Catalog / Mercedes / CLK / 1 generation
Mercedes CLK Engines and Transmissions
A Mercedes CLK engine in this generation is gasoline-powered, with the drivetrain sending power to the rear wheels. Cabrio examples include the 2.3 MT with a manual transmission, plus 2.3 AT and 3.2 AT automatics: the 2.3 for everyday driving, the 3.2 AT for more relaxed touring.
Cabrio — Mercedes CLK Engines and Transmissions
Cabrio Mercedes CLK Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 MT Gasoline 1998 cm³ 136 hp 100 kW 190 N⋅m Manual RWD 2.0 AT Gasoline 1998 cm³ 192 hp 141 kW 270 N⋅m Automatic RWD 2.0 MT Gasoline 1998 cm³ 192 hp 141 kW 270 N⋅m Manual RWD 2.3 MT Gasoline 2295 cm³ 193 hp 142 kW 280 N⋅m Manual RWD 2.3 AT Gasoline 2295 cm³ 193 hp 142 kW 280 N⋅m Automatic RWD 3.2 AT Gasoline 3199 cm³ 218 hp 160 kW 310 N⋅m Automatic RWD 4.3 AT Gasoline 4266 cm³ 279 hp 205 kW 400 N⋅m Automatic RWD 2.0 AT Gasoline 1998 cm³ 136 hp 100 kW 190 N⋅m Automatic RWD
Coupe — Mercedes CLK Engines and Transmissions
Coupe Mercedes CLK Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
2.0 MT Gasoline 1998 cm³ 136 hp 100 kW 190 N⋅m Manual RWD 2.0 AT Gasoline 1998 cm³ 136 hp 100 kW 190 N⋅m Automatic RWD 2.0 MT Gasoline 1998 cm³ 192 hp 141 kW 270 N⋅m Manual RWD 2.0 AT Gasoline 1998 cm³ 192 hp 141 kW 270 N⋅m Automatic RWD 2.3 MT Gasoline 2295 cm³ 193 hp 142 kW 280 N⋅m Manual RWD 2.3 AT Gasoline 2295 cm³ 193 hp 142 kW 280 N⋅m Automatic RWD 4.3 AT Gasoline 4266 cm³ 279 hp 205 kW 400 N⋅m Automatic RWD 3.2 AT Gasoline 3199 cm³ 218 hp 160 kW 310 N⋅m Automatic RWD
Mercedes CLK Dimensions
Cabrio — Mercedes CLK Dimensions
Cabrio Mercedes CLK Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 MT 4569 mm 1720 mm 1379 mm 2690 mm 1475 kg 1980 kg 150 mm 2.0 AT 4569 mm 1720 mm 1379 mm 2690 mm 1520 kg 2000 kg 150 mm 2.0 MT 4569 mm 1720 mm 1379 mm 2690 mm 1520 kg 2000 kg 150 mm 2.3 MT 4569 mm 1720 mm 1379 mm 2690 mm 1450 kg 2030 kg 150 mm 2.3 AT 4569 mm 1720 mm 1379 mm 2690 mm 1350 kg 1850 kg 150 mm 3.2 AT 4569 mm 1720 mm 1379 mm 2690 mm 1620 kg 2070 kg 150 mm 4.3 AT 4569 mm 1720 mm 1379 mm 2690 mm 1755 kg 2050 kg 150 mm 2.0 AT 4569 mm 1720 mm 1379 mm 2690 mm 1475 kg 1980 kg 150 mm
Coupe — Mercedes CLK Dimensions
Coupe Mercedes CLK Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
2.0 MT 4569 mm 1720 mm 1369 mm 2690 mm 1275 kg 1800 kg 150 mm 2.0 AT 4569 mm 1720 mm 1369 mm 2690 mm 1275 kg 1800 kg 150 mm 2.0 MT 4569 mm 1720 mm 1369 mm 2690 mm 1320 kg 1820 kg 150 mm 2.0 AT 4569 mm 1720 mm 1369 mm 2690 mm 1320 kg 1820 kg 150 mm 2.3 MT 4569 mm 1720 mm 1369 mm 2690 mm 1350 kg 1850 kg 150 mm 2.3 AT 4569 mm 1720 mm 1369 mm 2690 mm 1350 kg 1850 kg 150 mm 4.3 AT 4569 mm 1720 mm 1369 mm 2690 mm 1480 kg 1960 kg 150 mm 3.2 AT 4569 mm 1720 mm 1369 mm 2690 mm 1420 kg 1920 kg 150 mm
Mercedes CLK Cargo Space
Cabrio — Mercedes CLK Cargo Space
Coupe — Mercedes CLK Cargo Space
