Kia Rio Specs, Engines & Dimensions (2011–2015)

Kia Rio Engines and Transmissions

A Kia Rio engine here is a 1.4-litre unit; the powertrain mixes gasoline or diesel with automatic or manual transmission. The 1.4 AT Sedan pairs gasoline with an automatic and front-wheel drive. 1.4 MT examples include a gasoline Sedan and a diesel Hatchback 5-door, both manual with the same drivetrain.

Sedan — Kia Rio Engines and Transmissions

Sedan Kia Rio Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.6 AT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Manual	FWD
1.6 MT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Manual	FWD
1.6 AT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Automatic	FWD
1.4 AT	Gasoline	1396 cm³	109 hp	80 kW	135 N⋅m	Automatic	FWD
1.4 MT	Gasoline	1396 cm³	109 hp	80 kW	135 N⋅m	Manual	FWD

Hatchback 5-door — Kia Rio Engines and Transmissions

Hatchback 5-door Kia Rio Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.4 MT	Gasoline	1396 cm³	109 hp	80 kW	135 N⋅m	Manual	FWD
1.6 AT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Manual	FWD
1.6 AT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Automatic	FWD
1.6 MT	Gasoline	1591 cm³	123 hp	90 kW	155 N⋅m	Manual	FWD
1.4 AT	Gasoline	1396 cm³	109 hp	80 kW	135 N⋅m	Automatic	FWD
1.2 MT	Gasoline	1248 cm³	82 hp	60 kW	123 N⋅m	Manual	FWD
1.4 MT	Gasoline	1396 cm³	90 hp	66 kW	220 N⋅m	Manual	FWD
1.4 MT	Diesel	1396 cm³	90 hp	66 kW	220 N⋅m	Manual	FWD

Kia Rio Dimensions

Sedan — Kia Rio Dimensions

Sedan Kia Rio Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.6 AT	4370 mm	1700 mm	1470 mm	2570 mm	1151 kg	1565 kg	160 mm
1.6 MT	4370 mm	1700 mm	1470 mm	2570 mm	1126 kg	1565 kg	160 mm
1.6 MT	4370 mm	1700 mm	1470 mm	2570 mm	1140 kg	Not provided	160 mm
1.6 AT	4370 mm	1700 mm	1470 mm	2570 mm	1218 kg	1565 kg	160 mm
1.4 AT	4370 mm	1700 mm	1470 mm	2570 mm	1140 kg	Not provided	160 mm
1.4 MT	4370 mm	1700 mm	1470 mm	2570 mm	1115 kg	Not provided	160 mm

Hatchback 5-door — Kia Rio Dimensions

Hatchback 5-door Kia Rio Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.4 MT	4120 mm	1700 mm	1470 mm	2570 mm	1120 kg	Not provided	160 mm
1.6 AT	4120 mm	1700 mm	1470 mm	2570 mm	1151 kg	1565 kg	160 mm
1.6 MT	4120 mm	1700 mm	1470 mm	2570 mm	1126 kg	1565 kg	160 mm
1.6 AT	4120 mm	1700 mm	1470 mm	2570 mm	1218 kg	Not provided	160 mm
1.6 MT	4120 mm	1700 mm	1470 mm	2570 mm	1145 kg	Not provided	160 mm
1.4 AT	4120 mm	1700 mm	1470 mm	2570 mm	1193 kg	Not provided	160 mm
1.2 MT	4120 mm	1700 mm	1470 mm	2570 mm	Not provided	Not provided	160 mm
1.4 MT	4120 mm	1700 mm	1470 mm	2570 mm	1164 kg	1690 kg	160 mm
1.4 MT	4120 mm	1700 mm	1470 mm	2570 mm	1164 kg	1690 kg	160 mm

Kia Rio Cargo Space

Sedan — Kia Rio Cargo Space

Sedan Kia Rio Cargo Space
Modification	Trunk volume min
1.6 AT	500 l
1.6 MT	500 l
1.6 MT	500 l
1.6 AT	500 l
1.4 AT	500 l
1.4 MT	500 l

Hatchback 5-door — Kia Rio Cargo Space

Hatchback 5-door Kia Rio Cargo Space
Modification	Trunk volume min	Trunk volume max
1.4 MT	389 l	1062 l
1.6 AT	389 l	1062 l
1.6 MT	389 l	1062 l
1.6 AT	389 l	1062 l
1.6 MT	389 l	1062 l
1.4 AT	389 l	1062 l
1.2 MT	389 l	1062 l
1.4 MT	389 l	1062 l
1.4 MT	389 l	1062 l

Kia Rio Trims and Equipment

Kia Rio trim levels sit on a chosen technical version, so equipment can differ even with the same engine and gearbox. On the 1.4 AT gasoline Sedan with automatic and front-wheel drive, you will see Comfort and Comfort (without warm options). Those names describe equipment packages, not a different powertrain.

Kia Rio Trims and Equipment
Modification	Body	Equipment
1.6 AT	Sedan	Luxe
1.6 AT	Sedan	Premium
1.6 AT	Sedan	Prestige
1.4 AT	Sedan	Comfort
1.4 AT	Sedan	Comfort (without warm options)
1.4 AT	Sedan	EX
1.4 AT	Sedan	LX
1.4 MT	Sedan	Comfort (without air A/Cing)
1.4 MT	Sedan	LX
1.4 MT	Hatchback 5-door	Comfort (without warm options)
1.6 AT	Hatchback 5-door	Luxe
1.6 AT	Hatchback 5-door	Premium
1.6 AT	Hatchback 5-door	Prestige
1.4 AT	Hatchback 5-door	Comfort
1.4 AT	Hatchback 5-door	Comfort (without warm options)
1.4 AT	Hatchback 5-door	EX
1.4 AT	Hatchback 5-door	LX
1.2 MT	Hatchback 5-door	LX
1.4 MT	Hatchback 5-door	LX
1.4 MT	Hatchback 5-door	LX
