Mazda 3 Engines and Transmissions
Mazda 3 engine choices cover everyday needs with both gasoline and diesel options. A 1.6-liter gasoline pairs with a manual or automatic transmission, while a 1.5-liter diesel comes as a manual. All drive the front wheels, balancing economy and responsiveness.
Sedan — Mazda 3 Engines and Transmissions
Sedan Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 AT Gasoline 1598 cm³ 104 hp 77 kW 144 N⋅m Automatic FWD 1.5 MT Gasoline 1496 cm³ 100 hp 74 kW 150 N⋅m Manual FWD 1.5 MT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 104 hp 77 kW 144 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 155 hp 115 kW 203 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 155 hp 115 kW 203 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Manual FWD 2.5 AT Gasoline 2488 cm³ 184 hp 137 kW 251 N⋅m Automatic FWD 2.5 MT Gasoline 2488 cm³ 184 hp 137 kW 251 N⋅m Manual FWD 1.5 MT Diesel 1499 cm³ 105 hp 77 kW 220 N⋅m Manual FWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Automatic FWD
Hatchback 5-door — Mazda 3 Engines and Transmissions
Hatchback 5-door Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Diesel 1499 cm³ 105 hp 77 kW 220 N⋅m Manual FWD 1.5 MT Gasoline 1496 cm³ 100 hp 74 kW 150 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 104 hp 77 kW 144 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 104 hp 77 kW 144 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 210 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 155 hp 115 kW 203 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 155 hp 115 kW 203 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Manual FWD 2.5 AT Gasoline 2488 cm³ 184 hp 137 kW 251 N⋅m Automatic FWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Automatic FWD
Mazda 3 Dimensions
Sedan — Mazda 3 Dimensions
Sedan Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.6 AT 4585 mm 1795 mm 1450 mm 2700 mm 1190 kg 1775 kg 160 mm 1.5 MT 4585 mm 1795 mm 1450 mm 2700 mm 1190 kg Not provided 155 mm 1.5 MT 4585 mm 1795 mm 1450 mm 2700 mm 1190 kg 1835 kg 155 mm 1.6 MT 4585 mm 1795 mm 1450 mm 2700 mm 1190 kg 1745 kg 160 mm 2.0 MT 4585 mm 1795 mm 1450 mm 2700 mm 1275 kg 1815 kg 155 mm 2.0 AT 4585 mm 1795 mm 1450 mm 2700 mm 1310 kg 1835 kg 155 mm 2.0 AT 4585 mm 1795 mm 1450 mm 2700 mm 1235 kg 1835 kg 155 mm 2.0 AT 4585 mm 1795 mm 1450 mm 2700 mm 1300 kg Not provided 155 mm 2.0 MT 4585 mm 1795 mm 1450 mm 2700 mm 1270 kg Not provided 155 mm 2.0 MT 4585 mm 1795 mm 1450 mm 2700 mm 1295 kg Not provided 155 mm 2.5 AT 4585 mm 1795 mm 1450 mm 2700 mm 1353 kg Not provided 155 mm 2.5 MT 4585 mm 1795 mm 1450 mm 2700 mm 1353 kg Not provided 155 mm 1.5 MT 4585 mm 1795 mm 1450 mm 2700 mm Not provided Not provided 155 mm 2.2 MT 4585 mm 1795 mm 1450 mm 2700 mm 1385 kg 1910 kg 155 mm 2.2 AT 4585 mm 1795 mm 1450 mm 2700 mm 1405 kg Not provided 155 mm 1.5 AT 4585 mm 1795 mm 1450 mm 2700 mm 1190 kg 1835 kg 155 mm 2.0 AT 4585 mm 1795 mm 1450 mm 2700 mm 1330 kg 1860 kg 155 mm
Hatchback 5-door — Mazda 3 Dimensions
Hatchback 5-door Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.5 MT 4465 mm 1795 mm 1450 mm 2700 mm Not provided Not provided 155 mm 1.5 MT 4465 mm 1795 mm 1450 mm 2700 mm 1190 kg 1800 kg 155 mm 1.6 MT 4465 mm 1795 mm 1450 mm 2700 mm 1190 kg 1745 kg 160 mm 1.6 AT 4465 mm 1795 mm 1450 mm 2700 mm 1190 kg 1775 kg 160 mm 2.0 MT 4465 mm 1795 mm 1450 mm 2700 mm 1280 kg 1815 kg 155 mm 2.0 AT 4465 mm 1795 mm 1450 mm 2700 mm 1315 kg 1835 kg 155 mm 2.0 AT 4465 mm 1795 mm 1450 mm 2700 mm 1320 kg 1835 kg 155 mm 2.0 MT 4465 mm 1795 mm 1450 mm 2700 mm 1277 kg Not provided 155 mm 2.0 AT 4465 mm 1795 mm 1450 mm 2700 mm 1303 kg Not provided 155 mm 2.0 MT 4465 mm 1795 mm 1450 mm 2700 mm 1295 kg 1815 kg 155 mm 2.5 AT 4465 mm 1795 mm 1450 mm 2700 mm 1362 kg Not provided 155 mm 2.2 MT 4465 mm 1795 mm 1450 mm 2700 mm 1395 kg 1910 kg 155 mm 2.2 AT 4465 mm 1795 mm 1450 mm 2700 mm 1405 kg 1930 kg 155 mm 1.5 AT 4465 mm 1795 mm 1450 mm 2700 mm 1190 kg 1835 kg 155 mm 2.0 AT 4465 mm 1795 mm 1450 mm 2700 mm 1330 kg 1860 kg 155 mm
Mazda 3 Cargo Space
Sedan — Mazda 3 Cargo Space
Hatchback 5-door — Mazda 3 Cargo Space
Mazda 3 Trims and Equipment
Mazda 3 trim levels tailor the experience beyond the powertrain. For example, the 1.5 AT sedan is offered in Exclusive and Active Plus configurations, each adding distinct comfort and convenience features. These trims allow buyers to match equipment to their priorities.
