT 6360 mm 1871 mm 1473 mm 4315 mm 145 mm
Sedan — Mercedes S-Class Dimensions
Sedan Mercedes S-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
S350 3.5 AT 5079 mm 1871 mm 1473 mm 3035 mm 1880 kg 2475 kg 150 mm S450 4.7 AT 5079 mm 1871 mm 1473 mm 3035 mm 2010 kg 2620 kg 150 mm S450 4.7 AT 5079 mm 1871 mm 1473 mm 3035 mm 1940 kg 2545 kg 150 mm S500 5.5 AT 5079 mm 1871 mm 1473 mm 3035 mm 1940 kg 2545 kg 150 mm S320d 3.0 AT 5079 mm 1871 mm 1473 mm 3035 mm 1955 kg 2550 kg 145 mm S420d 4.0 AT 5079 mm 1871 mm 1473 mm 3035 mm 2000 kg 2580 kg 145 mm S350 3.5 AT 5079 mm 1871 mm 1473 mm 3035 mm 1880 kg 2475 kg 150 mm S500 5.5 AT 5079 mm 1871 mm 1473 mm 3035 mm 1940 kg 2545 kg 150 mm S320d 3.0 AT 5079 mm 1871 mm 1473 mm 3035 mm 1955 kg 2550 kg 145 mm
Sedan Long — Mercedes S-Class Dimensions
Sedan Long Mercedes S-Class Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
S350 3.5 AT 5206 mm 1871 mm 1473 mm 3165 mm 1925 kg 2505 kg 150 mm S450 4.7 AT 5206 mm 1871 mm 1473 mm 3165 mm 2055 kg 2640 kg 150 mm S450 4.7 AT 5206 mm 1871 mm 1473 mm 3165 mm 1985 kg 2565 kg 150 mm S500 5.5 AT 5206 mm 1871 mm 1473 mm 3165 mm 2055 kg 2640 kg 150 mm S300 3.0 AT 5206 mm 1871 mm 1473 mm 3165 mm 1955 kg 2535 kg 150 mm S320d 3.0 AT 5206 mm 1871 mm 1473 mm 3165 mm 1955 kg 2550 kg 145 mm S420d 4.0 AT 5206 mm 1871 mm 1473 mm 3165 mm 2000 kg 2580 kg 145 mm S350 3.5 AT 5206 mm 1871 mm 1473 mm 3165 mm 1925 kg 2505 kg 150 mm S500 5.5 AT 5206 mm 1871 mm 1473 mm 3165 mm 2110 kg 2690 kg 150 mm S600 5.5 AT 5206 mm 1871 mm 1473 mm 3165 mm 2210 kg 2690 kg 150 mm S320d 3.0 AT 5206 mm 1871 mm 1473 mm 3165 mm 1955 kg 2550 kg 145 mm
Mercedes S-Class Cargo Space
Limousine — Mercedes S-Class Cargo Space
Limousine Mercedes S-Class Cargo Space Modification Trunk volume min
S600 6.2 AT 560 l
Sedan — Mercedes S-Class Cargo Space
Sedan Long — Mercedes S-Class Cargo Space
Mercedes S-Class Trims and Equipment
Mercedes S-Class trim levels are closely tied to the technical version you choose. The S350, for instance, comes in configurations that emphasize comfort and refinement, with equipment packages enhancing convenience. While the rear-wheel-drive Sedan offers a classic luxury feel, available all-wheel drive adds confidence in varied conditions. Overall, even base trims include a generous array of premium features.
