Land Rover Range Rover Specs, Engines & Dimensions (2012–2017)

Land Rover Range Rover Engines and Transmissions

You will find a Land Rover Range Rover engine in this generation with an automatic transmission and all-wheel drive. The 3.0 AT SUV 5-doors is offered as gasoline or hybrid, while the 4.4 AT SUV Long is a diesel example of that powertrain layout.

SUV 5-doors — Land Rover Range Rover Engines and Transmissions

SUV 5-doors Land Rover Range Rover Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Gasoline	2995 cm³	340 hp	250 kW	450 N⋅m	Automatic	AWD
5.0 AT	Gasoline	4999 cm³	550 hp	405 kW	680 N⋅m	Automatic	AWD
5.0 AT	Gasoline	4999 cm³	375 hp	276 kW	510 N⋅m	Automatic	AWD
3.0 AT	Hybrid	2993 cm³	292 hp	215 kW	700 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	248 hp	182 kW	600 N⋅m	Automatic	AWD
4.4 AT	Diesel	4367 cm³	339 hp	250 kW	700 N⋅m	Automatic	AWD
5.0 AT	Gasoline	4999 cm³	510 hp	375 kW	625 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	248 hp	182 kW	600 N⋅m	Automatic	AWD
4.4 AT	Diesel	4367 cm³	339 hp	250 kW	700 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	258 hp	190 kW	600 N⋅m	Automatic	AWD

SUV Long — Land Rover Range Rover Engines and Transmissions

SUV Long Land Rover Range Rover Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
4.4 AT	Diesel	4367 cm³	339 hp	250 kW	700 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	258 hp	190 kW	600 N⋅m	Automatic	AWD
5.0 AT	Gasoline	4999 cm³	510 hp	375 kW	625 N⋅m	Automatic	AWD

Land Rover Range Rover Dimensions

SUV 5-doors — Land Rover Range Rover Dimensions

SUV 5-doors Land Rover Range Rover Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
3.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2144 kg	2750 kg	278 mm	Not provided
5.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2330 kg	3150 kg	220 mm	295 mm
5.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2200 kg	3150 kg	220 mm	295 mm
3.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2394 kg	Not provided	220 mm	Not provided
3.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2160 kg	3000 kg	220 mm	295 mm
4.4 AT	4999 mm	1983 mm	1840 mm	2922 mm	2360 kg	3200 kg	220 mm	295 mm
5.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2330 kg	3150 kg	220 mm	295 mm
3.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2160 kg	3000 kg	220 mm	295 mm
4.4 AT	4999 mm	1983 mm	1840 mm	2922 mm	2360 kg	3200 kg	220 mm	295 mm
3.0 AT	4999 mm	1983 mm	1840 mm	2922 mm	2160 kg	3200 kg	220 mm	295 mm

SUV Long — Land Rover Range Rover Dimensions

SUV Long Land Rover Range Rover Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
4.4 AT	5199 mm	1983 mm	1840 mm	3120 mm	2360 kg	3200 kg	220 mm	295 mm
3.0 AT	5199 mm	1983 mm	1840 mm	3120 mm	2160 kg	3200 kg	220 mm	295 mm
5.0 AT	5199 mm	1983 mm	1840 mm	3120 mm	2413 kg	Not provided	220 mm	295 mm

Land Rover Range Rover Cargo Space

SUV 5-doors — Land Rover Range Rover Cargo Space

SUV 5-doors Land Rover Range Rover Cargo Space
Modification	Trunk volume min	Trunk volume max
3.0 AT	909 l	2030 l
5.0 AT	909 l	2030 l
5.0 AT	909 l	2030 l
3.0 AT	909 l	2030 l
3.0 AT	909 l	2030 l
4.4 AT	909 l	2030 l
5.0 AT	909 l	2030 l
3.0 AT	909 l	2030 l
4.4 AT	909 l	2030 l
3.0 AT	909 l	2030 l

SUV Long — Land Rover Range Rover Cargo Space

SUV Long Land Rover Range Rover Cargo Space
Modification	Trunk volume min	Trunk volume max
4.4 AT	909 l	2030 l
3.0 AT	909 l	2030 l
5.0 AT	909 l	2030 l

Land Rover Range Rover Trims and Equipment

Land Rover Range Rover trim levels sit on a named technical version rather than replacing it. The 3.0 AT SUV 5-doors gasoline automatic all-wheel drive example has Vogue as an equipment configuration. You keep that same drivetrain, while the trim shapes how the cabin is finished around you.

Land Rover Range Rover Trims and Equipment
Modification	Body	Equipment
3.0 AT	SUV 5-doors	Vogue
5.0 AT	SUV 5-doors	SVAutobiography
3.0 AT	SUV 5-doors	Vogue
5.0 AT	SUV 5-doors	Vogue
5.0 AT	SUV 5-doors	Autobiography
3.0 AT	SUV 5-doors	HSE
3.0 AT	SUV 5-doors	Vogue
3.0 AT	SUV 5-doors	Vogue SE
4.4 AT	SUV 5-doors	Autobiography
5.0 AT	SUV Long	Autobiography

Land Rover Range Rover Specs, Engines & Dimensions (2012–2017) — Fourth Generation
