Mazda 3 Engines and Transmissions
The Mazda 3 engine lineup balances efficiency and everyday usability. A 1.6 gasoline automatic suits easy city driving, while a 1.5 gasoline manual provides a more engaged feel. A 1.5 diesel manual delivers strong torque for long-distance fuel economy, all paired with front-wheel drive.
Sedan — Mazda 3 Engines and Transmissions
Sedan Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 AT Gasoline 1598 cm³ 104 hp 77 kW 144 N⋅m Automatic FWD 1.5 MT Gasoline 1496 cm³ 100 hp 74 kW 150 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 155 hp 115 kW 203 N⋅m Manual FWD 2.5 AT Gasoline 2488 cm³ 184 hp 137 kW 251 N⋅m Automatic FWD 2.5 MT Gasoline 2488 cm³ 184 hp 137 kW 251 N⋅m Manual FWD 1.5 MT Diesel 1499 cm³ 105 hp 77 kW 270 N⋅m Manual FWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 165 hp 121 kW 203 N⋅m Automatic FWD
Hatchback 5-door — Mazda 3 Engines and Transmissions
Hatchback 5-door Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.5 MT Gasoline 1496 cm³ 100 hp 74 kW 150 N⋅m Manual FWD 2.0 MT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 120 hp 88 kW 210 N⋅m Automatic FWD 2.0 MT Gasoline 1998 cm³ 165 hp 121 kW 210 N⋅m Manual FWD 1.5 MT Diesel 1499 cm³ 105 hp 77 kW 270 N⋅m Manual FWD 1.5 AT Diesel 1499 cm³ 105 hp 77 kW 270 N⋅m Automatic FWD 2.2 MT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Manual FWD 2.2 AT Diesel 2191 cm³ 150 hp 110 kW 380 N⋅m Automatic FWD 1.5 AT Gasoline 1496 cm³ 120 hp 88 kW 150 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 165 hp 121 kW 203 N⋅m Automatic FWD
Mazda 3 Dimensions
Sedan — Mazda 3 Dimensions
Sedan Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.6 AT 4580 mm 1795 mm 1450 mm 2700 mm 1296 kg 1775 kg 155 mm 1.5 MT 4580 mm 1795 mm 1450 mm 2700 mm 1185 kg 1800 kg 155 mm 2.0 AT 4580 mm 1795 mm 1450 mm 2700 mm 1240 kg 1835 kg 155 mm 2.0 MT 4580 mm 1795 mm 1450 mm 2700 mm 1205 kg 1815 kg 155 mm 2.0 MT 4580 mm 1795 mm 1450 mm 2700 mm 1270 kg Not provided 155 mm 2.5 AT 4580 mm 1795 mm 1450 mm 2700 mm 1353 kg Not provided 155 mm 2.5 MT 4580 mm 1795 mm 1450 mm 2700 mm 1353 kg Not provided 155 mm 1.5 MT 4580 mm 1795 mm 1450 mm 2700 mm 1265 kg 1870 kg 155 mm 2.2 MT 4580 mm 1795 mm 1450 mm 2700 mm 1320 kg 1910 kg 155 mm 1.5 AT 4580 mm 1795 mm 1450 mm 2700 mm 1296 kg 1835 kg 155 mm 2.0 AT 4580 mm 1795 mm 1450 mm 2700 mm 1300 kg 1860 kg 155 mm
Hatchback 5-door — Mazda 3 Dimensions
Hatchback 5-door Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.5 MT 4470 mm 1795 mm 1450 mm 2700 mm 1185 kg 1800 kg 155 mm 2.0 MT 4470 mm 1795 mm 1450 mm 2700 mm 1205 kg 1815 kg 155 mm 2.0 AT 4470 mm 1795 mm 1450 mm 2700 mm 1245 kg 1835 kg 155 mm 2.0 MT 4470 mm 1795 mm 1450 mm 2700 mm 1230 kg 1305 kg 155 mm 1.5 MT 4470 mm 1795 mm 1450 mm 2700 mm 1260 kg 1870 kg 155 mm 1.5 AT 4470 mm 1795 mm 1450 mm 2700 mm 1285 kg 1360 kg 155 mm 2.2 MT 4470 mm 1795 mm 1450 mm 2700 mm 1320 kg 1910 kg 155 mm 2.2 AT 4470 mm 1795 mm 1450 mm 2700 mm 1335 kg 1930 kg 155 mm 1.5 AT 4470 mm 1795 mm 1450 mm 2700 mm 1302 kg 1835 kg 155 mm 2.0 AT 4470 mm 1795 mm 1450 mm 2700 mm 1334 kg 1860 kg 155 mm
Mazda 3 Cargo Space
Sedan — Mazda 3 Cargo Space
Hatchback 5-door — Mazda 3 Cargo Space
Mazda 3 Trims and Equipment
Mazda 3 trim levels add convenience and style without overcomplicating the range. The Active Plus configuration focuses on essential comfort and connectivity, while Exclusive enhances the cabin with premium touches and advanced features, making the sedan feel more upscale.
