Hyundai i20 Specs, Engines & Dimensions (2012–2014)

Hyundai i20 Engines and Transmissions

Hyundai i20 engine choices after the restyling include a fuel-efficient 1.1-litre diesel paired with a manual gearbox, ideal for low running costs. A larger 1.4-litre diesel with manual transmission provides stronger mid-range pull for extra-urban driving. For petrol fans, a 1.4-litre gasoline unit comes with a smooth automatic, prioritising easy urban commutes. All examples use front-wheel drive, keeping the i20 predictable.

Mini 5-doors — Hyundai i20 Engines and Transmissions

Mini 5-doors Hyundai i20 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.1 MT	Diesel	1120 cm³	75 hp	55 kW	153 N⋅m	Manual	FWD
1.4 MT	Diesel	1396 cm³	90 hp	66 kW	220 N⋅m	Manual	FWD
1.4 MT	Gasoline	1396 cm³	100 hp	74 kW	137 N⋅m	Manual	FWD
1.3 MT	Gasoline	1248 cm³	85 hp	62 kW	121 N⋅m	Manual	FWD
1.4 AT	Gasoline	1396 cm³	100 hp	74 kW	137 N⋅m	Automatic	FWD

Mini 3-doors — Hyundai i20 Engines and Transmissions

Mini 3-doors Hyundai i20 Engines and Transmissions
Modification	Engine type	Engine capacity	Maximum power	Maximum power, kw	Maximum torque N⋅m	Transmission	Type of drive
1.1 MT	Diesel	1120 cm³	75 hp	55 kW	153 N⋅m	Manual	FWD
1.3 MT	Gasoline	1248 cm³	87 hp	64 kW	121 N⋅m	Manual	FWD
1.4 MT	Gasoline	1396 cm³	100 hp	75 kW	137 N⋅m	Manual	FWD
1.4 AT	Gasoline	1396 cm³	100 hp	75 kW	137 N⋅m	Automatic	FWD

Hyundai i20 Dimensions

Mini 5-doors — Hyundai i20 Dimensions

Mini 5-doors Hyundai i20 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.1 MT	3995 mm	1710 mm	1490 mm	2525 mm	Not provided	Not provided	150 mm
1.4 MT	3995 mm	1710 mm	1490 mm	2525 mm	1222 kg	1565 kg	150 mm
1.4 MT	3995 mm	1710 mm	1490 mm	2525 mm	1025 kg	1565 kg	150 mm
1.3 MT	3995 mm	1710 mm	1490 mm	2525 mm	1073 kg	1515 kg	150 mm
1.4 AT	3995 mm	1710 mm	1490 mm	2525 mm	1053 kg	1565 kg	150 mm

Mini 3-doors — Hyundai i20 Dimensions

Mini 3-doors Hyundai i20 Dimensions
Modification	Length	Width	Height	Wheelbase	Curb weight	Max weight	Ground clearance, minimum
1.1 MT	3940 mm	1710 mm	1490 mm	2525 mm	Not provided	Not provided	150 mm
1.3 MT	3940 mm	1710 mm	1490 mm	2525 mm	Not provided	Not provided	150 mm
1.4 MT	3940 mm	1710 mm	1490 mm	2525 mm	1025 kg	1565 kg	150 mm
1.4 AT	3940 mm	1710 mm	1490 mm	2525 mm	1053 kg	1565 kg	150 mm

Hyundai i20 Cargo Space

Mini 5-doors — Hyundai i20 Cargo Space

Mini 5-doors Hyundai i20 Cargo Space
Modification	Trunk volume min
1.1 MT	295 l
1.4 MT	295 l
1.4 MT	295 l
1.3 MT	295 l
1.4 AT	295 l

Mini 3-doors — Hyundai i20 Cargo Space

Mini 3-doors Hyundai i20 Cargo Space
Modification	Trunk volume min
1.1 MT	295 l
1.3 MT	295 l
1.4 MT	295 l
1.4 AT	295 l

Hyundai i20 Trims and Equipment

Hyundai i20 trim levels such as Inspire and Premium tailor the 1.4 AT Mini 5-door to different needs. Inspire covers essential comforts for practical everyday use, while Premium adds convenience features that make longer journeys and daily driving more pleasant. This structure lets buyers balance budget against equipment on a single engine and gearbox combination.

Hyundai i20 Trims and Equipment
Modification	Body	Equipment
1.3 MT	Mini 5-doors	Inspire
1.3 MT	Mini 5-doors	Insight
1.4 AT	Mini 5-doors	Inspire
1.4 AT	Mini 5-doors	Premium
1.4 AT	Mini 5-doors	Supreme
1.4 AT	Mini 5-doors	Insight
