Land Rover Range Rover Specs, Engines & Dimensions (2017–2022) — Fourth Generation Restyling

The Fourth Generation Restyling Land Rover Range Rover is offered as SUV 3-doors, SUV 5-doors and SUV Long. You pick the body that matches how you use the cabin and how much space you need.

← All Land Rover models

Land Rover Range Rover Engines and Transmissions

A Land Rover Range Rover engine in this restyling can be petrol, diesel or hybrid, and the powertrain is always automatic with all-wheel drive. Examples include the P565 5.0 AT gasoline SUV 3-doors, plus the 2.0 AT hybrid and D350 3.0 AT diesel in the five-door body.

SUV 3-doors — Land Rover Range Rover Engines and Transmissions

SUV 3-doors Land Rover Range Rover Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
P565 5.0 AT	Gasoline	4999 cm³	565 hp	416 kW	700 N⋅m	Automatic	AWD

SUV 5-doors — Land Rover Range Rover Engines and Transmissions

SUV 5-doors Land Rover Range Rover Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
4.4 AT	Diesel	4367 cm³	339 hp	250 kW	740 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	258 hp	190 kW	600 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	275 hp	202 kW	625 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2995 cm³	340 hp	250 kW	450 N⋅m	Automatic	AWD
2.0 AT	Hybrid	1997 cm³	300 hp	221 kW	640 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	249 hp	183 kW	500 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	258 hp	190 kW	600 N⋅m	Automatic	AWD
3.0 AT	Diesel	2993 cm³	275 hp	202 kW	625 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2995 cm³	380 hp	280 kW	450 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2996 cm³	400 hp	294 kW	550 N⋅m	Automatic	AWD
3.0 AT	Gasoline	2996 cm³	360 hp	265 kW	495 N⋅m	Automatic	AWD
D350 3.0 AT	Diesel	2997 cm³	350 hp	257 kW	700 N⋅m	Automatic	AWD
4.4 AT	Diesel	4367 cm³	339 hp	250 kW	740 N⋅m	Automatic	AWD
P525 5.0 AT	Gasoline	4999 cm³	525 hp	386 kW	625 N⋅m	Automatic	AWD
P565 5.0 AT	Gasoline	4999 cm³	565 hp	416 kW	700 N⋅m	Automatic	AWD
P400e 2.0 AT	Plug-in	1997 cm³	404 hp	297 kW	640 N⋅m	Automatic	AWD

SUV Long — Land Rover Range Rover Engines and Transmissions

SUV Long Land Rover Range Rover Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
3.0 AT	Diesel	2993 cm³	249 hp	183 kW	500 N⋅m	Automatic	AWD
P565 5.0 AT	Gasoline	4999 cm³	565 hp	416 kW	700 N⋅m	Automatic	AWD
P400e 2.0 AT	Plug-in	1997 cm³	404 hp	297 kW	640 N⋅m	Automatic	AWD
P525 5.0 AT	Gasoline	4999 cm³	525 hp	386 kW	625 N⋅m	Automatic	AWD
4.4 AT	Diesel	4367 cm³	339 hp	250 kW	740 N⋅m	Automatic	AWD

Land Rover Range Rover Dimensions

SUV 3-doors — Land Rover Range Rover Dimensions

SUV 3-doors Land Rover Range Rover Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
P565 5.0 AT	5013 mm	2073 mm	1794 mm	2922 mm	2497 kg	3160 kg	220 mm	297 mm

SUV 5-doors — Land Rover Range Rover Dimensions

SUV 5-doors Land Rover Range Rover Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
4.4 AT	5000 mm	2073 mm	1869 mm	2925 mm	2592 kg	3340 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2387 kg	3170 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2466 kg	3170 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2388 kg	3120 kg	220 mm	Not provided
2.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2603 kg	3250 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2249 kg	3100 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2249 kg	3100 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2328 kg	3130 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2256 kg	3070 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2342 kg	3140 kg	220 mm	Not provided
3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2342 kg	3140 kg	220 mm	Not provided
D350 3.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2350 kg	3150 kg	220 mm	297 mm
4.4 AT	5000 mm	2073 mm	1869 mm	2925 mm	2504 kg	3290 kg	220 mm	Not provided
P525 5.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2383 kg	3160 kg	220 mm	Not provided
P565 5.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2497 kg	3160 kg	220 mm	297 mm
P400e 2.0 AT	5000 mm	2073 mm	1869 mm	2925 mm	2509 kg	3210 kg	220 mm	Not provided

SUV Long — Land Rover Range Rover Dimensions

SUV Long Land Rover Range Rover Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum	Ground clearance, maximum
3.0 AT	5200 mm	2073 mm	1869 mm	3122 mm	2466 kg	3170 kg	220 mm	Not provided
P565 5.0 AT	5200 mm	2073 mm	1869 mm	3122 mm	2673 kg	3200 kg	220 mm	297 mm
P400e 2.0 AT	5200 mm	2073 mm	1869 mm	3122 mm	2671 kg	3250 kg	220 mm	Not provided
P525 5.0 AT	5200 mm	2073 mm	1869 mm	3122 mm	2518 kg	3200 kg	220 mm	Not provided
4.4 AT	5200 mm	2073 mm	1869 mm	3122 mm	2583 kg	3340 kg	220 mm	Not provided

Land Rover Range Rover Cargo Space

SUV 3-doors — Land Rover Range Rover Cargo Space

SUV 3-doors Land Rover Range Rover Cargo Space
Modification	Trunk volume min	Trunk volume max
P565 5.0 AT	900 l	2030 l

SUV 5-doors — Land Rover Range Rover Cargo Space

SUV 5-doors Land Rover Range Rover Cargo Space
Modification	Trunk volume min	Trunk volume max
4.4 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
2.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
3.0 AT	900 l	2030 l
D350 3.0 AT	900 l	2030 l
4.4 AT	900 l	2030 l
P525 5.0 AT	900 l	2030 l
P565 5.0 AT	900 l	2030 l
P400e 2.0 AT	900 l	2030 l

SUV Long — Land Rover Range Rover Cargo Space

SUV Long Land Rover Range Rover Cargo Space
Modification	Trunk volume min	Trunk volume max
3.0 AT	900 l	2030 l
P565 5.0 AT	900 l	2030 l
P400e 2.0 AT	900 l	2030 l
P525 5.0 AT	900 l	2030 l
4.4 AT	900 l	2030 l

Land Rover Range Rover Trims and Equipment

Land Rover Range Rover trim levels sit on a technical version rather than replacing it. On the P400e 2.0 AT plug-in hybrid SUV 5-doors, Vogue and Autobiography change cabin finish and equipment while the automatic all-wheel-drive hardware stays the same.

Land Rover Range Rover Trims and Equipment
Modification	Body	Equipment
4.4 AT	SUV 5-doors	Vogue SE
4.4 AT	SUV 5-doors	Autobiography Black
4.4 AT	SUV 5-doors	SVAutobiography Dynamic
3.0 AT	SUV 5-doors	HSE
3.0 AT	SUV 5-doors	Vogue
3.0 AT	SUV 5-doors	Vogue SE
D350 3.0 AT	SUV 5-doors	Vogue
D350 3.0 AT	SUV 5-doors	Autobiography
D350 3.0 AT	SUV 5-doors	Vogue
4.4 AT	SUV 5-doors	Vogue
4.4 AT	SUV 5-doors	Autobiography
4.4 AT	SUV 5-doors	HSE
4.4 AT	SUV 5-doors	Autobiography Black
P525 5.0 AT	SUV 5-doors	Vogue
P525 5.0 AT	SUV 5-doors	Autobiography
P525 5.0 AT	SUV 5-doors	HSE
P525 5.0 AT	SUV 5-doors	Autobiography Black
P565 5.0 AT	SUV 5-doors	SVAutobiography Dynamic
P400e 2.0 AT	SUV 5-doors	Vogue
P400e 2.0 AT	SUV 5-doors	Autobiography
P400e 2.0 AT	SUV 5-doors	HSE
P400e 2.0 AT	SUV 5-doors	Autobiography Black
P400e 2.0 AT	SUV 5-doors	HSE Dynamic
P400e 2.0 AT	SUV Long	Autobiography
P400e 2.0 AT	SUV Long	Autobiography SV
P525 5.0 AT	SUV Long	Autobiography
4.4 AT	SUV Long	Vogue

Land Rover Range Rover Battery, Range, Charging

Land Rover Range Rover battery capacity on the plug-in hybrid is a lithium-ion pack you recharge for short electric trips before the petrol engine joins in. Both the P400e 2.0 AT SUV 5-doors and the P400e 2.0 AT SUV Long use that battery with automatic all-wheel drive.

SUV 5-doors — Land Rover Range Rover Battery, Range, Charging

SUV 5-doors Land Rover Range Rover Battery, Range, Charging
Modification	Battery power	Battery type	Driving range, maximum	Full charge home	Full public charging time
D350 3.0 AT	Not provided	Lithium-ion batterie	Not provided	Not provided	Not provided
P400e 2.0 AT	13 kWh	Lithium-ion batterie	40 km	450 min	165 min

SUV Long — Land Rover Range Rover Battery, Range, Charging

SUV Long Land Rover Range Rover Battery, Range, Charging
Modification	Battery power	Battery type	Driving range, maximum	Full charge home	Full public charging time
P400e 2.0 AT	13 kWh	Lithium-ion batterie	40 km	450 min	165 min
