Catalog / Mazda / 323 Lantis / 2 generation
Mazda 323 Lantis Engines and Transmissions
Examples of Mazda 323 Lantis engine choices include the gasoline 1.1 MT and 1.3 MT sedans, both pairing a manual transmission with front-wheel drive. The 1.1 MT estate uses that same drivetrain layout. With these manual versions, you choose when to downshift for hills or overtaking, particularly when carrying passengers and luggage.
Sedan — Mazda 323 Lantis Engines and Transmissions
Sedan Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.1 MT Gasoline 1100 cm³ 54 hp 40 kW Not provided Manual FWD 1.3 MT Gasoline 1299 cm³ 60 hp 44 kW 103 N⋅m Manual FWD 1.5 MT Gasoline 1498 cm³ 75 hp 55 kW 116 N⋅m Manual FWD 1.5 MT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Manual FWD
Estate 5-door — Mazda 323 Lantis Engines and Transmissions
Estate 5-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.1 MT Gasoline 1100 cm³ 54 hp 40 kW Not provided Manual FWD 1.3 MT Gasoline 1299 cm³ 60 hp 44 kW 103 N⋅m Manual FWD 1.5 MT Gasoline 1490 cm³ 86 hp 63 kW 120 N⋅m Manual FWD 1.5 MT Gasoline 1490 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 1.5 MT Gasoline 1498 cm³ 75 hp 55 kW 116 N⋅m Manual FWD
Hatchback 3-door — Mazda 323 Lantis Engines and Transmissions
Hatchback 3-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.1 MT Gasoline 1100 cm³ 54 hp 40 kW Not provided Manual FWD 1.5 MT Gasoline 1498 cm³ 75 hp 55 kW 116 N⋅m Manual FWD 1.3 MT Gasoline 1299 cm³ 60 hp 44 kW 103 N⋅m Manual FWD 1.5 MT Gasoline 1489 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 1.5 MT Gasoline 1500 cm³ 86 hp 63 kW Not provided Manual FWD
Hatchback 5-door — Mazda 323 Lantis Engines and Transmissions
Hatchback 5-door Mazda 323 Lantis Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive
1.1 MT Gasoline 1100 cm³ 54 hp 40 kW Not provided Manual FWD 1.3 MT Gasoline 1299 cm³ 60 hp 44 kW 103 N⋅m Manual FWD 1.5 MT Gasoline 1490 cm³ 86 hp 63 kW 120 N⋅m Manual FWD 1.5 MT Gasoline 1490 cm³ 88 hp 65 kW 132 N⋅m Manual FWD 1.5 MT Gasoline 1498 cm³ 75 hp 55 kW 116 N⋅m Manual FWD
Mazda 323 Lantis Dimensions
Sedan — Mazda 323 Lantis Dimensions
Sedan Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
1.1 MT 4060 mm 1630 mm 1380 mm 2400 mm 936 kg 150 mm 1.3 MT 4060 mm 1630 mm 1380 mm 2400 mm 936 kg 150 mm 1.5 MT 4060 mm 1630 mm 1380 mm 2400 mm 936 kg 150 mm 1.5 MT 4060 mm 1630 mm 1380 mm 2400 mm Not provided 150 mm
Estate 5-door — Mazda 323 Lantis Dimensions
Estate 5-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.1 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg Not provided 150 mm 1.3 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg Not provided 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 870 kg 1360 kg 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 870 kg 1360 kg 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg Not provided 150 mm
Hatchback 3-door — Mazda 323 Lantis Dimensions
Hatchback 3-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum
1.1 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg 150 mm 1.3 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm Not provided 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm Not provided 150 mm
Hatchback 5-door — Mazda 323 Lantis Dimensions
Hatchback 5-door Mazda 323 Lantis Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum
1.1 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg Not provided 150 mm 1.3 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg Not provided 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 870 kg 1360 kg 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 870 kg 1360 kg 150 mm 1.5 MT 3960 mm 1630 mm 1380 mm 2400 mm 936 kg Not provided 150 mm
