Catalog / Ford / Focus (North America) / 1 generation
Ford Focus (North America) Engines and Transmissions
Ford Focus (North America) engine and transmission combinations include the gasoline 2.3 MT and 2.3 AT sedans, plus the 2.0 MT estate. These examples use front-wheel drive. The manual versions give you control over gear selection, while the automatic sedan reduces the effort of driving in stop-start traffic.
Sedan — Ford Focus (North America) Engines and Transmissions
Sedan Ford Focus (North America) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1988 cm³ 111 hp 82 kW 169 N⋅m Manual FWD 2.0 AT Gasoline 1988 cm³ 111 hp 82 kW 169 N⋅m Automatic FWD 2.0 MT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Manual FWD 2.0 AT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Automatic FWD
Estate 5-door — Ford Focus (North America) Engines and Transmissions
Estate 5-door Ford Focus (North America) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Manual FWD 2.0 AT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Automatic FWD
Hatchback 3-door — Ford Focus (North America) Engines and Transmissions
Hatchback 3-door Ford Focus (North America) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Manual FWD 2.0 AT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Automatic FWD
Hatchback 5-door — Ford Focus (North America) Engines and Transmissions
Hatchback 5-door Ford Focus (North America) Engines and Transmissions Modification Engine type Engine capacity Maximum power Maximum power, kw Maximum torque N⋅m Transmission Type of drive 2.0 MT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Manual FWD 2.0 AT Gasoline 1988 cm³ 131 hp 96 kW 173 N⋅m Automatic FWD 2.3 MT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Manual FWD 2.3 AT Gasoline 2261 cm³ 145 hp 107 kW 200 N⋅m Automatic FWD
Ford Focus (North America) Dimensions
Sedan — Ford Focus (North America) Dimensions
Sedan Ford Focus (North America) Dimensions Modification Length Width Height Wheelbase Curb weight Ground clearance, minimum 2.0 MT 4450 mm 1699 mm 1430 mm 2616 mm 1190 kg 170 mm 2.0 AT 4450 mm 1699 mm 1430 mm 2616 mm Not provided 170 mm 2.0 MT 4450 mm 1699 mm 1430 mm 2616 mm 1250 kg 170 mm 2.0 AT 4450 mm 1699 mm 1430 mm 2616 mm 1182 kg 170 mm 2.3 MT 4450 mm 1699 mm 1430 mm 2616 mm Not provided 170 mm 2.3 AT 4450 mm 1699 mm 1430 mm 2616 mm Not provided 170 mm
Estate 5-door — Ford Focus (North America) Dimensions
Estate 5-door Ford Focus (North America) Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4526 mm 1699 mm 1369 mm 2616 mm 1195 kg 1640 kg 170 mm 2.0 AT 4526 mm 1699 mm 1369 mm 2616 mm Not provided 1640 kg 170 mm 2.3 MT 4526 mm 1699 mm 1369 mm 2616 mm 1260 kg Not provided 170 mm 2.3 AT 4526 mm 1699 mm 1369 mm 2616 mm Not provided Not provided 170 mm
Hatchback 3-door — Ford Focus (North America) Dimensions
Hatchback 3-door Ford Focus (North America) Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4270 mm 1699 mm 1430 mm 2616 mm 1146 kg 1670 kg 170 mm 2.0 AT 4270 mm 1699 mm 1430 mm 2616 mm Not provided 1670 kg 170 mm 2.3 MT 4270 mm 1699 mm 1430 mm 2616 mm 1270 kg Not provided 170 mm 2.3 AT 4270 mm 1699 mm 1430 mm 2616 mm Not provided Not provided 170 mm
Hatchback 5-door — Ford Focus (North America) Dimensions
Hatchback 5-door Ford Focus (North America) Dimensions Modification Length Width Height Wheelbase Curb weight Max weight Ground clearance, minimum 2.0 MT 4270 mm 1699 mm 1430 mm 2616 mm 1146 kg 1670 kg 170 mm 2.0 AT 4270 mm 1699 mm 1430 mm 2616 mm Not provided 1670 kg 170 mm 2.3 MT 4270 mm 1699 mm 1430 mm 2616 mm 1270 kg Not provided 170 mm 2.3 AT 4270 mm 1699 mm 1430 mm 2616 mm Not provided Not provided 170 mm
Ford Focus (North America) Cargo Space
Sedan — Ford Focus (North America) Cargo Space
Estate 5-door — Ford Focus (North America) Cargo Space
Estate 5-door Ford Focus (North America) Cargo Space Modification Trunk volume min Trunk volume max 2.0 MT 991 l 2067 l 2.0 AT 991 l 2067 l 2.3 MT 991 l 2067 l 2.3 AT 991 l 2067 l
Hatchback 3-door — Ford Focus (North America) Cargo Space
Hatchback 3-door Ford Focus (North America) Cargo Space Modification Trunk volume min Trunk volume max 2.0 MT 350 l 1210 l 2.0 AT 350 l 1210 l 2.3 MT 350 l 1210 l 2.3 AT 350 l 1210 l
Hatchback 5-door — Ford Focus (North America) Cargo Space
Hatchback 5-door Ford Focus (North America) Cargo Space Modification Trunk volume min Trunk volume max 2.0 MT 350 l 1210 l 2.0 AT 350 l 1210 l 2.3 MT 350 l 1210 l 2.3 AT 350 l 1210 l
