Mercedes CLA Specs, Engines & Dimensions (2013–2016) — First Generation

The first-generation Mercedes CLA combines a sweeping roofline with a choice of Sedan and five-door Estate bodies. If you regularly carry bulky luggage, the Estate’s larger rear opening may matter more to you than its styling.

← All Mercedes models

Mercedes CLA Engines and Transmissions

Your Mercedes CLA engine choice should reflect your usual journeys. Selected Estate examples include the gasoline CLA200 1.6 DCT and manual diesel CLA180CDI 1.5 MT, both with front-wheel drive. The diesel CLA180CDI 2.1 DCT combines a dual-clutch transmission with all-wheel drive. DCT versions handle gear changes for you, while the manual gives you direct control over gear selection.

Estate 5-door — Mercedes CLA Engines and Transmissions

Estate 5-door Mercedes CLA Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
CLA200 1.6 DCT	Gasoline	1595 cm³	156 hp	115 kW	250 N⋅m	Robotic	FWD
CLA200 2.0 DCT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Robotic	AWD
CLA180 1.6 MT	Gasoline	1595 cm³	122 hp	90 kW	200 N⋅m	Manual	FWD
CLA180 1.6 DCT	Gasoline	1595 cm³	122 hp	90 kW	200 N⋅m	Robotic	FWD
CLA200 1.6 MT	Gasoline	1595 cm³	156 hp	115 kW	250 N⋅m	Manual	FWD
CLA200 2.0 DCT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Robotic	FWD
CLA200 2.0 MT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Manual	FWD
CLA200 2.0 DCT	Gasoline	1991 cm³	218 hp	160 kW	350 N⋅m	Robotic	AWD
CLA180CDI 1.5 MT	Diesel	1461 cm³	109 hp	80 kW	260 N⋅m	Manual	FWD
CLA180CDI 1.5 DCT	Diesel	1461 cm³	109 hp	80 kW	260 N⋅m	Robotic	FWD
CLA180CDI 2.1 MT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Manual	FWD
CLA180CDI 2.1 DCT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Robotic	FWD
CLA180CDI 2.1 DCT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Robotic	AWD
CLA220CDI 2.1 DCT	Diesel	2143 cm³	177 hp	130 kW	350 N⋅m	Robotic	FWD
CLA220CDI 2.1 DCT	Diesel	2143 cm³	177 hp	130 kW	350 N⋅m	Robotic	AWD

Sedan — Mercedes CLA Engines and Transmissions

Sedan Mercedes CLA Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
CLA250 2.0 DCT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Robotic	AWD
CLA200 1.6 DCT	Gasoline	1595 cm³	150 hp	110 kW	250 N⋅m	Robotic	FWD
CLA250 2.0 MT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Manual	FWD
CLA200 2.0 MT	Gasoline	1991 cm³	218 hp	160 kW	350 N⋅m	Manual	FWD
CLA200 2.0 DCT	Gasoline	1991 cm³	218 hp	160 kW	350 N⋅m	Robotic	FWD
CLA200 2.0 DCT	Gasoline	1991 cm³	218 hp	160 kW	350 N⋅m	Robotic	AWD
CLA180CDI 1.5 DCT	Diesel	1461 cm³	109 hp	80 kW	240 N⋅m	Robotic	FWD
CLA180CDI 1.5 MT	Diesel	1461 cm³	109 hp	80 kW	260 N⋅m	Manual	FWD
CLA200CDI 1.8 DCT	Diesel	1796 cm³	136 hp	100 kW	300 N⋅m	Robotic	FWD
CLA180CDI 2.1 MT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Manual	FWD
CLA180CDI 2.1 DCT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Robotic	FWD
CLA180CDI 2.1 DCT	Diesel	2143 cm³	136 hp	100 kW	300 N⋅m	Robotic	AWD
CLA220CDI 2.1 DCT	Diesel	2143 cm³	170 hp	125 kW	350 N⋅m	Robotic	AWD
CLA220CDI 2.1 DCT	Diesel	2143 cm³	170 hp	125 kW	350 N⋅m	Robotic	FWD
CLA220CDI 2.1 DCT	Diesel	2143 cm³	177 hp	130 kW	350 N⋅m	Robotic	AWD
CLA220CDI 2.1 DCT	Diesel	2143 cm³	177 hp	130 kW	350 N⋅m	Robotic	FWD
CLA200 1.6 DCT	Gasoline	1595 cm³	156 hp	115 kW	250 N⋅m	Robotic	FWD
CLA180 1.6 MT	Gasoline	1595 cm³	122 hp	90 kW	200 N⋅m	Manual	FWD
CLA180 1.6 DCT	Gasoline	1595 cm³	122 hp	90 kW	200 N⋅m	Robotic	FWD
CLA200 1.6 MT	Gasoline	1595 cm³	156 hp	115 kW	250 N⋅m	Manual	FWD
CLA250 2.0 DCT	Gasoline	1991 cm³	211 hp	155 kW	350 N⋅m	Robotic	FWD

Mercedes CLA Dimensions

Estate 5-door — Mercedes CLA Dimensions

Estate 5-door Mercedes CLA Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight
CLA200 1.6 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1460 kg	1955 kg
CLA200 2.0 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1555 kg	2050 kg
CLA180 1.6 MT	4630 mm	1777 mm	1435 mm	2699 mm	1430 kg	1955 kg
CLA180 1.6 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1460 kg	1955 kg
CLA200 1.6 MT	4630 mm	1777 mm	1435 mm	2699 mm	1430 kg	1955 kg
CLA200 2.0 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1500 kg	1995 kg
CLA200 2.0 MT	4630 mm	1777 mm	1435 mm	2699 mm	1470 kg	1995 kg
CLA200 2.0 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1565 kg	2050 kg
CLA180CDI 1.5 MT	4630 mm	1777 mm	1435 mm	2699 mm	1465 kg	1990 kg
CLA180CDI 1.5 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1495 kg	1990 kg
CLA180CDI 2.1 MT	4630 mm	1777 mm	1435 mm	2699 mm	1530 kg	2050 kg
CLA180CDI 2.1 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1555 kg	2050 kg
CLA180CDI 2.1 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1530 kg	2100 kg
CLA220CDI 2.1 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1555 kg	2050 kg
CLA220CDI 2.1 DCT	4630 mm	1777 mm	1435 mm	2699 mm	1615 kg	2100 kg

Sedan — Mercedes CLA Dimensions

Sedan Mercedes CLA Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
CLA250 2.0 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1540 kg	2025 kg	117 mm
CLA200 1.6 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1430 kg	1915 kg	117 mm
CLA250 2.0 MT	4630 mm	1777 mm	1432 mm	2699 mm	1450 kg	1965 kg	117 mm
CLA200 2.0 MT	4630 mm	1777 mm	1432 mm	2699 mm	1460 kg	1965 kg	117 mm
CLA200 2.0 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1490 kg	1965 kg	117 mm
CLA200 2.0 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1490 kg	1965 kg	117 mm
CLA180CDI 1.5 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1475 kg	1955 kg	117 mm
CLA180CDI 1.5 MT	4630 mm	1777 mm	1432 mm	2699 mm	1450 kg	1955 kg	117 mm
CLA200CDI 1.8 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1505 kg	1985 kg	117 mm
CLA180CDI 2.1 MT	4630 mm	1777 mm	1432 mm	2699 mm	1500 kg	2005 kg	117 mm
CLA180CDI 2.1 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1525 kg	2005 kg	117 mm
CLA180CDI 2.1 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1580 kg	2060 kg	117 mm
CLA220CDI 2.1 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1580 kg	2060 kg	117 mm
CLA220CDI 2.1 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1525 kg	2005 kg	117 mm
CLA220CDI 2.1 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1580 kg	2060 kg	117 mm
CLA220CDI 2.1 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1525 kg	2005 kg	117 mm
CLA200 1.6 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1430 kg	1915 kg	117 mm
CLA180 1.6 MT	4630 mm	1777 mm	1432 mm	2699 mm	1390 kg	1850 kg	117 mm
CLA180 1.6 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1430 kg	1920 kg	117 mm
CLA200 1.6 MT	4630 mm	1777 mm	1432 mm	2699 mm	1395 kg	1920 kg	117 mm
CLA250 2.0 DCT	4630 mm	1777 mm	1432 mm	2699 mm	1480 kg	1965 kg	Not provided

Mercedes CLA Cargo Space

Estate 5-door — Mercedes CLA Cargo Space

Estate 5-door Mercedes CLA Cargo Space
Modification	Trunk volume min	Trunk volume max
CLA200 1.6 DCT	495 l	1354 l
CLA200 2.0 DCT	495 l	1354 l
CLA180 1.6 MT	495 l	1354 l
CLA180 1.6 DCT	495 l	1354 l
CLA200 1.6 MT	495 l	1354 l
CLA200 2.0 DCT	495 l	1354 l
CLA200 2.0 MT	495 l	1354 l
CLA200 2.0 DCT	495 l	1354 l
CLA180CDI 1.5 MT	495 l	1354 l
CLA180CDI 1.5 DCT	495 l	1354 l
CLA180CDI 2.1 MT	495 l	1354 l
CLA180CDI 2.1 DCT	495 l	1354 l
CLA180CDI 2.1 DCT	495 l	1354 l
CLA220CDI 2.1 DCT	495 l	1354 l
CLA220CDI 2.1 DCT	495 l	1354 l

Sedan — Mercedes CLA Cargo Space

Sedan Mercedes CLA Cargo Space
Modification	Trunk volume min
CLA250 2.0 DCT	470 l
CLA200 1.6 DCT	470 l
CLA250 2.0 MT	470 l
CLA200 2.0 MT	470 l
CLA200 2.0 DCT	470 l
CLA200 2.0 DCT	470 l
CLA180CDI 1.5 DCT	470 l
CLA180CDI 1.5 MT	470 l
CLA200CDI 1.8 DCT	470 l
CLA180CDI 2.1 MT	470 l
CLA180CDI 2.1 DCT	470 l
CLA180CDI 2.1 DCT	470 l
CLA220CDI 2.1 DCT	470 l
CLA220CDI 2.1 DCT	470 l
CLA220CDI 2.1 DCT	470 l
CLA220CDI 2.1 DCT	470 l
CLA200 1.6 DCT	470 l
CLA180 1.6 MT	470 l
CLA180 1.6 DCT	470 l
CLA200 1.6 MT	470 l
CLA250 2.0 DCT	470 l

Mercedes CLA Trims and Equipment

Mercedes CLA trim levels describe equipment choices alongside the powertrain specification. The gasoline, front-wheel-drive CLA180 1.6 DCT Sedan has configurations named SE and Urban. When choosing between them, check the individual car’s seats, infotainment and parking aids: the engine and transmission designation alone does not tell you which conveniences are fitted.

Mercedes CLA Trims and Equipment
Modification	Body	Equipment
CLA200 1.6 DCT	Estate 5-door	CLA 200 Special Series
CLA200 2.0 DCT	Estate 5-door	CLA 250 4Matic Special Series
CLA250 2.0 DCT	Sedan	CLA 250 4Matic Special Series
CLA200 1.6 DCT	Sedan	CLA 200 Special Series
CLA200 1.6 DCT	Sedan	SE
CLA200 1.6 DCT	Sedan	Urban
CLA180 1.6 MT	Sedan	SE
CLA180 1.6 MT	Sedan	Urban
CLA180 1.6 DCT	Sedan	SE
CLA180 1.6 DCT	Sedan	Urban
CLA180 1.6 DCT	Sedan	AMG
CLA200 1.6 MT	Sedan	Urban
CLA250 2.0 DCT	Sedan	Urban
CLA250 2.0 DCT	Sedan	AMG
