Catalog / Mazda / 3 / 1 generation
Mazda 3 Engines and Transmissions
Mazda 3 engine options cover both gasoline and diesel needs. A 1.6-liter gasoline pairs with a manual gearbox, while a 2.0-liter gasoline comes with an automatic. A 1.6-liter diesel with a manual transmission offers strong low-end torque for efficient highway driving.
Sedan — Mazda 3 Engines and Transmissions
Sedan Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.6 MT Diesel 1560 cm³ 110 hp 80 kW 240 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Manual FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 186 N⋅m Automatic FWD 2.0 MT Gasoline 1999 cm³ 150 hp 110 kW 187 N⋅m Manual FWD 2.3 MT Gasoline 2261 cm³ 156 hp 115 kW 203 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 156 hp 115 kW 203 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 160 hp 119 kW 203 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 160 hp 119 kW 203 N⋅m Automatic FWD 1.6 AT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Automatic FWD
Hatchback 5-door — Mazda 3 Engines and Transmissions
Hatchback 5-door Mazda 3 Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 1.4 MT Gasoline 1348 cm³ 84 hp 62 kW 122 N⋅m Manual FWD 1.4 MT Gasoline 1388 cm³ 80 hp 59 kW 124 N⋅m Manual FWD 1.6 MT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Manual FWD 2.0 MT Gasoline 1999 cm³ 150 hp 110 kW 186 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 160 hp 118 kW 203 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 160 hp 118 kW 203 N⋅m Manual FWD 1.6 MT Diesel 1560 cm³ 110 hp 81 kW 245 N⋅m Manual FWD 1.6 AT Gasoline 1598 cm³ 105 hp 77 kW 145 N⋅m Automatic FWD 2.0 AT Gasoline 1998 cm³ 150 hp 110 kW 186 N⋅m Automatic FWD
Mazda 3 Dimensions
Sedan — Mazda 3 Dimensions
Sedan Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.6 MT 4490 mm 1755 mm 1465 mm 2640 mm 1265 kg 1770 kg 160 mm 1.6 MT 4490 mm 1755 mm 1465 mm 2640 mm 1170 kg 1675 kg 160 mm 2.0 AT 4490 mm 1755 mm 1465 mm 2640 mm Not provided 1725 kg 160 mm 2.0 MT 4490 mm 1755 mm 1465 mm 2640 mm 1220 kg 1725 kg 160 mm 2.3 MT 4490 mm 1755 mm 1465 mm 2640 mm 1220 kg 1725 kg 160 mm 2.3 AT 4490 mm 1755 mm 1465 mm 2640 mm Not provided Not provided 160 mm 2.3 MT 4490 mm 1755 mm 1465 mm 2640 mm 1253 kg 1732 kg 160 mm 2.3 AT 4490 mm 1755 mm 1465 mm 2640 mm 1273 kg 1760 kg 160 mm 1.6 AT 4490 mm 1755 mm 1465 mm 2640 mm 1195 kg 1700 kg 135 mm
Hatchback 5-door — Mazda 3 Dimensions
Hatchback 5-door Mazda 3 Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 1.4 MT 4420 mm 1755 mm 1465 mm 2640 mm 1180 kg 1695 kg 160 mm 1.4 MT 4420 mm 1755 mm 1465 mm 2640 mm 1185 kg 1695 kg 140 mm 1.6 MT 4420 mm 1755 mm 1465 mm 2640 mm 1190 kg 1695 kg 140 mm 2.0 MT 4420 mm 1755 mm 1465 mm 2640 mm 1240 kg 1745 kg 140 mm 2.3 AT 4420 mm 1755 mm 1465 mm 2640 mm 1282 kg Not provided 160 mm 2.3 MT 4420 mm 1755 mm 1465 mm 2640 mm 1282 kg Not provided 160 mm 1.6 MT 4420 mm 1755 mm 1465 mm 2640 mm 1280 kg 1785 kg 140 mm 1.6 AT 4420 mm 1755 mm 1465 mm 2640 mm 1260 kg 1695 kg 160 mm 2.0 AT 4420 mm 1755 mm 1465 mm 2640 mm Not provided 1745 kg 160 mm
Mazda 3 Cargo Space
Sedan — Mazda 3 Cargo Space
Hatchback 5-door — Mazda 3 Cargo Space
Mazda 3 Trims and Equipment
Mazda 3 trim levels, such as Active and Comfort, build on technical versions like the 1.6 AT. Active focuses on essential comfort, while Comfort adds upgraded upholstery and convenience features, allowing buyers to balance equipment with budget.
