Mercedes A-Class Specs, Engines & Dimensions (2001–2004)

Mercedes A-Class Engines and Transmissions

Every Mercedes A-Class engine here is a compact four-cylinder driving the front wheels. Gasoline versions such as the A140 1.4 suit town use, while the A170 1.7 diesel favours economy on longer runs. The powertrain pairs with either a manual gearbox, as in the A140 1.4 MT, or an automatic transmission.

Hatchback 5-door — Mercedes A-Class Engines and Transmissions

Hatchback 5-door Mercedes A-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
A140 1.4 AT Long	Gasoline	1397 cm³	82 hp	60 kW	130 N⋅m	Automatic	FWD
A160 1.6 AT Long	Gasoline	1598 cm³	102 hp	75 kW	150 N⋅m	Automatic	FWD
A170 1.7 AT Long	Diesel	1689 cm³	95 hp	70 kW	180 N⋅m	Automatic	FWD
A190 1.9 AT Long	Gasoline	1898 cm³	125 hp	92 kW	180 N⋅m	Automatic	FWD

Mini 5-doors — Mercedes A-Class Engines and Transmissions

Mini 5-doors Mercedes A-Class Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
A140 1.4 MT	Gasoline	1397 cm³	82 hp	60 kW	130 N⋅m	Manual	FWD
A140 1.4 AT	Gasoline	1397 cm³	82 hp	60 kW	130 N⋅m	Automatic	FWD
A160 1.6 MT	Gasoline	1598 cm³	102 hp	75 kW	150 N⋅m	Manual	FWD
A210 2.1 MT	Gasoline	2084 cm³	140 hp	103 kW	205 N⋅m	Manual	FWD
A210 2.1 AT	Gasoline	2084 cm³	140 hp	103 kW	205 N⋅m	Automatic	FWD
A170 1.7 MT	Diesel	1689 cm³	75 hp	55 kW	160 N⋅m	Manual	FWD
A170 1.7 AT	Diesel	1689 cm³	75 hp	55 kW	160 N⋅m	Automatic	FWD
A170 1.7 AT	Diesel	1689 cm³	95 hp	70 kW	180 N⋅m	Automatic	FWD
A190 1.9 MT	Gasoline	1898 cm³	125 hp	92 kW	180 N⋅m	Manual	FWD
A190 1.9 AT	Gasoline	1898 cm³	125 hp	92 kW	180 N⋅m	Automatic	FWD
A160 1.6 AT	Gasoline	1598 cm³	102 hp	75 kW	150 N⋅m	Automatic	FWD
A170 1.7 MT	Diesel	1689 cm³	95 hp	70 kW	180 N⋅m	Manual	FWD

Mercedes A-Class Dimensions

Hatchback 5-door — Mercedes A-Class Dimensions

Hatchback 5-door Mercedes A-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
A140 1.4 AT Long	3776 mm	1719 mm	1589 mm	2593 mm	1060 kg	1580 kg	150 mm
A160 1.6 AT Long	3776 mm	1719 mm	1589 mm	2593 mm	1070 kg	1590 kg	125 mm
A170 1.7 AT Long	3776 mm	1719 mm	1589 mm	2593 mm	1115 kg	1635 kg	150 mm
A190 1.9 AT Long	3776 mm	1719 mm	1589 mm	2593 mm	1185 kg	1630 kg	150 mm

Mini 5-doors — Mercedes A-Class Dimensions

Mini 5-doors Mercedes A-Class Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
A140 1.4 MT	3606 mm	1719 mm	1575 mm	2423 mm	1035 kg	1490 kg	150 mm
A140 1.4 AT	3606 mm	1719 mm	1575 mm	2423 mm	1065 kg	1580 kg	150 mm
A160 1.6 MT	3606 mm	1719 mm	1575 mm	2423 mm	1135 kg	1500 kg	125 mm
A210 2.1 MT	3606 mm	1719 mm	1575 mm	2423 mm	1095 kg	1550 kg	150 mm
A210 2.1 AT	3606 mm	1719 mm	1575 mm	2423 mm	1125 kg	1640 kg	150 mm
A170 1.7 MT	3606 mm	1719 mm	1575 mm	2423 mm	1085 kg	1540 kg	150 mm
A170 1.7 AT	3606 mm	1719 mm	1575 mm	2423 mm	1085 kg	1540 kg	150 mm
A170 1.7 AT	3606 mm	1719 mm	1575 mm	2423 mm	1120 kg	1635 kg	150 mm
A190 1.9 MT	3606 mm	1719 mm	1575 mm	2423 mm	1185 kg	1630 kg	150 mm
A190 1.9 AT	3606 mm	1719 mm	1575 mm	2423 mm	1110 kg	1630 kg	150 mm
A160 1.6 AT	3606 mm	1719 mm	1575 mm	2423 mm	Not provided	1500 kg	125 mm
A170 1.7 MT	3606 mm	1719 mm	1575 mm	2423 mm	1090 kg	1545 kg	150 mm

Mercedes A-Class Cargo Space

Hatchback 5-door — Mercedes A-Class Cargo Space

Hatchback 5-door Mercedes A-Class Cargo Space
Modification	Trunk volume min	Trunk volume max
A140 1.4 AT Long	390 l	1930 l
A160 1.6 AT Long	390 l	1930 l
A170 1.7 AT Long	390 l	1930 l
A190 1.9 AT Long	390 l	1930 l

Mini 5-doors — Mercedes A-Class Cargo Space

Mini 5-doors Mercedes A-Class Cargo Space
Modification	Trunk volume min	Trunk volume max
A140 1.4 MT	390 l	1740 l
A140 1.4 AT	390 l	1740 l
A160 1.6 MT	390 l	1740 l
A210 2.1 MT	390 l	1740 l
A210 2.1 AT	390 l	1740 l
A170 1.7 MT	390 l	1740 l
A170 1.7 AT	390 l	1740 l
A170 1.7 AT	390 l	1740 l
A190 1.9 MT	390 l	1740 l
A190 1.9 AT	390 l	1740 l
A160 1.6 AT	390 l	1740 l
A170 1.7 MT	390 l	1740 l

Mercedes A-Class Trims and Equipment

Mercedes A-Class trim levels sit on top of the technical version rather than replacing it. The A190 1.9 AT in Mini 5-doors form, for example, carries the Standart equipment configuration: the same engine and automatic drivetrain, with features fixed when the car was originally ordered. Factory options and later additions mean two identical trims can still differ, so check each car's actual equipment.

Mercedes A-Class Trims and Equipment
Modification	Body	Equipment
A170 1.7 AT	Mini 5-doors	Standart
A190 1.9 AT	Mini 5-doors	Standart
A160 1.6 AT	Mini 5-doors	Standart
