Catalog / Mazda / 323F / 1 generation
Mazda 323F Engines and Transmissions
The Mazda 323F engine in these examples is a 1.8-liter gasoline unit matched to a manual transmission. Liftback versions such as the 1.8 MT in front-wheel drive and the 1.8 MT with all-wheel drive share that powertrain, so you pick the drivetrain that suits everyday grip and simplicity.
Liftback — Mazda 323F Engines and Transmissions
Liftback Mazda 323F Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.6 MT Gasoline 1597 cm³ 84 hp 61 kW 125 N⋅m Manual FWD 1.6 MT Gasoline 1597 cm³ 88 hp 64 kW 125 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 88 hp 64 kW 125 N⋅m Automatic FWD 1.8 MT Gasoline 1839 cm³ 103 hp 75 kW 160 N⋅m Manual AWD 1.8 MT Gasoline 1839 cm³ 128 hp 94 kW 165 N⋅m Manual FWD 1.6 AT Gasoline 1597 cm³ 84 hp 61 kW 125 N⋅m Automatic FWD
Mazda 323F Dimensions
Liftback — Mazda 323F Dimensions
Liftback Mazda 323F Dimensions Modification Length Width Height Wheelbase Curb weight
1.6 MT 4260 mm 1675 mm 1380 mm 2500 mm 990 kg 1.6 MT 4260 mm 1675 mm 1380 mm 2500 mm 990 kg 1.6 AT 4260 mm 1675 mm 1380 mm 2500 mm 990 kg 1.8 MT 4260 mm 1675 mm 1380 mm 2500 mm 1120 kg 1.8 MT 4260 mm 1675 mm 1380 mm 2500 mm 1120 kg 1.6 AT 4260 mm 1675 mm 1380 mm 2500 mm 990 kg
Mazda 323F Cargo Space
Liftback — Mazda 323F Cargo Space
Mazda 323F Trims and Equipment
Mazda 323F Trims and Equipment Modification Body Equipment
1.6 AT Liftback GLX
